It is of vital importance, before attempting to operate
your engine, to read the general 'SAFETY
INSTRUCTIONS AND WARNINGS' section on
pages 2-6 of this booklet and to strictly adhere to the
advice contained therein.
Also, please study the entire contents of this
instruction manual, so as to familiarize yourself
with the controls and other features of the engine.
Keep these instructions in a safe place so that you
may readily refer to them whenever necessary.
It is suggested that any instructions supplied with
the aircraft, radio control equipment, etc., are
accessible for checking at the same time.
CONTENTS
STARTING THE ENGINE &
2-6
7-9
10
11-14
ENGINE EXPLODED VIEWS & PARTS LIST
15
CARBURETOR EXPLODED VIEWS& PARTS LIST
16
17
18-20
MEMO
1
21-25
26-27
28-29
30-31
32-33
34
35
36
