SERVICE
TFT-LCD MONITOR
LCD-Monitor
Chassis
PO24FS
Manual
Fashion Feature
- Worldwide TV Monitor Model
(Input to NT,PAL and SECAM areas supported).
- MFM (Multi-function Monitor)
: A variety of external sources supported as well as PC
PC, DVI, DVD, DTV Set-top Box.
- 16:10 display.
- Menu Opacity: Can control the opacity of PIP and OSD.
- CM LVDS (COLOR ENHANCER) Built-in Chip, Improved
Picture Quality (MAGICCOLOR PRO).
Model
242MP

Advertisement

Table of Contents
loading

Related Manuals for Samsung 242MP

Summary of Contents for Samsung 242MP

  • Page 1: Service Manual

    LCD-Monitor Chassis Model PO24FS 242MP SERVICE Manual TFT-LCD MONITOR Fashion Feature - Worldwide TV Monitor Model (Input to NT,PAL and SECAM areas supported). - MFM (Multi-function Monitor) : A variety of external sources supported as well as PC PC, DVI, DVD, DTV Set-top Box.
  • Page 2 Samsung Electronics Co.,Ltd. This Service Manual is a property of 416, Maetan-3Dong, Yeongtong-Gu, Suwon City, Gyeonggi-Do, Samsung Electronics Co., Ltd. Korea, 443-742 Any unauthorized use of Manual can be Printed in Korea punished under applicable International P/N : BN82-00124B-00 and/or domestic law.

  • Page 3: Product Main Specification

    -Adopts the Dolby Virtual and BBE features to enhance the sound quality. -MFM TV MONITOR (RF, FM, AV, S-VIDEO, COMPONENT, SCART, PC, DVI). -242MP: Uses the AMLCD 6300K Panel (PVA PANEL). -Video Input: RF, CVBS (Composite Video Baseband Signal),S-VIDEO,COMPONENT, SCART(RGB,CVBS),PC ANALOG and DVI.

  • Page 4: Specification

    2 Product Specifications 2-2 Specification Item Description LCD Panel TFT-LCD panel, RGB vertical stripe, normally black, 24-Inch viewable, 0.27 mm pixel pitch Scanning Frequency Horizontal : 31 kHz ~ 81 kHz (Automatic) Vertical : 56 Hz ~ 75 Hz (Automatic) Display Colors 16.7 Million colors Maximum Resolution...
  • Page 5 2 Product Specifications Item Description 1) MagicBright support. DISPLAY IMAGE PERFOMANCE - Text Mode : 160 cd/m2 < 90 ~160 > - Internet Mode : 220 cd/m2 < 190 ~ 250 > - Entertain Mode : 400 cd/m2 < 360 ~ 450 > 2) MagicColor Pro 2-1 MagicColor (Factory mode: Off) - Off: Not adaptive full color saturation enhancement...
  • Page 6 [ Cinema 23HD ] [ Pollock 24" ] Appearance LM230W01 LTM240W1-L01 LM230W02 LTM240M1-L01 Panel (LG Philips LCD) (SAMSUNG AMLCD) (LG Philips LCD) (SAMSUNG AMLCD) Power Adapter 8A/14V, 120Watt 24.5V/ 3.5A, 90Watt 24/14/13/5, 150W 5A/18.5V, 0.8A/5V SET Dimension (H W Dmm) Bezel(Width)/Depth 45.1 / 68.3...

  • Page 7: Option Specification

    2 Product Specifications 2-4 Option Specification Item Item Name Code.No Remark Quick Setup Guide BH68-00376M Warranty Card (Not available in all BH68-00261F locations) User's Guide, Monitor Driver, Natural Color BN59-00391D software BN39-00115A POWER CORD 3903-000085 AUDIO CABLE BN39-00061B RADIO ANTENNA AA39-00365A DVI CABLE BN39-00073A...

  • Page 8: Speaker Assy

    2 Product Specifications Item Item Name Code.No Remark Remote Control BN59-00434A Batteries 4301-000121 (AAA Connector 3705-001191 Side Cover SPEAKER ASSY BN96-01816A COVER ASSY SPEAKER BN63-01713A...
  • Page 9 2 Product Specifications Item Item Name Code.No Remark Speaker-Audio cable Screws (Black 4EA, Silver 4EA) Speaker-Side cover...

  • Page 10: Circuit Descriptions

    13 Circuit Descriptions 13 Circuit Descriptions 13-1 Overall Block Structure 13-1...

  • Page 11: Overall Block Description

    13 Circuit Descriptions 13-1-1 Overall Block Description <Main Board> Formats of input sources include RF, CVBS, S-VIDEO,COMPONENT,SCART,PC and DVI. GM1601H, a SCALER IC, has built-in TMDS that enables to process DVI signals without an additional IC and includes HDCP (High Bandwidth Digital Content Protection). This is a neighboring circuit component IC that consists of a DDR memory and a 2M flash memory chips.

  • Page 12: Main Board Part

    13 Circuit Descriptions 13-2 Main board part 13-2-1 VSP (Within VCTI) - 4 Inputs and 1 Output - CVBS, S-Video, RF, SCART MST9886 Input External Video Source Input Video(AV) S-Video Scart 13-2-2 MST9886 - 8 Bit ADC - 2 input 1 output - Used for Component input (Y, Pb, Pr Signal R,G,B Signal (D))
  • Page 13 13 Circuit Descriptions 13-2-3 MDIN150 - Macro Image Tech.( ) Deinterlacer IC - Motion Adaptive 3-D Deinterlacing - Serial I2C Communication MST9886 Output GM 1601 Input - If the AD converted video signal by ADC is an Interlaced signal, the signal is converted into a progressive signal.

  • Page 14: Sound Input

    13 Circuit Descriptions 13-2-5 S5D2544X - System LSI ( ) Enhancer IC - Serial I2C Communication - ASE, GTC, Color Tone, Gamma, 6-Color, Color Weakness SCALER Output PANEL Output LVDS Output LVDS Input 13-2-6 Sound <1> - Audio Switch : TEA6422 - Audio Delay AD : PCM1802 Delay : NJU26901...
  • Page 15 13 Circuit Descriptions 13-2-7 Sound <2> - Global version(All sound standard) - BBE, virtual Dolby Surround, Mute function - Audio decoder: MSP (within Vcti) - Amplifier : TPA3002 Sound Input Sound Input Sound Input Speaker Speaker TPA3002 Headphone amp Did I skip RF Sound Delay? RF Sound is output though the Vcti Sound Output, switched and delayed by TEA6422 and re-input to Vcti.
  • Page 16 13 Circuit Descriptions 13-3 MagicColor Pro 13-3-1 MagicColor (Factory mode: Off) - Off: Not adaptive full color saturation enhancement - Intelligent: Adaptive full color saturation enhancement except skin color - Full: Adaptive full color saturation enhancement - Demo: Display difference between adaptive full color and non-adaptive full color saturation enhancement 13-3-2 Color Tone (Factory mode: Noraml) - Warm2(4000K) , Warm1(5000K) , Normal(6500K) , Cool1(7000K) , Cool2(8000K), Cool3(9300K), Cool4(10000K)
  • Page 17 13 Circuit Descriptions MEMO 13-8...

  • Page 18: Factory Data

    4 Alignments and Adjustments 4 Alignments and Adjustments This section describes to adjust LCD monitor after replacing EEPROM, Main PBA or Panel. 4-1 Factory Mode Adjustments - PAL : Power off INFO MENU MUTE Power ON - NTSC : Power off MUTE Power ON 4-2 Factory DATA...
  • Page 19 4 Alignments and Adjustments c i t Black Level Expander/Compressor (BLEC) : Leaves bright images as they are and makes dark images darker. This function is used to adjust the visual quality. (TV, AV, S-Video and Scart only) Menus for White Balance Adjustment :Adjusts the Drive (gain) and Cutoff (offset) to adjust the color temperature and the screen display quality.
  • Page 20 4 Alignments and Adjustments Luma/Chrominance Transient Improvement (LTI/CTI) :Corrects the suite signal of the luminance and the color difference signal to enhance the sharpness and to reduce peaking. The higher the peaking value, the higher the sharpness. However, a higher sharpness also shows noise more clearly. (TV, AV, S-Video and Scart only) -Peaking :Adjusts the Peaking strength and weakness by adjusting the...
  • Page 21 4 Alignments and Adjustments Contrast, Brightness, Saturation and Tint Adjustment :Adjusts Br,Cont and Color,Tint by adjusting the output signal level of the VCTI IC.(TV, AV, S-Video and Scart only) -VSP(Video Processor) part -SCART YCrCb Control This menu is used to adjust the contrast, brightness, color saturation and tint of the Scart R,G,B output signal.
  • Page 22 4 Alignments and Adjustments -MSP(Multistandard Sound Processor) part -ADC9883 part s f f s f f Caution: This function is used to adjust the sense of color. However, adjusting to an extreme value may saturate a color. Red/BLUE/GREEN Input Gain/Offset Adjustment :Although the Offset/Gain can be adjusted in the DDP block of the VCT, ADC and Scaler, you can only adjust the Offset/Gain in DDP and Scaler in our implementation.
  • Page 23 4 Alignments and Adjustments Caution: PC analog Only ( 1920*1200@60Hz 16gray pattern) The color adjustment will only work properly with a particular pattern in a particular mode. Using the color adjustment in other cases may distort the color. s f f The Color Adjustment function provided by Gm1601.
  • Page 24 4 Alignments and Adjustments -Option/Color Weakness/Checksum -Factory Selection: Select the country in which the monitor has been manufactured -Erase NVRam : Erases the Scaler RAM. Do not select this menu. Bus-Stop : Stops the I2C that is used by Micom to ¡®force¡¯...
  • Page 25 4 Alignments and Adjustments -Mdin 150 If the value of the Coring is low, it is close to a moving picture. If the value is high, it is close to a still picture. (Common for Y and C) If the value of the Gain is low, it is close to a still picture.

  • Page 26: Ddc Jig Installation

    4 Alignments and Adjustments 4-3 DDC jig installation * Please use DVI cable connection adapter for DVI input. 4-4 How to execute DDC...
  • Page 27 4 Alignments and Adjustments Click “Sys Config” Select “Station : Write station” Check “Serial No and Week : Don’ t change” Click “Save” Click “Open” icon. Select “Connected Port #1” and Next “OK”. File Name - 242MPA.DDC : Analog 242MPD.DDC : DVI Press enter key on your keyboard.

  • Page 28: Micom Program Upgrade

    4 Alignments and Adjustments 4-5 Micom program upgrade Make a connection as done for DDC input, and supply power to the set. Run the Malibu Flash Downloader 1.7 program. 1. Select Flash Download. 2. Select 4MB_CF. 3. Select a program to download. 4.

  • Page 29: Factory Mode Adjustments

    4 Alignments and Adjustments 4-6 Factory Mode Adjustments 4-6-1 Factory Mode OSD GAMMA BLE MODE BLE GAIN BLE TILT STATIC BLE CUT OFF R CUT OFF B CUT OFF G CUT OFF WHITE DRIVE R DRIVE B DRIVE G DRIVE BLUE STRETCH LTI CORING LTI GAIN...

  • Page 30: Alignments And Adjustments

    4 Alignments and Adjustments Brightness Contrast Cb Saturation Cr Saturation Tint FM - AM - Presc NICAM - Presc SCART - Presc ADC 9883 RED Gain BLUE Gain GREEN Gain RED Offset BLUE Offset GREEN Offset Auto Color Custom Color RED Gain GREEN Gain BLUE Gain...
  • Page 31 4 Alignments and Adjustments Option Suwon CH. Table SESK CH. Table SAMEX CH Table Erase NVRam Bus-Stop Mdin Horizontal Peaking Fiter Edge Enhancement Fiter Deinterlacer Control Upd4084 DYGAIN DYCOR DCGAIN DCCOR VAPInv YPFG YHCor Color weakness-Testpattern Check Sum 4-14...

  • Page 32: Disassembly And Reassembly

    5 Disassembly and Reassembly 5 Disassembly and Reassembly This section of the service manual describes the disassembly and reassembly procedures for the PO24FS LCD monitor. WARNING: This monitor contains electrostatically sensitive devices. Use caution when handling these components. 5-1 Disassembly Cautions: 1.
  • Page 33 Disassembly and Reassembly 3. Remove 4 screws from the Shield and lift up the shield. FH, +, B, M3, L8, BLK, PLT, SWRCH18A FH, +, M3, L6, N1 PLT, SWRCH18A, FP 4. Disconnect cables and remove 4 screws from the Invert PCB shield . 5.
  • Page 34 Disassembly and Reassembly 6. Disconnect cables and remove 4 screws. 7. Lift up the board. 5-2 Reassembly Reassembly procedures are in the reverse order of dissasembly procedures, place the lamp wire correctly in the locator groove so that the wire will not bind or interfere with rear cover.
  • Page 35 Disassembly and Reassembly Memo...

  • Page 36: Troubleshooting

    6 Troubleshooting 6 Troubleshooting 6-1 No Power Does proper DC12V appear at Check Adapter C614(+12V _IN)? Does proper DC5V appear at Check Adapter FT670(+5V _IN)? Does proper DC5V appear at Check Adapter FT671(+5V _STDIN)? Does proper DC12V appear at Check related circuit of IC602 or IC300 FT672(+12V _MAIN)? Does proper DC5V appear at Check related circuit of IC603 or IC300...
  • Page 37 6 Troubleshooting WAVEFORMS IC602 IC606 C614 IC603 IC300 IC3000...
  • Page 38 6 Troubleshooting 6-2 No Lamp Does proper DC24V appear at Check Adapter C602(+24V _IN)? Does proper DC24V appear at Check related circuit of IC601 or IC300 FT600(+24V _INVERTER)? Check Inverter and Lamp of LCD Panel...
  • Page 39 6 Troubleshooting WAVEFORMS IC601 C602 FT600 IC300...
  • Page 40 6 Troubleshooting 6-3 No Video (PC Signal) Power Indicator is Green Does a signal appear at Pin. No. Check related circuit of IC102 or CN101 4, 10 of IC102(H/V Sync)? (Schmitte Trigger or 15P D-sub) Does a signal appear at C100, C102, Check related circuit of CN101 (15P D-sub) C104(R,G,B input)?
  • Page 41 6 Troubleshooting WAVEFORMS IC400 IC400 IC300 CN100 C102 C104 CN101...
  • Page 42 6 Troubleshooting 6-4 No Picture (TV Signal) Does a signal appear at Pin. No. 1,2 of Check CN703 and Tuner FT810(1F,2 of X6966M)? Does a signal appear at R821, R826, Check relatted circuit of IC802 and Q801, Q802, Q803(VCTi) R827(VCT_ROUT, GOUT, BOUT)? Does a signal appear at Pin.
  • Page 43 6 Troubleshooting WAVEFORMS IC900 IC302 FT810 IC7001 TUNER...

  • Page 44: No Picture (Video, S-Video, Scart)

    6 Troubleshooting 6-5 No Picture (Video, S-Video, Scart) Does a signal appear at R726(VIDEO_AR), R727(VIDEO_AL), Check CN701 and CN702 or AV Device R721(S-Video), R711(Scart)? Does a signal appear at R821, R826, Check relatted circuit of IC802 and Q801, Q802, Q803(VCTi) R827(VCT_ROUT, GOUT, BOUT)? Does a signal appear at Pin.
  • Page 45 6 Troubleshooting WAVEFORMS IC900 IC302 IC7001 CN702 CN701 6-10...

  • Page 46: No Picture(Component)

    6 Troubleshooting 6-6 No Picture(COMPONENT) Does a signal appear at R7069(COMP_Y), Check CN701 or AV Device R7067(COMP_PB), R7073(COMP_PR)? Does a signal appear at Check related circuit of IC7001(MST9886) RA7002~RA7003(ADC output)? Does a signal appear at RA902~RA903, Check related circuit of IC900(Mdin150) RA905~RA908 (Deinterlacer output)? Does a signal appear at Pin.
  • Page 47 6 Troubleshooting WAVEFORMS IC900 IC7001 CN701 6-12...

  • Page 48: No Sound(Component)

    6 Troubleshooting 6-7 No Sound(Component) Does a signal appear at R745(COMP_AR), Check CN701 or AV Device R747(COMP_AL)? Does a signal appear at R759(AIN_L), Check related circuit of IC700(TEA6422) R760(AIN_R)? Does a signal appear at C548(VAIN_L), Check related circuit of IC503(PCM1802), IC502(PCM1754) and IC505(NJU26901) C549(VAIN_R)? Does a signal appear at R510(LOUD_OUT_R),...
  • Page 49 6 Troubleshooting WAVEFORMS IC500 IC502 503 505 IC802 IC700 IC701 CN501 502 6-14...
  • Page 50 6 Troubleshooting 6-8 No Sound(TV) Does a signal appear at Pin. No. 1,2 of Check CN703 and Tuner FT810(IF1,2 of X6966M)? Does a signal appear at R862(TV_L), Check related circuit of IC802(VCTi) R863(TV_R)? Does a signal appear at R759(AIN_L), Check related circuit of IC700(TEA6422) R760(AIN_R)? Does a signal appear at C548(VAIN_L), Check related circuit of IC503(PCMI802),...
  • Page 51 6 Troubleshooting WAVEFORMS IC500 IC502 503 505 IC802 IC700 TUNER CN501 502 6-16...
  • Page 52 6 Troubleshooting 6-9 No Sound(VIDEO, S-VIDEO, SCART) Does a signal appear at R726(VIDEO_AR), Check CN701, CN702 or AV Device R727(VIDEO_AL), R723(SCART_RIN), R722(SCART_LIN)? Does a signal appear at R759(AIN_L), Check related circuit of IC700(TEA6422) R760(AIN_R)? Does a signal appear at C548(VAIN_L), Check related circuit of IC503(PCM1802), IC502(PCM1754) and IC505(NJU26901) C549(VAIN_R)?
  • Page 53 6 Troubleshooting WAVEFORMS IC500 IC502 503 505 IC802 IC700 CN702 CN701 CN501 502 6-18...
  • Page 54 6 Troubleshooting 6-10 No Sound(PC) Does a signal appear at L101(PC_AL), L102(PC_AR)? Check CN107 Does a signal appear at R759(AIN_L), Check related circuit of IC700(TEA6422) R760(AIN_R)? Does a signal appear at C548(VAIN_L), Check related circuit of IC503(PCM1802), IC502(PCM1754) and IC505(NJU26901) C549(VAIN_R)? Does a signal appear at R510(LOUD_OUT_R), Check related circuit of IC802 (VCTi)
  • Page 55 6 Troubleshooting WAVEFORMS IC500 IC502 503 505 IC802 IC700 CN107 CN501 502 6-20...
  • Page 56 6 Troubleshooting 6-11 Problems & Troubleshooting (Checklist) When display noises such as vertical lines or dots appear on the screen. When the screen repeatedly powers on and off, this is probably due to one of the Backlight wires being disconnected. When any of the function keys or the IR does High voltages run through the primary GND and not work.
  • Page 57 6 Troubleshooting 6-12 Voltage Checkpoint (INVERTER) While the power is off, the #2 pin STD of the 10-pin connector still runs an electric current of 5V while the others are turned off and go into standby. The consumption power is satisfied in this way. 6-22...
  • Page 58 6 Troubleshooting 6-13 Voltage Checkpoint (SMPS) When any one of the backlight lamp wires is disconnected, the screen will repeatedly power on and off, to protect the screen. First check the lamp wires. 6-14 Follow-ups for Board Replacement - Check if the PC colors are properly adjusted. - DDC Input (Both analog and digital inputs required) - Perform a hard power off after resetting in service mode.
  • Page 59 6 Troubleshooting MEMO 6-24...
  • Page 60 7 Exploded View & Parts List 7 Exploded View & Parts List -You can search for updated part codes through ITSELF web site. URL : http://itself.sec.samsung.co.kr/ 7-1 Device Development Figure...

  • Page 61: Parts List

    7 Exploded View & Parts List 7-2 Parts List DESCRIPTION CODE No. SPECIFICATION Q'ty REMARKS ASSY, COVER-FRONT BN96-01720 ABS HB PO24FS COVER-FRONT BN63-01659A ABS HB BK07 + SPRAY COVER-DECORATION BN63-01711A PMMA HB CLEAR + SILK COVER-KNOB CONTROL BN63-01712A ABS+PC B GR70 + Silver KNOB-CONTROL BN64-00350A ABS+PC HB GR70 + Silver...

  • Page 62: Wiring Diagram

    10 Wiring Diagram 10 Wiring Diagram 10-1...
  • Page 63 10 Wiring Diagram 10-1 Connector connection condition CN602 CN301 CN3000 CN501 CN502 CN102 CN101 CN701 10-2...
  • Page 64 11 PCB Diagrams 11 PCB Diagrams LVDS Power Inverter Comb CM LVDS Power Deinter Video lacer Decorder Scaler Tuner Fucntion RCA Jack SPK output D-sub PC Stereo input Headphone output 11-1...
  • Page 65 11 PCB Diagrams Loc. No. Description Loc. No. Description Q8009 TR-SMALL SIGNAL 136.0 144.8 Q801 TR-SMALL SIGNAL 173.5 84.4 IC100 IC-EEPROM 85.8 15.9 Q8010 TR-SMALL SIGNAL 146.5 99.7 IC101 IC-EEPROM 19.4 31.2 Q8011 TR-SMALL SIGNAL 145.7 108.9 IC102 IC-TTL 55.6 20.2 Q8012 TR-SMALL SIGNAL...

  • Page 66: Schematic Diagrams

    12 Schematic Diagrams 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-1 3D PC INPUT Part Schematic Diagram 12-1...
  • Page 67 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-2 SCALER Part Schematic Diagram 12-2...
  • Page 68 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-3 MCU & FUNCTION Part Schematic Diagram 12-3...
  • Page 69 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-4 VIDEO INPUT 2 Part Schematic Diagram 12-4...
  • Page 70 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-5 VIDEO Part Schematic Diagram 12-5...
  • Page 71 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-6 ADC Part Schematic Diagram 12-6...
  • Page 72 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-7 AUDIO & LIPSYNC Part Schematic Diagram 12-7...
  • Page 73 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-8 POWER & INVERTER Part Schematic Diagram 12-8...
  • Page 74 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-9 3D COMB FILTER Part Schematic Diagram 12-9...
  • Page 75 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-10 DEINTERLACER MDIN150 Part Schematic Diagram 12-10...
  • Page 76 12 Schematic Diagrams -This Document can not be used without Samsung's authorization. 12-11 CM_LVDS 2 Part Schematic Diagram 12-11...
  • Page 77 12 Schematic Diagrams MEMO 12-12...

  • Page 78: Electrical Parts List

    8 Electrical Parts List 8 Electrical Parts List 8-1 Main PCB Parts SA/SNA Remark Code No. Loc. No. Description Specification SPZ-PO24FSSBS/EDC SDI,PVA-ZPD BN94-00642M ASSY PCB MAIN PO24FS FT810 2904-001179 FILTER-SAW 36.125MHz,-,32.65-39.6MHz/0.5dB,SIP5K,+-0MHz/21.8dB,31.25MHz/37dB CN102 3701-001173 CONNECTOR-DVI 24P,3R,FEMALE,ANGLE,AUF CN101 3701-001219 CONNECTOR-DSUB 15P,3R,FEMALE,ANGLE,AUF CN702 3711-002001 CONNECTOR-HEADER BOX,20P,2R,2MM,STRAIGHT,SN,BLK...
  • Page 79 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification ZD712 0403-001435 DIODE-ZENER QZX363C5V6,5.32-5.88V,200MW,SOT-363,TP ZD718 0403-001435 DIODE-ZENER QZX363C5V6,5.32-5.88V,200MW,SOT-363,TP ZD106 0406-001163 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD ZD107 0406-001163 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD ZD501 0406-001163 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD ZD502 0406-001163 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD ZD704 0406-001163 DIODE-TVS CDS3C05GTA,6.4V/-/-,-,SMD ZD705 0406-001163 DIODE-TVS...
  • Page 80 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification IC700 1001-001178 IC-AUDIO SWITCH TEA6422D,AUDIO SWITCH ,SOIC,28P,300MIL,-,10.2V,0TO+70C,PLASTIC,-,-,-,-,10UA,ST,- IC503 1002-001387 IC-A/D CONVERTER PCM1802,24BIT,SSOP,20P,7.5x5.6x2mm,-,ST,-,PLASITC,3.30V,-40to+85C,-,A/D CONVERTE IC502 1002-001399 IC-D/A CONVERTER PCM1754,24BIT,SSOP,16P,5X4.8X1.75MM,-,TP,-,PLASITC,5V,-55TO+150C,80MW,- IC7001 1002-001403 IC-A/D CONVERTER MST9886-110,8Bits,QFP,128P,17.2x23.2mm,-,-,-,PLASTIC,3.3V,-20to+80C,643mW,- IC300 1003-001800 IC-LCD CONTROLLER gm1601H-CF,PBGA,416P,35x35x2.33mm,-,-,TR,PLASTIC,3.3V,0to+70C,-,2.4,- IC100 1103-000129 IC-EEPROM...
  • Page 81 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R362 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R363 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R364 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R365 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R366 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R367 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R368 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R369 2007-000070 R-CHIP...
  • Page 82 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R497 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R508 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R509 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R511 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R513 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R527 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R531 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R532 2007-000070 R-CHIP...
  • Page 83 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R847 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R848 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R849 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R850 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R851 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R853 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R861 2007-000070 R-CHIP 0ohm,5%,1/10W,TP,1608 R880 2007-000070 R-CHIP...
  • Page 84 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R460 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R467 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R471 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R473 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R474 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R475 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R476 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 R477 2007-000074 R-CHIP...
  • Page 85 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R7061 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 R7065 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 R8007 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 R8016 2007-000075 R-CHIP 220ohm,5%,1/10W,TP,1608 R905 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R916 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R917 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 R114 2007-000077 R-CHIP...
  • Page 86 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R8015 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8022 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8029 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8035 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8042 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8052 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8068 2007-000078 R-CHIP 1Kohm,5%,1/10W,TP,1608 R8072 2007-000078 R-CHIP...
  • Page 87 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R3028 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R3031 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R3034 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R3036 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R3037 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R3040 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R306 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 R345 2007-000090 R-CHIP...
  • Page 88 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R809 2007-000113 R-CHIP 33ohm,5%,1/10W,TP,1608 R810 2007-000113 R-CHIP 33ohm,5%,1/10W,TP,1608 R904 2007-000113 R-CHIP 33ohm,5%,1/10W,TP,1608 R602 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 R608 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 R633 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 R8055 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 R8045 2007-000121 R-CHIP...
  • Page 89 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification R8017 2007-000799 R-CHIP 360ohm,5%,1/10W,TP,1608 R737 2007-000857 R-CHIP 4.3Kohm,1%,1/10W,TP,1608 R522 2007-000913 R-CHIP 43Kohm,5%,1/10W,TP,1608 R601 2007-000979 R-CHIP 5.6Kohm,1%,1/10W,TP,1608 R620 2007-000979 R-CHIP 5.6Kohm,1%,1/10W,TP,1608 R151 2007-001002 R-CHIP 510ohm,5%,1/10W,TP,1608 R8047 2007-001044 R-CHIP 56ohm,5%,1/10W,TP,1608 R128 2007-001164 R-CHIP...
  • Page 90 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C507 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C514 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C627 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C633 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C637 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C644 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C704 2203-000140 C-CER,CHIP 1.5nF,10%,50V,X7R,TP,1608,- C705 2203-000140 C-CER,CHIP...
  • Page 91 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C3059 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3060 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3061 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3062 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3063 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3064 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3065 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C3066 2203-000189 C-CER,CHIP...
  • Page 92 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C616 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C618 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C620 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C622 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C623 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C653 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C658 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C668 2203-000189 C-CER,CHIP...
  • Page 93 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C8048 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C8049 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C8050 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C8051 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C8052 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C808 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C814 2203-000189 C-CER,CHIP 100nF,+80-20%,25V,Y5V,TP,1608, C819 2203-000189 C-CER,CHIP...
  • Page 94 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C440 2203-000236 C-CER,CHIP 0.1nF,5%,50V,C0G,1608 C608 2203-000236 C-CER,CHIP 0.1nF,5%,50V,C0G,1608 C650 2203-000236 C-CER,CHIP 0.1nF,5%,50V,C0G,1608 C100 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 C101 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 C102 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 C103 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,1608 C104 2203-000257 C-CER,CHIP...
  • Page 95 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C7047 2203-000903 C-CER,CHIP 0.0047NF,0.25PF,50V,C0G,TP,1608 C665 2203-000925 C-CER,CHIP 470NF,+80-20%,50V,Y5V,TP,2012 C7004 2203-000972 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 C7005 2203-000972 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 C7006 2203-000972 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 C7010 2203-000972 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 C7012 2203-000972 C-CER,CHIP 47nF,10%,16V,X7R,TP,1608 C7013 2203-000972 C-CER,CHIP...
  • Page 96 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C420 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C421 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C422 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C423 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C425 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C426 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C427 2203-005005 C-CER,CHIP 100nF,10%,16V,X7R,1608 C428 2203-005005 C-CER,CHIP...
  • Page 97 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C3042 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3043 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3046 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3050 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3054 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3056 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3071 2203-005437 C-CER,CHIP 10000nF,+80-20%,10V,Y5V,TP,3216 C3073 2203-005437 C-CER,CHIP...
  • Page 98 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C780 2402-001086 C-AL,SMD 100UF,20%,16V,WT,TP,6.6X6.6X5.3 C400 2402-001128 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM C401 2402-001128 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM C402 2402-001128 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM C403 2402-001128 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM C404 2402-001128 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM C424 2402-001128 C-AL,SMD 100UF,20%,16V,WT,TP,6.3X5.7MM C519 2402-001128 C-AL,SMD...
  • Page 99 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification C639 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C647 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C649 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C652 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C656 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C660 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C661 2409-001065 C-ORGANIC 82UF,20%,16V,WT,TP,8X6.9MM,- C781 2409-001065 C-ORGANIC...
  • Page 100 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification FT605 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT606 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT607 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT608 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT609 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT610 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT611 3301-001145 BEAD-SMD 60OHM,4516,6000,TP,70OHM/45MHZ,82OHM/760MHZ,0.01 FT612 3301-001145 BEAD-SMD...
  • Page 101 8 Electrical Parts List SA/SNA Remark Code No. Loc. No. Description Specification BN96-01980A ASSY SHIELD P-COVER PO24FS,SECC T0.8,546.7*352.3 BN63-01664A SHIELD-COVER PO24FS,SECC,T0.8 BN63-01881A EARTH-PLATE PO24FS,SUS,T0.1,11.0,30 BN91-00841G ASSY LCD-SPZ PO24FS BN07-00195B LCD-PANEL LTM240M1-L02,NB243T,8bit,546.4*352*36.9,16.7M,16:9,0.270*0.270,0~50,5V,PVA ZPD 8-24...
  • Page 102 DET,2000MM,24P/24P,BLACK,-,DVI-D(M) TO DVI-D(M) ACCESSORY BN39-00115A CBF SIGNAL NL5MO,15P/15P,2990,1830MM,UL2990,BLACK,D-SUB/MALE,-,-,- ACCESSORY BN59-00434A REMOCON Manet_Multi,TM79,40,SV-012P,EX,NT/PAL ACCESSORY BN63-01713A COVER-SPEAKER PO24FS,ABS+Urethane,T2.5,HB,GR70 ACCESSORY BN68-00739Q MANUAL-QSG PO24FS WW QSG,SyncMaster,W/W,Mojo100g,A4 ACCESSORY BN96-00840D ASSY MANUAL P-IB+QSG PO24FS 242MP,SYNCMASTER,W/W,30 LANG.,BN59-391D+BH68-376L QUICK_SETUP BH68-00376M MANUAL-02 LCDQUICK SETUP GUIDE,SYNCMASTER,KOREAN,DOMESTIC,MOJO100G,298,420 BN59-00391D S/W DRIVER-00,IB PO24FS 242MP,W/W,SYNCMASTER,W/W 8-25...
  • Page 103 8 Electrical Parts List 8-26...

  • Page 104: Block Diagram

    9 Block Diagrams 9 Block Diagram - Document can not be used without Samsung's authorization.
  • Page 105 9 Block Diagrams Memo...
