Technical Manual
JBL SMS1

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Power Capacity:
SMS1-Sub
80 Watts Continous Pink Noise
160 Watts Continuous Program
Peak
SMS1-Sat
10 Watts Continous Pink Noise
(x 4 Speakers)
20 Watts Continous Program
(x 4 Speakers)
40 Watts (x 4 Speakers)
• SPL Capability (1m):
SMS1-SUB, 104dB Average, 110dB Peak
SMS1-Sat, 92dB Average, 98db Peak
(x 4 Speakers)
• Frequency Range:
40–16 kHz (±10dB)
• Frequency Response:
45–13 kHz (±3db)
SYSTEM COMPONENTS:
• Cabinet:
Enclosure (Not For Sale)
• Grille:
See Drawing
• Low Frequency
200mm (8 in.) Cone Transducer
Transducer:
(338-259-001)
• DC Resistance:
3.5 ohm ±10%
PACKAGE
9, 10, 11
End Pad
Polybag
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
SYSTEM COMPONENTS
• High Frequency
Transducer:
320 Watts
• DC Resistance:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
•
Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

Warranty 59660
Owners Manual SMS1
SYS Man-Pl
SAT Spkr and
Hardware (4)
Packaging
Carton
Carton
(cont'd)
64mm (2-1/2 in.) (4)
(338236-001)
7.2 ohm ±10
–10 DBu Balanced Input
5.0V Input, 20 Hz to 400 Hz
3.0V Input, 100 Hz to 20 kHz
Subwoofer
458mm x 546mm x 280mm D
(18.0 x 21.5 x 11.0 in.D.)
SAT Satellite (4 Each)
135mm x 84mm x 202mm D
(5.3 x 3.3 x 7.95 in.D.)
69 lbs. (31.3 kg.)
SAT Spk (4 each)
338812-001 Gray
338811-001 White
RED
RED
RED/
RED/
RED/
BLK
BLK
BLK
Driver, Subwoofer
338259-001
WHT
GREY
NOTE: Sub Amp & D Amp Assy obsolete. Entire unit
must be replaced(SMS1-SUB, or SMS1-SUB-WH)
RED
RED
RED/
BLK
D Amp Assy
338299-001
N/A
Sub Amp
338208-001
N/A
02-05
