4358-4548 Avenue
5/22/08
4:30 PM
Replacement Parts List
NOTE: If requested color is not available, similar color will be
substituted.
Part
Cost
Quantity Total Cost
Crotch Strap/Buckle $4.99 X______= $ ______________
Harness Strap . . . . .$2.00 X______= $ ______________
Full Pad Set . . . . . .$39.99 X______= $ ______________
Cup Holder . . . . . . .$2.99 X______= $ ______________
Harness Retainer . . .$1.50 X______= $ ______________
Locking Clip . . . . . . .$2.50 X______= $ ______________
Tether Kit . . . . . . . .$9.99 X______= $ ______________
Latch Kit . . . . . . . .$24.99 X______= $ ______________
Instructions . . . . . . .$0.00 X______= $ ______________
Merchandise Total:
Shipping and handling:
Up to $25.00 . . . . . . . . . .$5.95
$25.01 to $50.00 . . . . . . .$6.95
$50.01 to $75.00 . . . . . . .$8.95
$75.01 to $100.00 . . . . . .$9.95
Sales Tax
(Indiana, California, Arkansas, and Massachusetts residents add applicable
sales tax.)
Grand Total
No shipping and handling on instructions for quantities under 6. Add $.50 for
each instruction over 6, then add applicable shipping and handling.
Fill Out For Credit Card
Visa
Card Exp. Date: ______________________________
Cardholder's Name: __________________________
Card Number: ______________________________
Signature____________________________________
Page 1
$ ____________
$ ______________
$100.01 to $150.00 . . . . .$10.95
$150.01 to $200.00 . . . . .$11.95
$200.01 and up . . . . . . . .$13.95
Outside Continental USA $10.00
$ ____________
$ ______________
Mastercard
50
S S a a f f e e t t y y 1 1 s s t t A A v v e e n n u u e e
C C a a r r S S e e a a t t
I I n n s s t t r r u u c c t t i i o o n n M M a a n n u u a a l l
www.safety1st.com
This child
restraint is
designed for
use by children
whose:
Weight:
5-40 pounds
(2.3-18 kg)
Height:
19-43 inches
(48-110 cm)
Read all instructions
BEFORE USING this child restraint.
KEEP INSTRUCTIONS FOR FUTURE USE.
IMPORTANT!
Failure to follow the warnings on the labels
and in the instruction manual can result in
the death or serious injury of your child.
Para recibir las instrucciones en español, llame al
1-800-544-1108 o solicitarse por escrito al dirección por arriba.
Eng. 4358-4548
