Page 1 StorageWorks Fibre Channel Storage Switch User's Guide AA-RHBYA-TE 135267-001 First Edition (April 1999) AA-RHBYA-TE 135267-001 Part Number Compaq Computer Corporation...
Page 2 MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE, GOOD TITLE AND AGAINST INFRINGEMENT. This publication contains information protected by copyright. No part of this publication may be photocopied or reproduced in any form without prior written consent from Compaq Computer Corporation. © 1999 Compaq Computer Corporation.
Page 3: Table Of Contents
Text Conventions ....................xiii Symbols in Text ....................xiii Symbols on Equipment..................xiv Rack Stability......................xv Getting Help ......................xv Compaq Technical Support................xv Compaq Website ...................xvi Compaq Authorized Reseller .................xvi +D=FJAH Introduction Option Kits ......................1-1 Front Panel Features.................... 1-2 +D=FJAH Installing the Switch Installation Summary ..................
Page 4 StorageWorks Fibre Channel Storage Switch User's Guide Turn on the Power to the Switch.................2-14 Enter the IP Address of Your Switch ..............2-16 +D=FJAH ! Managing the Switch Switch Management Overview................3-1 Comparing Switch Management Access Methods..........3-2 Fabric Management through a Single Ethernet Port..........3-4 Managing Using the Front Panel Buttons.............
Page 5 About This Guide v Flash Date ....................3-23 Boot Prom Date..................3-23 Port Type ....................3-23 Module Type....................3-24 Port Throughput ..................3-24 Temperature ....................3-25 Error Log ....................3-26 Licenses ..................... 3-27 Test Menu......................3-27 Managing Via Telnet..................3-27 Default Usernames and Security Levels ............
Page 6 StorageWorks Fibre Channel Storage Switch User's Guide Port Detail View Page .................. 5-3 Administrative Interface Page............... 5-4 Telnet Interface Page..................5-4 Installing Web Tools and Logging on to the Switch ..........5-4 Fabric Management and Licensing ............... 5-4 License Installation ..................5-5 Logging On to the Switch Via the Web............
Page 7 About This Guide vii Appendix A Glossary Definition of Terms.....................A-1 Appendix B Telnet Commands Introduction to Telnet Commands................B-1 General Commands.....................B-2 agtcfgSet ......................B-2 agtcfgShow ....................B-3 aliasShow.....................B-5 date ......................B-6 dateShow .....................B-7 errDump.......................B-7 errShow .......................B-7 fabricShow....................B-9 fastboot ...................... B-10 flashDefault....................B-11 flashDownload ...................B-12 flashSet ......................B-16 flashShow ....................B-22 h ........................B-26 help......................B-27...
Page 8 viii StorageWorks Fibre Channel Storage Switch User's Guide switchEnable....................B-54 switchName ....................B-55 switchShow....................B-56 tempShow ....................B-59 version .......................B-59 diagHelp ....................B-61 routeHelp ....................B-61 Diagnostic Commands ..................B-62 centralMemoryTest ..................B-62 crossPortTest....................B-62 portLoopbackTest ..................B-65 portRegTest ....................B-68 ramTest......................B-68 rdramTest....................B-69 spinSilk......................B-69 diagClearError ...................B-72 diagDisablePost..................B-72 diagEnablePost...................B-72 diagShow ....................B-73 Routing Commands...................B-76 bcastShow....................B-76 fspfShow....................B-78...
Page 9 Figure 2-3. Installing the Mounting Brackets in a RETMA 41U Rack ....2-7 Figure 2-4. Connecting an Extender Bracket to a Mounting Bracket ....2-8 Figure 2-5. Installing the Mounting Brackets in a RETMA 42U or Compaq Classic Rack ....................2-8 Figure 2-6.
Page 10 StorageWorks Fibre Channel Storage Switch User's Guide Figure 6-3. Zone Management Example 2 ............6-12 Figure 6-4. aliAdd Command ................6-18 Figure 6-5. aliCreate Command.................6-18 Figure 6-6. aliDelete Command.................6-18 Figure 6-7. aliRemove Command ..............6-19 Figure 6-8. aliShow Command ................6-19 Figure 6-9. cfgAdd Command ................6-20 Figure 6-10.
Page 11 About This Guide xi Figure B-26. portLogDump Command Example ..........B-39 Figure B-27. portLogShow Command Example..........B-40 Figure B-28. portPerfShow Command Example..........B-45 Figure B-29. portShow Command Example ............B-46 Figure B-30. portStatsShow Command Example..........B-49 Figure B-31. reboot Command Example ............B-53 Figure B-32. syslogdIp Command Example ............B-53 Figure B-33.
Page 12 StorageWorks Fibre Channel Storage Switch User's Guide Table 2-2 Fiber-optic Cable Specifications ............2-13 Table 2-3 Port LED Status Indicators..............2-14 Table 3-1 Comparison of Managegement Access Methods........3-2 Table 3-2 Front Panel Control Buttons..............3-6 Table 3-3 Front Panel and Telnet Commands............3-8 Table 3-4 Operating Mode Definitions..............3-15 Table 3-5 Port Types..................3-24 Table 3-6 Module Types ..................3-24...
Page 13: About This Guide
About This Guide This guide is designed to be used as step-by-step instructions for installation and as a reference for operation, troubleshooting, and future upgrades. Text Conventions This document uses the following conventions to distinguish elements of text: Keys Keys appear in boldface. A plus sign (+) between two keys indicates that they should be pressed simultaneously.
Page 14: Symbols On Equipment
StorageWorks Fibre Channel Storage Switch User's Guide CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information. IMPORTANT: Text set off in this manner presents clarifying information or specific instructions.
Page 15: Rack Stability
A technical support specialist will help you diagnose the problem or guide you to the next step in the warranty process. In North America, call the Compaq Technical Phone Support Center at 1-800-OK-COMPAQ .
Page 16: Compaq Website
StorageWorks Fibre Channel Storage Switch User's Guide Outside North America, call the nearest Compaq Technical Support Phone Center. Telephone numbers for world wide Technical Support Centers are listed on the Compaq website. Access the Compaq website by logging on to the Internet at http://www.compaq.com...
Page 17: Introduction
SAN functions. Compaq will support many of these and other SAN functions in the future. Contact your Compaq Authorized Reseller or Compaq Account Representative for specific information on these...
Page 18: Front Panel Features
1-2 StorageWorks Fibre Channel Storage Switch User's Guide Table 1-1 Option Kits Model Part Number 8-port Fibre Channel Switch, rack mount kit, software/doc. DS-DSGGA-AA kit, no GBICs 380591-B21 16-port Fibre Channel Switch, rack mount kit, DS-DSGGA-AB software/doc. kit, no GBICs 380578-B21 The Switch supports up to 16 fibre channel ports and consists of a motherboard, processor board, connectors for supporting up to 8 dual-port...
Page 19 Introduction 1-3 3 Front Panel Display: Shows menu selections. Used to configure and manaage the Switch using the front panel controls. Power Connector: Connects the Switch to the power source. ON/OFF Switch: Turns the Switch ON and Off. Front Panel Controls: The front panel controls are used to navigate through the built-in menus and to make menu selections.
Page 21: Installing The Switch
Chapter Installing the Switch Installation Summary To install the Switch you have to perform the following steps: Unpack the shipping container Select an operating location Select a Switch mounting method Install the Gigabit Interface Converter (GBIC) modules (ordered separately) Connect cables to the Switch Turn on the power to the Switch Enter the IP address.
Page 22: Table 2-1 Universal Mounting Kit Parts
2-2 StorageWorks Fibre Channel Storage Switch User's Guide A software and documentation kit An Installation Kit that includes rubber mounting feet A Universal Mounting Kit for mounting the Switch in an equipment rack. Table 2-1 describes the kit contents, while Figure 2-1 illustrates the parts.
Page 23: Selecting An Operating Location
Installing the Switch 2-3 SHR-1383 ™ š › œ Mounting bracket; Extender bracket; Slide bracket; Hardware bag Figure 2-1. Universal Mounting Kit Parts Selecting an Operating Location The Switch should be located in a secure or limited-access place to control use of the Switch front panel controls, and to ensure that cable connections are not compromised.
Page 24: Power Requirements
2-4 StorageWorks Fibre Channel Storage Switch User's Guide Power Requirements You connect the ac power cord to a switched connector on the bottom right side of the Switch front panel. The ac power source must meet these requirements: A properly–wired, earth–grounded ac outlet Voltage capability of 90–134 Vac or 180–257 Vac, and IEC 801-5 surge voltage Input voltage frequency of 50–60 Hz...
Page 25: Mounting The Switch In An Equipment Rack
Switch in a 19-inch equipment rack. Mounting the Switch in an Equipment Rack You can install the Switch in a RETMA 41U or 42U rack, in a Compaq rack, or in a metric SW600 rack. Observe the following guidelines: When you install the Switch in a closed or multi–rack assembly, be sure the air temperature measured at the Switch front panel does not exceed 40°...
Page 26: Figure 2-2. Positioning The Mounting Template
2-6 StorageWorks Fibre Channel Storage Switch User's Guide IMPORTANT: The template front should be positioned against the front rail, while the template rear should be positioned against the rear rail. SHR-1384 Figure 2-2. Positioning the Mounting Template 2. Pencil–mark the mounting bracket holes on each side of the rack with an M.
Page 27: Figure 2-3. Installing The Mounting Brackets In A Retma 41U Rack
Figure 2-3. Installing the Mounting Brackets in a RETMA 41U Rack Attaching Mounting Brackets in a RETMA 42U or Compaq Rack You can mount the Switch in this rack from either the front or the rear of the rack. Perform the following steps: 1.
Page 28: Figure 2-4. Connecting An Extender Bracket To A Mounting Bracket
4. Insert an alignment washer into each of the eight rail holes marked M (Figure 2–5). SHR-1382 Figure 2-5. Installing the Mounting Brackets in a RETMA 42U or Compaq Classic Rack 5. Attach each mounting bracket to the rack rails by inserting SEMS 10-32x5/8 screws through the alignment washers into the bracket holes;...
Page 29: Figure 2-6. Installing The Mounting Brackets In A Metric Rack
Installing the Switch 2-9 IMPORTANT: These screws must be fully tightened to ensure to strength of the extended bracket. 7. Go to the subsection entitled Attaching the Slide Brackets to the Switch. Attaching Mounting Brackets in a Metric Rack You mount the Switch in this rack from the front of the rack only. Perform the following steps: 1.
Page 30: Figure 2-7. Attaching The Slide Brackets, Rack-Front Installation
2-10 StorageWorks Fibre Channel Storage Switch User's Guide Attaching the Slide Brackets to the Switch You attach the slide brackets to the Switch using different bracket mounting holes for a rack-front installation than for a rack-rear installation. Use Figure 2–7 or Figure 2–8 to guide you in installing the slide brackets on the Switch; attach each bracket with two SEMS 10–32 x 9/32 pan–head screws.
Page 31: Figure 2-9. Securing The Brackets In The Front
Installing the Switch 2-11 Installing the Switch in the Rack To install the Switch in the rack you have to lift up the Switch and insert the slide brackets into the mounting brackets. CAUTION: Make sure you keep the Switch parallel to the floor when you insert the slide brackets into the mounting brackets;...
Page 32: Installing Gbic Modules
2-12 StorageWorks Fibre Channel Storage Switch User's Guide Installing GBIC Modules Each interface card installed in the Switch has two G_Ports. A GBIC module must be installed in each G_Port in order to use that port. Perform the following steps to install a GBIC module. CAUTION: The GBIC modules contain static sensitive components.
Page 33: Connecting The Storageworks Subsystem And The Host To The Switch
Installing the Switch 2-13 Figure 2-11. Attaching Cable Ties to the Rack Rails Connecting the StorageWorks Subsystem and the Host to the Switch The StorageWorks subsystem and the host connect to the Switch by fiber– optic cables that have the specifications shown in Table 2–2. Table 2-2 Fiber-optic Cable Specifications Item...
Page 34: Connecting An Ethernet Network To The Switch
2-14 StorageWorks Fibre Channel Storage Switch User's Guide Connecting an Ethernet Network to the Switch Connect an Ethernet 10BaseT network to the Switch by plugging in the Š Ethernet cable at the RJ-45 connector Connecting the Power Cable to the Switch ˆ...
Page 35 Installing the Switch 2-15 Fast yellow Error, fault with port. Flashes every 1/2 second. Steady green Online (connected with external device over cable) Slow green Online, but segmented (loopback cable or incompatible Switch) flashes every 2 seconds. Fast green Internal loopback (diagnostic). Flashes every 1/2 second.
Page 36: Enter The Ip Address Of Your Switch
2-16 StorageWorks Fibre Channel Storage Switch User's Guide Enter the IP Address of Your Switch To enter an IP address you use the front panel display and the four buttons under the display. (Refer to Chapter 3 for more information on managing the Switch using the front panel.) After the Switch successfully completes POST, proceed as follows: 1.
Page 37: Managing The Switch
Chapter Managing the Switch Switch Management Overview This chapter contains general information and examples on managing and monitoring the Switch. This chapter discusses: Comparing Switch Management Methods Managing the Switch Using the Front Panel Controls Managing Via Telnet Managing with SNMP syslog Daemon Managing the Switch using StorageWorks Command Console (refer to Chapter 4 for an introduction to StorageWorks Command Console...
Page 38: Comparing Switch Management Access Methods
3-2 StorageWorks Fibre Channel Storage Switch User's Guide Comparing Switch Management Access Methods There are several access methods for managing a Switch. Table 3-1 summarizes the different management access methods. Table 3-1 Comparison of Managegement Access Methods Method Description Local In-Band Out-of-band (Ethernet)
Page 39: Figure 3-1. Methods For Managing Information
Managing the Switch 3-3 Figure 3-1 shows the various methods and communication paths for accessing Switch management information. (StorageWorks Comand Console GUI interface is not shown.) Management Information Telnet Front-Panel SES Device SNMP Agent SNMP HTTP FC-IP IP Over Ethernet Push Buttons Fibre Channel (In Band) Ethernet (Out-of-Band)
Page 40: Fabric Management Through A Single Ethernet Port
Fabric Management through a Single Ethernet Port Multiple Compaq Storage Switches can be managed through a single IP connection to one of the Switches using Telnet services, Web Tools or SNMP commands, shown in Figure 3-2. Each Switch supports a 10bT Ethernet connection that has generally been the link for IP services.
Page 41: Managing Using The Front Panel Buttons
Managing the Switch 3-5 The Switches not connected to the Ethernet must have their default gateways set to the Fibre Channel IP address of the Switch connected to the Ethernet. Also, these Switches must have their FC IP addresses in a different subnet from the Ethernet IP addresses of the management station.
Page 42: Figure 3-3. Front Panel Buttons
3-6 StorageWorks Fibre Channel Storage Switch User's Guide SHR-1209 Figure 3-3. Front Panel Buttons Table 3-2 lists the primary control button functions. Button function changes depending on the menu level. Buttons either control navigating through the menus or incrementing/decrementing numeric values. Table 3-2 Front Panel Control Buttons Item Number...
Page 43: Activating Menu Display
Managing the Switch 3-7 Activating Menu Display The Switch’s front panel display is normally not illuminated. Pressing any front panel buttons activates the display: If no command is issued, the display turns off after 30 seconds Menus The menus are controlled using front panel buttons. From the initial display, users can navigate to commands and configure the Switch.
Page 44: Table 3-3 Front Panel And Telnet Commands
3-8 StorageWorks Fibre Channel Storage Switch User's Guide Table 3-3 shows the front panel commands and their equivalent Telnet command. NOTE: For most applications default values should be used. Table 3-3 Front Panel and Telnet Commands Menu RONT ANEL ELNET OMMAND EFAULT Conjfiguration...
Page 45 Managing the Switch 3-9 Table 3-3 Front Panel and Telnet Commands continued Menu RONT ANEL ELNET OMMAND EFAULT Switch Offline SwitchDisable Operation Switch Online SwitchEnable Port Disable portDisable <portno> Port Enable portEnable <portno> Close Telnet exit Session Reboot reboot Status Switch Name switchShow Worldwide Name...
Page 46: Configuration Menu
3-10 StorageWorks Fibre Channel Storage Switch User's Guide Table 3-3 Front Panel and Telnet Commands continued Menu RONT ANEL ELNET OMMAND EFAULT Port Register portRegTest Test Central Memory centralMemoryTest Test RDRAM Test rdramTest Port Loopback portLoopbackTest Test Cross Port Test crossPortTest Spin Silk Test spinSilk...
Page 47: Ethernet Subnetmask
Managing the Switch 3-11 To enter an IP address: 1. Use <Up> and <Down> to increment or decrement the displayed value. The underlined cursor indicates the numbers to modify. When entering a number, <Up> and <Down> start in the slow mode and move to the fast mode if the button is held down.
Page 48: Fibre Channel Subnetmask
3-12 StorageWorks Fibre Channel Storage Switch User's Guide 4. Use <Up> and <Down> to increment or decrement the displayed value. The underlined cursor indicates the numbers to modify. 5. After entering a number, press <Tab/Esc> to move the cursor to modify the next field.
Page 49: Domain
Managing the Switch 3-13 Domain Pressing <Enter>, while Domain is selected, displays: Domain The domain number uniquely identifies the Switch in a Fabric. This Switch ID is normally automatically assigned by the Switch and may be any value between 0 and 31. You may also assign the initial domain number manually. The Switch with the lowest initial domain will become the master Switch and control the configuration.
Page 50: E_D_Tov
3-14 StorageWorks Fibre Channel Storage Switch User's Guide E_D_TOV Pressing <Enter>, while E_D_TOV is selected, displays: E_D_TOV 2000 E_D_TOV (Error Detect Time Out Value) is adjustable in 1-second increments using the front panel controls, but its value is displayed in milliseconds.
Page 51: Virtual Channels
Managing the Switch 3-15 The operating modes are determined by the host adapter. The five operating modes for the Switch are described in Table 3-4. Table 3-4 Operating Mode Definitions Mode Description Normal operating mode, none of the following modes are in effect Tachyon operating mode.
Page 52: Vc Link Ctl
3-16 StorageWorks Fibre Channel Storage Switch User's Guide VC Link Ctl Pressing<Enter>, while VC Link Ctl is selected, displays: VC Link Ctl The Virtual Channel Link Control changes the link control channel. There are two options: 0 and 1. Option 0 forces data receipt acknowledgments on Class 2 channels to be sent back on the data channel.
Page 53: Vc Multicast
Managing the Switch 3-17 VC Multicast Pressing <Enter>, while VC Multicast is selected, displays: VC Multicast The virtual channel multicast is shown as channel 7 in the example. You may change the multicast transmission channel to either virtual channel 6 or 7. Verify that the multicast channel has the frame class priority set to the frame class of the expected traffic.
Page 54: Open/Opened Bb_Credit
3-18 StorageWorks Fibre Channel Storage Switch User's Guide time and increases performance. For a complete description of buffer-to-buffer credit, refer to the industry specification Fibre Channel Physical and Signalling Interface (FC-PH). Open/Opened BB_credit Pressing <Enter>, while Open/Opened BB_credit is selected, displays: Open/Opened BB_credit The number is used to specifies the maximum number of R_RDY's an FL_Port can issue (provided buffers are available) at the beginning of each loop...
Page 55: Operation Menu
Managing the Switch 3-19 NOTE: Resetting the Switch to default causes all configuration settings, names, and passwords entered to be reset to default settings, except the IP address and switchname. Operation Menu You control the Switch’s overall operational state using the Operation Menu. Pressing <Enter>...
Page 56: Port Disable
3-20 StorageWorks Fibre Channel Storage Switch User's Guide Port Disable Pressing <Enter>, while the Port Disable message is selected, displays a submenu to select the port to disable. Operation Menu: Port Disable Pressing <Enter>, while a selected port is displayed, disables the port. The LED associated with the port changes from green to amber indicating the selected port has been disabled.
Page 57: Reboot
Managing the Switch 3-21 Reboot Pressing <Enter> while the Reboot message is displayed causes the Switch to reboot immediately. Operation Menu: Reboot Rebooting the Switch causes it to immediately exit all current processes and states, and start the POST process. Exercise caution using the reboot command on a Switch connected to the Fabric.
Page 58: Firmware Version
3-22 StorageWorks Fibre Channel Storage Switch User's Guide The Switch’s WWN is a unique numeric identifier for each Switch and it is assigned by the manufacturer. A numbering scheme administrated globally assures that this WWN is unique. Firmware Version Pressing <Enter>, while Firmware Version is selected, displays: Firmware Version: V1.6 Current Date...
Page 59: Flash Date
Managing the Switch 3-23 Flash Date Pressing <Enter>, while Flash Date is selected, displays: Flash Date: Nov 16 18:15:59 PST 1998 This display gives the date and time for the last flash firmware update. If you upgrade the firmware in flash memory with a different firmware version, the Use this date to quickly date the new firmware was entered is displayed.
Page 60: Module Type
3-24 StorageWorks Fibre Channel Storage Switch User's Guide Table 3-5 Port Types Type Description E_Port is an interSwitch expansion port, used to connect to an E_Port of another Switch to build a larger Switch Fabric. F_Port, the Fabric access port is used to connect an N_Port and is used within the Switch Fabric for control and management..
Page 61: Temperature
Managing the Switch 3-25 This display shows port throughput on the Switch. The throughput number represents the number of bytes received plus the number of bytes transmitted per second and is displayed as bytes/second (B/s), kilobytes/second (KB/s) or megabytes/second (MB/s). You can select different ports using <Up> and <Down>, from port 0 to port 15, and all ports, and is used to monitor a single or the aggregate of all port(s) performance.
Page 62: Error Log
3-26 StorageWorks Fibre Channel Storage Switch User's Guide The temperature readings are shown at a rate of one reading per second on the front panel. Readings obtained during a Telnet session are single reading made at command execution. Error Log Selecting Error Log, then pressing <Enter>, displays: 01 Feb 12 08:48:29 (23) Err SENSOR-FAILED-3...
Page 63: Licenses
Managing the Switch 3-27 Licenses Selecting Licenses, then pressing <Enter>, displays: Licenses Features requiring a license are: Table 3-7 Licenses Type Description None Web Tools installed Zoning installed SES iinstalled Test Menu The tests available from the Test Menu are part of the diagnostic and fault isolation capabilities.
Page 64: Default Usernames And Security Levels
CAUTION: Access to root should be limited to those responsible for maintaining and modifying the Fabric. Commands available to root, if used inappropriately, can cause the Switch to stop functioning or to function abnormally. Root should only be used at the request of Compaq’s customer service.
Page 65: Changing Passwords
Managing the Switch 3-29 Changing Passwords 1. Log in as admin. 2. Issue the command passwd. Each username (admin, user, other) is displayed in sequence allowing the administrator to modify each password and name. 3. Enter a password or name while a user name is displayed to replace the existing password or name.
Page 66 3-30 StorageWorks Fibre Channel Storage Switch User's Guide SNMP-BULKGET (SNMPv2C). A manager can change management information on the agent. This operation is termed SNMP-SET. An agent can send information to the manager without being explicitly polled for. This operation is termed a trap in SNMPv1 or a notification in SNMPv2C. Traps or notifications would alert the manager to events that occur on the agent system, such as reboot.
Page 67: Snmpv1 Transports
Managing the Switch 3-31 iso(1) org(3) dod(6) internet(1) directory (1) mgmt(2) experimental(3) private (4) mib-2(1) fibreChannel(42) enterprise(1) system(1) interface(2) fcFe(1) bcsi(1588) sysObjectID(2) sysDescr(1) fcFabric(2) commDev(2) SHR-1210 Figure 3-5. MIB Tree A MIB object is therefore uniquely identified or named by its position in the tree.
Page 68: Mib-Ii Support
3-32 StorageWorks Fibre Channel Storage Switch User's Guide MIB-II Support There are eleven groups of objects specified in MIB-II. The Switch’s SNMP agent supports 3 of these groups. The three groups supported include: System group (object ID is {iso, org, dod, internet, mgmt, mib-2, 1}) Interfaces group (object ID is {iso, org, dod, internet, mgmt, mib-2, 2}) SNMP group (object ID is {iso, org, dod, internet, mgmt, mib-2, 11}) The following variables are modifiable via the SNMP set command, given an...
Page 69: Specific Mibs
Managing the Switch 3-33 Specific MIBs Five groups of MIBs are defined and supported: Switch System Group Fabric Group SNMP Agent Configuration Group Fibre Channel Port Group Name Server Group. Generic Traps Setting up the Switch’s SNMP connection to an existing managed network allows the network system administrator to receive the following generic traps: coldStart –...
Page 70: Agent Configuration
3-34 StorageWorks Fibre Channel Storage Switch User's Guide swFCPortScn - a notification that a Fibre Channel Port changes its operational state. For instance, the Fibre Channel Port goes from on-line to offline. The VarBind in the Trap Data Unit contains the corresponding instance of the port's operational status.
Page 71: Tools For Managing With Snmp
Storage Switch. The SNMP MIBs are integrated into the SWCC software. Refer to SWCC documentation included with the Storage Switch CD. Information is provided for Compaq CNMS and HP OpenView for those sites that want to control the Switch using tools other than SWCC.
Page 72 9. From the list select RFC1213-MIB and then click on next. If you do not have the RFC1213-MIB, it is available from Compaq. 10. The next window will ask you for the SysObject ID. This is the string of numbers that defines the object id for SNMP.
Page 73 Managing the Switch 3-37 19. Click OK on the next window, then choose “Browse MIB to parse” from the next window. 20. Choose the sw.mib. The MIB should compile successfully. Exit out of the Parse MIB Window. Exit out of the MIB Browser window. HP OpenView SNMP Setup The following example explains how to integrate a Switch Enterprise MIB to the SNMP database through HP OpenView in a Windows NT environment.
Page 74: Syslog Daemon
3-38 StorageWorks Fibre Channel Storage Switch User's Guide syslog Daemon A UNIX style syslog daemon (syslogd) process has been added. Syslogd reads system events and forwards system messages to users and/or writes the events to log files according to your system configuration. Introduction Syslogd reads system events and forwards system messages to users and/or stores them in log files according to your system configuration.
Page 75: Syslogd Support
Managing the Switch 3-39 An example entry in a syslogd log file is: Jul 18 12:48:00 sendmail[9558]: NOQUEUE: SYSERR(uucp): /etc/mail/sendmail.cf: line 0: cannot open: No such file or directory The first two items are the event’s date/time (as known by the machine where syslogd is running) and the machine name that issued the error.
Page 76: Error Message Format
3-40 StorageWorks Fibre Channel Storage Switch User's Guide Error Message Format Each error message logged sends the following information: Error number (1 for the first error after boot, increments by one with each new error). The error message, exactly as it is stored in the error log (and printed via the command errShow).
Page 77: Message Classification
Managing the Switch 3-41 Example: syslogd running on Switch sw9 is sending log events to the UNIX machine called example. The following is an example of a No memory error generated by the shell. This is a severity 1 (LOG_CRITICAL) error. syslogd is configured to store the errors in: /var/adm/silkworm file.
Page 78: Switch Configuration
3-42 StorageWorks Fibre Channel Storage Switch User's Guide Switch configuration To start the syslogd type the following command: syslogdIp <IP address of the syslogd machine> The command with no parameter prints the IP address of the current target syslogd machine. An IP address of 0.0.0.0 disables the forwarding of error messages to syslogd.
Page 79 Managing the Switch 3-43 The local7 prefix identifies the message from a Switch. Note that usually a file must exist and have the proper permission in order for the syslogd to write to it.
Page 81: Storageworks Command Console Software
Chapter StorageWorks Command Console Software Introduction The StorageWorks Command Console (SWCC) Fibre Channel Switch software allows you to manage the Switch, Fabric and your HSG80 Storage Subsystem from the same window. Once the software is installed, you can access, manage, and configure the Switch and Fabric by double-clicking on an icon, the Fabric Window, in Command Console’s Navigation Window, shown in Figure 4-1.
Page 82: Storageworks Command Console Fibre Channel Switch Applet Requirements
4-2 StorageWorks Fibre Channel Storage Switch User's Guide If you choose to install and use the Fibre Channel Switch software, detailed instructions on how to install, configure and use SWCC are provided in: Getting Started with SWCC for the Fibre Channel Switch Guide, xx- AA-RHDAA-TE (included in the Fibre Channel Switch software kit) Command Console V2.1 (HSG80) for RAID Array 8000/ESA12000 User’s Guide AA-RFR2C-TE, 387405-003 (inluded with your Storage...
Page 83: Accessing The Command Console Fabric Window
StorageWorks Command Console Software 4-3 Accessing the Command Console Fabric Window To create the Fabric, add Fabric elements, and monitor and manage the Switch and Fabric, double-click on the Fabric Network icon in the Navigation Window to display the Fibre Channel Network Window, shown in Figure 4-2. Figure 4-2.
Page 85: Managing The Switch Over The Web
Chapter Managing the Switch over the Web Introduction to Switch Web Tools This chapter discusses how to manage and monitor a Switch using Switch Web Tools. To manage the Switch over the web, you log onto a Switch from a host with a Java enabled web browser by means of the Internet or Intranet.
Page 86: Main Web Tools Screens
5-2 StorageWorks Fibre Channel Storage Switch User's Guide Glossary help Online help HTML pages Out-of-band interface via a 10BaseT Ethernet connection. Main Web Tools Screens The Web management tools provide five screens, shown in Figure 5–1, as follows: Figure 5-1. Main Web Tools Screens (Pages)
Page 87: Fabric View Page
Managing the Switch over the Web 5-3 Fabric View Page The Fabric View Page shows the number of network Switches and confirms worldwide names, domain IDs, and Switch names. Fabric Topology View Page The Fabric Topology View Page shows the physical configuration including active domains, paths and routing information.
Page 88: Administrative Interface Page
Switch Fabric Management and Licensing All Compaq Switches are license. It is possible that other Switches in a Fabric may not have the Web browser license key installed. This does not prevent a Switch from appearing in the Fabric view page on the browser, but attempting to click on an unlicensed Switch in order to manage that Switch results in a failure.
Page 89: License Installation
Switch, Web browsers are not able to connect to the Switch. The License Key has been installed at the factory for Compaq Switches. CAUTION: If an invalid key number is entered the existing license (if any) is overwritten, thus eliminating any/all valid license keys.
Page 90: Logging On To The Switch Via The Web
The Switch web management JAVA code runs on the following browsers: Internet Explorer 4.0 /Netscape 4.0 or above on Windows NT or Windows 95. Netscape 4.0/HotJava 1.1 or above on Compaq Tru64, and Solaris 2.5. To log on to the Switch Via the Web: 1. Launch a Web browser.
Page 91: Using Web Tools
Managing the Switch over the Web 5-7 Using Web Tools This section contains general information and examples on managing and monitoring the Switch via the Web Tools. It discusses each of the Web pages. They are: Fabric View Page Fabric Topology View Page General Switch View Page Port Detail View Page Performance View Page...
Page 92: Fabric View Page
5-8 StorageWorks Fibre Channel Storage Switch User's Guide Fabric View Page The Fabric View Page, Figure 5–2 is the first Web Page displayed. This is a global page and shows all Switches that comprise the Fabric. Note that any Switch in the Fabric can show the overall Fabric view, therefore it is not critical which Switch is accessed initially.
Page 93: Fabric Topology View Page
Managing the Switch over the Web 5-9 Fabric Topology View Page The Fabric Topology View Page, displayed by clicking on the Fabric Topology button, shows the physical configuration including active domains and paths, and routing information. Figure 5–3 and Figure 5–4 show the Fabric Topology View Page. The Fabric topology shown is viewed from the host domain (or host Switch) which is initially requested from the web browser.
Page 94: Figure 5-3. Fabric Topology View Page
5-10 StorageWorks Fibre Channel Storage Switch User's Guide Figure 5-3. Fabric Topology View Page...
Page 95: Figure 5-4. Fabric Topology View Page
Managing the Switch over the Web 5-11 Figure 5-4. Fabric Topology View Page...
Page 96: General Switch View Page
5-12 StorageWorks Fibre Channel Storage Switch User's Guide Table 5-1 Fabric Topology Fields Field Description List of Active Domains in the Fabric Displays the number of active domains in the Fabric including Switch names and Switch domain List of Active Paths by Domain. Displays the domain ID associated with the Switch name, WWN, and total number of paths by domain.
Page 97: Figure 5-5. General Switch View Page
Managing the Switch over the Web 5-13 Under normal conditions, the browser’s lower right corner holds animated thermometers and spinning fans. The color and blinking speed of the port LEDs are updated every 1 to 2.5 seconds depending on the operating system and browser used.
Page 98: Table 5-2 General Information Fields
5-14 StorageWorks Fibre Channel Storage Switch User's Guide Table 5-2 General Information Fields Field Description The Switch’s WWN is a unique numeric identifier for each Switch and it is assigned by the manufacturer. A numbering scheme administrated globally assures that this WWN is unique to this Switch. Domain ID The domain ID 0 to 31.
Page 99: Table 5-3 Port Led Status Indicators
Managing the Switch over the Web 5-15 If the port contains a GBIC, one of the following is shown: For copper GBICs, a graphic representation of a copper GBIC with the letters “CU” For short wave fiber GBICs, a graphic representation of a GBIC with the letters “S”...
Page 100: Port Detail View Page
5-16 StorageWorks Fibre Channel Storage Switch User's Guide Port Detail View Page The Port Detail View Page, Figure 5-6, provides statistics for each port. The page features 16 cascaded folders (tabs) one for each port. Each folder has a tab on the top to show the port number and a status light to tell the port state. The port information is updated once per second.
Page 101: Figure 5-6. Port Detail View Page
Managing the Switch over the Web 5-17 Figure 5-6. Port Detail View Page...
Page 102 5-18 StorageWorks Fibre Channel Storage Switch User's Guide Table 5-4 Port Detail View Page Fields Field Description Port Number The port number. Port Status The port state follows the GBIC type. The possible port states include: No_Card no card present in this Switch slot No_Module no GBIC module in this port No_Light the module is not receiving light No_Sync the module is receiving light but is out of sync...
Page 103: Table 5-4 Port Detail View Page Fields
Managing the Switch over the Web 5-19 Table 5-4 Port Detail View Page Fields continued Field Description Rx_flushed Number of flushed transmissions. Tx_unavail Number of interrupted transmissions. Free_buffer Number of buffer interrupts. Overrun Number of buffer overruns. Suspended Number of suspended interrupts. Parity_err Number of parity errors.
Page 104: Performance View Page
5-20 StorageWorks Fibre Channel Storage Switch User's Guide Performance View Page The Performance View Page, Figure 5-7, displays port and Switch throughput in bytes per second. Each port is numbered and throughput for the entire Switch is displayed under the individual port readings. The first 16 graphs show the port throughput for port number 0 through 15.
Page 105: Figure 5-7. Performance View Page
Managing the Switch over the Web 5-21 Figure 5-7. Performance View Page...
Page 106: Administrative Interface Page
5-22 StorageWorks Fibre Channel Storage Switch User's Guide Administrative Interface Page The Administrative Functions Page, Figure 5-8, is used to enable (or disable) the Switch or ports, and change the Switch name, date/time, IP addresses, user name, and password. It is also used to download firmware, and to reboot a Switch.
Page 107: Table 5-5 System Administration Fields
Managing the Switch over the Web 5-23 Table 5-5 System Administration Fields Category Field Description Switch Administration Switch Disabled If the box is checked, the Switch is disabled. It may need to be enabled after firmware upgrades, maintenance, and diagnostic tests. To enable the Switch, click the check box to remove the check and select the Commit...
Page 108 5-24 StorageWorks Fibre Channel Storage Switch User's Guide Table 5-5 System Administration Fields continued Category Field Description Gateway The gateway address. Refer to the network administrator for the appropriate gateway address value to enter here. Fibre Channel IP The Fibre Channel IP address. The default IP address is a temporary number derived from the Switch’s WWN.
Page 109 Managing the Switch over the Web 5-25 Table 5-5 System Administration Fields continued Category Field Description Reset Resets the display to previous defaults. Flash Download Host Name or Host IP The host name or Host IP address Remote User Name The remote user name Download File From The absolute directory path from...
Page 110: Telnet Interface Page
5-26 StorageWorks Fibre Channel Storage Switch User's Guide Telnet Interface Page The Telnet Interface Page, Figure 5-9, allows you to launch a Telnet session directly from your Web browser. Only users with admin or user privilege can access this page and is not in the help menu. To launch a Telnet session click on the Telnet button in the General Switch View Page.
Page 111: Popup Help Dialog Box
Managing the Switch over the Web 5-27 Popup Help Dialog Box The Popup Help Dialog Box, Figure 5-10, displays all glossary help and warning messages in a single popup dialog box. This popup dialog box can contain up to 100 entries, each with a time stamp. The top item is deleted sequentially in order to display a new message when over 100 entries are recorded.
Page 113: Zoning
Chapter Zoning Zoning Overview This chapter discusses general information about managing and monitoring the Switch using Zoning, as follows Zoning Components Zone Management Zone Enforcement Multi Switch Fabrics. Zoning is used to setup barriers between different operating environments, to deploy logical Fabric subsets by creating defined user groups, or to create test and/or maintenance areas that are separate within the Fabric.
Page 114: Increased San Control
6-2 StorageWorks Fibre Channel Storage Switch User's Guide Figure 6-1. Fabric with Three Zones The benefits of Zoning include: Increased environmental security where and when needed Optimization of Information Technology (IT) resources in response to user demand and changing user profiles Versatility to customize environments as and when needed.
Page 115: The Simplicity Of Zoning
Zoning 6-3 Zone members see only members in their zones and, therefore, access only one another. A device not included in a zone is not available to the zone devices. The Simplicity of Zoning Zoning involves: Zone Specification – Telnet commands are used to create, delete, and display zones, to add or remove zone members, and to configure zone sets.
Page 116: Questions And Answers About Zoning
6-4 StorageWorks Fibre Channel Storage Switch User's Guide Automatic, transparent distribution throughout the Fabric, a single failure cannot interrupt Zoning Enforcement to other SAN connections Automatic service scaling with Fabric size, no requirement to upgrade systems as Switches are added and connectivity increases Automatic, transparent deployment, no requirement for human intervention unless Zoning Specification must change.
Page 117: Zoning Specifications
Zoning 6-5 5. Why is this service a software service, wouldn't the zones be more stable in hardware? The Fabric retains the Zoning specification in two ways: Information persists until it is deleted or changed. Zoning information is recorded in the Switch’s flash memory. Zoning Specifications Zoning Specifications, they are: Administration...
Page 118: Zoning Management Methods
6-6 StorageWorks Fibre Channel Storage Switch User's Guide Zoning Management Methods Zones are managed by Telnet commands. Zoning Backup When the Switch is powered off and back on, Zoning configuration data is retained in Switch flash memory. Zoning Concepts This section discusses the Zoning concepts and components. Zoning Components Zoning has several components besides the zones themselves, as follows: Zone members...
Page 119 Zoning 6-7 Zone definitions are persistent. That is the definition remains in effect across reboots and power cycles until it is deleted or changed. A device may be a member of multiple zones. Zone Members Zone members may be specified using one of the following notations: Node World Wide Name Port World Wide Name Physical Fabric port number.
Page 120 6-8 StorageWorks Fibre Channel Storage Switch User's Guide Names. For example, the name “host” could be used as an alias for 10:00:00:60:69:00:00:8a. Zone Configurations A zone configuration is a set of zones. At any one time, zoning may be disabled or one zone configuration may be in effect. When a zone configuration is in effect, all zones that are members of that configuration are in effect.
Page 121: Using Zoning
Zoning 6-9 Using Zoning This section contains general information and examples on managing and monitoring the Switch using Zoning. The section discusses: Zoning Components Easy Setup and Administration of Zoning Zone Management Zone Enforcement Multi Switch Fabrics. Zoning Components Zoning has several components. In addition to the zones themselves, zoning is comprised of: zone members, zone aliases, and zone configurations.
Page 122: Zone Enforcement
6-10 StorageWorks Fibre Channel Storage Switch User's Guide Zoning uses logical device subsets within an SAN network for resource partitioning for management and access control. Within a zone the device sets may access one another. All Fabric connected devices can be configured into one or more zones.
Page 123 Zoning 6-11 Zone member additions and removals. Zone members can be displayed for all zones or by individual zone or configuration. The Telnet commands are based on the three object types: Alias Configuration Zone. They provide five “same set” commands for each object type: Create Delete Remove...
Page 124: Figure 6-2. Zone Management Example
6-12 StorageWorks Fibre Channel Storage Switch User's Guide admin> aliCreate "array1", "21:00:00:20:37:0c:76:85; 21:00:00:20:37:0c:71:df" admin> aliAdd "array1", "21:00:00:20:37:0c:72:51; 21:00:00:20:37:0c:71:0a" admin> aliCreate "array2", "21:00:00:20:37:0c:66:23; 21:00:00:20:37:0c:73:7f" admin> aliAdd "array2", "21:00:00:20:37:0c:9c:6b; 21:00:00:20:37:0c:66:3a" admin> aliCreate "loop1", "21:00:00:20:37:0c:67:e3; 21:00:00:20:37:0c:76:1f" admin> aliAdd "loop1", "21:00:00:20:37:0c:6a:40; 21:00:00:20:37:0c:59:7e" admin> cfgEnable "USA_cfg" zone config "USA_cfg"...
Page 125: Multi-Switch Fabrics
Zoning 6-13 Multi-Switch Fabrics There are two databases used by Zoning: The zone configuration data The N_Port login data. Zone Configuration Data This data is shown as the defined configuration by the cfgShow command, and is stored in flash by the cfgSave command. This data is a replicated database, all Fabric Switches have a complete copy.
Page 126 6-14 StorageWorks Fibre Channel Storage Switch User's Guide Adding a New Fabric Adding a new Fabric (a Fabric where there is no zone configuration information) to an existing Zoned Fabric is similar to adding a new Switch. All Switches in the new Fabric inherit the zone configuration data. If a zone configuration is enabled, then the same configuration becomes enabled in the new Switches.
Page 127: Zoning Commands
Zoning 6-15 Zoning Commands Zoning is managed by logging into a Switch via Telnet. Any Fabric Switch can be used to manage Zoning. A change made to the Zoning information on the master Switch is replicated through all Switches in the Fabric. This chapter contains information and examples on managing zones, including: Zone Alias Commands...
Page 128: Table 6-1 Zoning Commands
6-16 StorageWorks Fibre Channel Storage Switch User's Guide Table 6-1 Zoning Commands Command Description aliAdd Adds a member to a zone alias aliCreate Creates a zone alias aliDelete Deletes a zone alias aliRemove Removes a member from a zone alias aliShow Shows zone alias definition cfgAdd...
Page 129: Zone Alias Commands
Zoning 6-17 Table 6-1 Zoning Commands continued Command Description cfgRemove Removes a zone from a configuration cfgShow Show zones configuration definition zoneAdd Adds a member to a zone zoneCreate Creates a zone zoneDelete Deletes a zone zoneRemove Removes a member from a zone zoneShow Shows zone definition cfgClear...
Page 130: Figure 6-4. Aliadd Command
6-18 StorageWorks Fibre Channel Storage Switch User's Guide aliAdd Figure 6-4 shows the aliAdd command adds one or more new alias_members to an existing zone alias and is a list of one or more physical Fabric port numbers (for example, 1,2) or World Wide Names (for example, 10:00:00:60:69:00:00:8a) separated by semicolons.
Page 131: Figure 6-7. Aliremove Command
Zoning 6-19 aliRemove Figure 6-7 shows the aliRemove command which removes one or more alias_members from an existing zone alias. The members removed are found by an exact string match when removing multiple members order is important. If this command results in all members being removed the zone alias is deleted.
Page 132: Zone Configuration Commands
6-20 StorageWorks Fibre Channel Storage Switch User's Guide Zone Configuration Commands Zone Configuration commands allow you to manipulate the zone configurations. Table 6-3 summarizes the commands. Table 6-3 Zone Configuration Command Descriptions Command Description cfgAdd Adds a zone to a configuration cfgCreate Creates a zone configuration cfgDelete...
Page 133: Figure 6-11. Cfgdelete Command
Zoning 6-21 cfgDelete Figure 6-11 shows the cfgDelete which deletes an existing zone configuration. admin> cfgDelete "USA_cfg" value = 0 = 0x0 Figure 6-11. cfgDelete Command fgRemove Figure 6-12 shows the cfgRemove command which removes one or more cfg_members from an existing zone configuration. The members removed are found by an exact string match when removing multiple members order is important.
Page 134: Figure 6-13. Cfgshow Command
6-22 StorageWorks Fibre Channel Storage Switch User's Guide cfgShow Figure 6-13 shows the cfgShow command which prints the specified zone configuration definition if a parameter is given, otherwise all zone configuration information is printed. admin> cfgShow Defined configuration: cfg: USA_cfg Red_zone; Blue_zone; Green_zone zone: Blue_zone 0,1;...
Page 135: Zone Commands
Zoning 6-23 Zone Commands Zone commands allow you to manipulate the zones within a Fabric. Table 6-4 summarizes the commands. Table 6-4 Zone Command Descriptions Command Description zoneAdd Adds a member to a zone zoneCreate Creates a zone zoneDelete Deletes a zone zoneRemove Removes a member from a zone zoneShow...
Page 136: Figure 6-15. Zonecreate Command
6-24 StorageWorks Fibre Channel Storage Switch User's Guide zoneCreate Figure 6-15 shows the zoneCreate command which creates a new zone. zone_name is a C-style name for the zone and cannot already used for any other zone object. zone_members is a list of one or more physical Fabric port numbers (for example, 1,2), World Wide Names (for example, 10:00:00:60:69:00:00:8a), or zone alias names separated by semicolons.
Page 137: Figure 6-18. Zoneshow Command
Zoning 6-25 admin> zoneShow Defined configuration: cfg: USA_cfg Red_zone; Blue_zone; Green_zone zone: Blue_zone 0,1; array1; 0,2; array2 zone: Red_zone 0,0; loop1 alias: array1 21:00:00:20:37:0c:76:8c; 21:00:00:20:37:0c:71:02 alias: array2 21:00:00:20:37:0c:76:22; 21:00:00:20:37:0c:76:28 alias: loop1 21:00:00:20:37:0c:76:85; 21:00:00:20:37:0c:71:df Effective configuration: cfg: USA_cfg zone: Blue_zone 21:00:00:20:37:0c:76:8c 21:00:00:20:37:0c:71:02 21:00:00:20:37:0c:76:22 21:00:00:20:37:0c:76:28...
Page 138: Configuration Management Commands
6-26 StorageWorks Fibre Channel Storage Switch User's Guide Configuration Management Commands Configuration Management commands allow you to configure the zones. Table 6-5 summarizes the commands. Table 6-5 Configuration Management Command Descriptions Command Description cfgClear Clears all zone configurations cfgDisable Disables a zone configuration cfgEnable Enables a zone configuration cfgSave...
Page 139: Figure 6-20. Cfgdisable Command
Zoning 6-27 cfgDisable Figure 6-20 shows the cfgDisable command which disables the current zone configuration. The Fabric returns to non zoning mode where all devices see each other. admin> cfgDisable "USA_cfg" value = 0 = 0x0 Figure 6-20. cfgDisable Command cfgEnable Figure 6-21 shows the cfgEnable which requires a license.
Page 140: Figure 6-23. Cfgshow Command Example
6-28 StorageWorks Fibre Channel Storage Switch User's Guide cfgShow Figure 6-23 shows the cfgShow command output, the specified zone configuration definition if a parameter is given, otherwise all zone configuration information is printed. admin> cfgShow Defined configuration: cfg: USA1 Blue_zone cfg: USA_cfg Red_zone;...
Page 141: Appendix A Glossary
Appendix Glossary Definition of Terms Table A-1 contains terms relating to the Switch and Fibre Channel connections. Table A-1 Switch Terminology Term Definition Alias Server A Fabric software facility that supports multicast group management. Arbitrated Loop The FC Arbitrated Loop (FC-AL) is a standard defined on top of the FC-PH standard.
Page 142 A-2 StorageWorks Fibre Channel Storage Switch User's Guide Table A-1 Switch Terminology continued Community (SNMP) An SNMP community is a relationship between an SNMP agent and a set of SNMP managers that defines authentication, access control, and proxy characteristics. Credit Credit, applied to a Switch, is a numeric value that represents the maximum number of receive buffers provided by an...
Page 143 Glossary A-3 Table A-1 Switch Terminology continued E_Port A port is designated an E_Port when it is used as an interSwitch expansion port to connect to the E_Port of another Switch to build a larger Switch Fabric. E_D_TOV (Error Detect Time Out Value) E_D_TOV (Error-Detect Time-Out Value) defines the time the Switch waits for an expected response before declaring an...
Page 144 A-4 StorageWorks Fibre Channel Storage Switch User's Guide Table A-1 Switch Terminology continued Interswitch Link (ISL) ISL is a fiber link between two Switches Loop A loop is a configuration of devices (for example, JBODs) connected to the Fabric via and FL_Port interface card. Multicast Multicast is used when multiple copies of data are to be sent to designated multiple...
Page 145 Glossary A-5 Table A-1 Switch Terminology continued Isolated E_Port ISL is online but not operational between Switches because of overlapping domain ID or nonidentical parameters such as E_O_TOVs. Simple Network Management Protocol SNMP is a TCP/IP protocol that generally (SNMP) uses the User Datagram Protocol (UDP) to exchange messages between a management information base and a...
Page 147: Appendix B Telnet Commands
Appendix Telnet Commands Introduction to Telnet Commands This Appendix contains information and examples on managing and monitoring the Switch via Telnet, including: General Commands Diagnosis Commands Routing Commands License Commands Telnet Zoning commands are in Chapter 6. The user can configure, operate, and test the Switch using the following commands and settings through the Telnet interface.
Page 148: General Commands
B-2 StorageWorks Fibre Channel Storage Switch User's Guide General Commands General commands allow you to control basic Switch operations. agtcfgSet Figure B-1 shows the agtcfgSet command which is used to set the SNMP agent configuration to a fiber channel Switch. The fields are described in Table B-1.
Page 149: Agtcfgshow
Telnet Commands B-3 agtcfgShow Figure B-2 shows agtcfgShow command displays SNMP agent configuration. The fields are described in Table B-1. admin> agtcfgShow Current SNMP Agent Configuration Customizable MIB-II system variables: sysDescr = Fibre Channel Switch. sysLocation = End User Premise sysContact = Field Support.
Page 150: Table B-1 Agtcfgshow Field Command Descriptions
B-4 StorageWorks Fibre Channel Storage Switch User's Guide Table B-1 agtcfgShow Field Command Descriptions Field Description sysDescr System description: the default value is set as “ Fibre Channel Switch ” sysLocation The node’s physical location. The default setting is “End User Premise”. sysContact The identification and contact information for this system.
Page 151: Aliasshow
Telnet Commands B-5 aliasShow Figure B-3 shows the aliasShow command which displays local Alias Server information. If there is no local alias group, a message stating that is displayed. If there are one or more local entries, the output looks like. admin>...
Page 152: Date
B-6 StorageWorks Fibre Channel Storage Switch User's Guide date Figure B-4 shows the date command entered by itself displays the system date and time. You can also set the date as shown below: To set the date: 1. Type the command followed by the date in the format “mmddHHMMyy”...
Page 153: Dateshow
Telnet Commands B-7 dateShow Figure B-5 shows the dateShow command which displays system and firmware dates. admin> dateShow Current date: Mon Nov 16 21:34:08 1998 Booted at: Mon Nov 16 21:26:33 1998 Firmware date: Mon Nov 16 18:15:26 PST 1998 Flash date: Mon Nov 16 18:15:42 PST 1998 Boot prom date: Tue Feb 18 09:30:53 PST 1997...
Page 154 B-8 StorageWorks Fibre Channel Storage Switch User's Guide Date and time of the first occurrence each error type was sensed Total number of occurrences of each error type (up to 999) The maximum error number is 999. Error type Error level for each error type 0–Panic (when this level is reached, the Switch automatically reboots and the display no longer shows the error) 1–Critical...
Page 155: Fabricshow
Telnet Commands B-9 admin> errShow Error 02 -------- 0x103dc470 (tSilkworm): Apr 9 10:41:06 Error SENSOR-FAILED, 3, sensor 7 (Fan 2) is below minimum Type <CR> to continue, Q<CR> to stop: Error 01 -------- 0x103dc470 (tSilkworm): Apr 9 10:40:51 Error DIAG-TIMEOUT, 1, Port 2 receive timeout.
Page 156: Fastboot
B-10 StorageWorks Fibre Channel Storage Switch User's Guide Table B-4 fabricShow Command Field Descriptions Fabric Element Description switch n Each line shows: The Switch's domain ID (0 - 31) The Switch's embedded port ID The Switch's WorldWide Name The Switch’s Ethernet and FC IP addresses The Switch's name (a “>”...
Page 157: Flashdefault
Telnet Commands B-11 flashDefault Figure B-9 shows the flashDefault command resets the Switch to the factory default configuration values. This command may not be executed on an operational Switch. You must first disable the Switch using the switchDisable command. admin> flashDefault value = 0 = 0x0 Figure B-9.
Page 158: Flashdownload
In the event that an upgrade to the firmware of a Compaq StorageWorks Fibre Channel Switch is needed from the latest version of the Compaq...
Page 159 11. You can then click on the RSHD window and type Control C or select File and Exit to stop Rshd from running. 12. Select the Telnet window and type reboot to cause the Switch to reboot and copy the flash into the ram and come up running the latest Compaq StorageWorks Switch Firmware.
Page 160 5. Click on the RSHD window and type Control C or select File and Exit 6. to stop Rshd from running. 7. Select the Telnet window and type reboot to cause the Switch to reboot and copy the flash into the ram and come up running the latest Compaq StorageWorks Switch Firmware.
Page 161 Compaq Tru64 system. The Compaq StorageWorks Fibre Channel Switch uses remote shell capabilities of unix to log in to the Compaq TRu64 host on which the f/w image resides and copy the image over to the Compaq StorageWorks Fibre Channel Switch. As such, the user (mary) and Compaq StorageWorks Fibre Channel Switch host (IP address) must be in the .rhosts file of the Compaq Tru64 host to allow login...
Page 162: Flashset
B-16 StorageWorks Fibre Channel Storage Switch User's Guide 6. Instruct the Switch to reboot on the new firmware image <switch>:admin> reboot flashSet Figure B-10 shows the flashSet command which is used to set the Switch’s configuration parameters. This command may not be executed on an operational Switch.
Page 163: Table B-5 Flashset Command Field Descriptions
Telnet Commands B-17 Table B-5 flashSet Command Field Descriptions Field Description The domain number uniquely identifies the Switch in a Fabric. Normally, this Switch domain_id ID is automatically assigned by the Switch and may be any value between 0 and 31. The number represents the number of buffers, in a range from 1 to 16, available to b_to_b the host.
Page 164 B-18 StorageWorks Fibre Channel Storage Switch User's Guide Table B-5 flashSet Command Field Descriptions continued Field Description Error Detect Time Out Value E_D_TOV) is displayed in milliseconds. e_d_tov This timer is used to flag a potential error condition when an expected response is not received (an acknowledgment or reply in response to packet receipt, for example) within the set time limit.
Page 165 Telnet Commands B-19 Table B-5 flashSet Command Field Descriptions continued Field Description The administrator determines the adapter, then sets the Switch for the op_mode corresponding operating mode. The modes are: 0 - Normal operating mode, none of the following modes are in effect 1 - Tachyon operating mode.
Page 166 B-20 StorageWorks Fibre Channel Storage Switch User's Guide Table B-5 flashSet Command Field Descriptions continued Field Description The Virtual Channel Link Control changes the link control channel. There are two vc_link_ctl options: 0 and 1. Option 0 forces data receipt acknowledgments on Class 2 channels to be sent back on the data channel.
Page 167 Telnet Commands B-21 Table B-5 flashSet Command Field Descriptions continued Field Description FL_Port supports 2 frame collection methods, piling and bundling. If NL_Ports can collection handle multiple frame context in a loop, using piling can minimize loop tenancies, method reduce overhead and increase loop efficiency. The modes are: 0 - piling (frames are accumulated per destination AL_PA) 1 - bundling (frames are separated in different queues based on source/destination pairs)
Page 168: Flashshow
B-22 StorageWorks Fibre Channel Storage Switch User's Guide flashShow Figure B-11 shows the flashShow command which displays the Switch’s configuration status. The display shows remote host and flash configuration information for flash-0 and flash-1 (a mirrored image of flash-0 and included as a fail safe device).
Page 169: Table B-6 Flashshow Command Field Descriptions
Telnet Commands B-23 Code fl-0 fl-1 ---- ---- ---- text off 00000020 00000020 text addr 10330000 10330000 text size 0000d990 0000d990 data off 0000d9b0 0000d9b0 data addr 1033d9c0 1033d9c0 data size 00001b48 00001b48 magic 2112 2112 tsum 2638 2638 dsum 376d 376d hsum...
Page 170 B-24 StorageWorks Fibre Channel Storage Switch User's Guide Table B-6 flashShow Command Field Descriptions continued Field Description The receive data field size. df_size The resource allocation time out value. r_a_tov The error detect time out value. e_d_tov Operating mode. op_mode Virtual channel link control.
Page 171 Telnet Commands B-25 Table B-6 flashShow Command Field Descriptions continued Field Description The maximum number of R_RDY's an FL_Port issues (provided open bb_credit buffers are available) at the beginning of each loop tenancy. Fabric Address Notification (FAN frames are sent by the Fabric to send FAN frames notify the public loop devices about their node ID and address.
Page 172: Figure B-12. H Command Example
B-26 StorageWorks Fibre Channel Storage Switch User's Guide Table B-6 flashShow Command Field Descriptions continued Field Description Data checksum. dsum Header checksum. hsum Figure B-12 shows the h command which displays the shell history of the previous 20 commands. The older commands are replaced by new commands. The shell history is similar to the Unix Korn shell history facility with a built- in line editor (similar to Unix vi) that allows previously typed commands to be edited.
Page 173: Help
Telnet Commands B-27 help Figure B-13 shows the help command which displays a list of commands in alphabetical order. With an additional lists of “grouped” commands: NOTE: The help display changes depending on the login user level and will display only those commands that are available to the current user.
Page 174: Figure B-13. Help Command Example
B-28 StorageWorks Fibre Channel Storage Switch User's Guide admin> help agtcfgSet Set SNMP agent configuration agtcfgShow Print SNMP agent configuration aliasShow Print Alias Server information date Print/set the system date and time dateShow Print system and firmware dates errDump Print error log (no page breaks) errShow Print error log fabricShow...
Page 175: Figure B-14. I Command Example
Telnet Commands B-29 Figure B-14 shows the i command which displays a currently running task summary. The fields are described in Table B-7. admin>i NAME ENTRY STATUS ERRNO DELAY ---------- ------------ -------- --- ---------- -------- -------- ------- tExcTask _excTask 103f7eb0 0 PEND 1014f718 103f8200 3d0001...
Page 176 B-30 StorageWorks Fibre Channel Storage Switch User's Guide Table B-7 i Command Field Descriptions Field Description Task name Name Task entry point ID Entry Task ID Task priority with VxWorks Current executing state of task Status Program counter Stack pointer Last error number generated by this task ERRNO For pending tasks, the amount of time a...
Page 177: Ifshow
Telnet Commands B-31 ifShow Figure B-15 shows the ifShow command which displays network interface information. The display includes three sections organized by interface: ei – Ethernet 10-BaseT port lo – loopback interface fc – Fibre Channel. This section is omitted if IP over Fibre Channel is not configured admin>...
Page 178: Ipaddrset
B-32 StorageWorks Fibre Channel Storage Switch User's Guide ipAddrSet Figure B-16 shows the ipAddrSet command which is used to set the Switch’s Ethernet IP Address, Ethernet Subnetmask, Fibre Channel IP Address, Fibre Channel Subnetmask, and Gateway Address. The fields are described in Table B-8.
Page 179: Login
Telnet Commands B-33 login Figure B-17 shows the login command which logs in a user from a remote host. If a user is already logged in, the command logs out the user and allow a new user login. admin> login Figure B-17.
Page 180: Nsallshow
B-34 StorageWorks Fibre Channel Storage Switch User's Guide nsAllShow Table B-20 shows the nsAllShow command which displays a list of PIDs of nodes connected to the Fabric. The nsAllShow command optionally takes an integer parameter, the value of the FC-PH type. For example, nsAllShow 8 shows all SCSI- FCP nodes.
Page 181: Passwd
Telnet Commands B-35 passwd Figure B-22 shows the passwd command which is used to set user names and passwords. admin> passwd username 1 [admin]: "admin" password: username 2 [user]: "user" password: username 3 [other]: "other" password: Figure B-22. passwd Command Example The command syntax is passwd [ "user name"...
Page 182: Examples
B-36 StorageWorks Fibre Channel Storage Switch User's Guide Examples The following is a list of possible examples: 1. Invalid user name. admin> passwd "nobody" passwd: nobody is not a valid user name. 2. Invalid command usage. admin> passwd "" Usage: passwd [username] 3.
Page 183: Portdisable
Telnet Commands B-37 admin> passwd New username [admin]: Old password: New password: Re-enter new password: passwd: Passwords do not match; try again. New password: Re-enter new password: passwd: Passwords do not match; try again. New password: Re-enter new password: passwd: Number of failure attempts exceeded. New username [user]: ^C 8.
Page 184: Portenable
B-38 StorageWorks Fibre Channel Storage Switch User's Guide portEnable Figure B-24 shows the portEnable command which is used to enable a specific port. The first example shows a L-Port and the second an F-Port (as displayed by the switchShow command). The command syntax is portEnable <port #>.
Page 185: Portlogdump
Telnet Commands B-39 portLogDump Figure B-26 shows the portLogDump command which displays the port log without page breaks. Note that the portLogDump and portLogShow commands are the same except for how much information the port log displays without intervention. The fields are described in Table B-9. The command syntax is portLogDump.
Page 186: Portlogshow
B-40 StorageWorks Fibre Channel Storage Switch User's Guide portLogShow Figure B-27 shows the portLogShow command which displays the Switch’s port activity. Entries consist of Fabric login (ext. Link Service request to a Fabric F_Port, 22fffffe), Port login (ext. Link Service request to the management server, 22fffffa), and a SES Inquiry request (unsolicited command to the management server, 06fffffa).
Page 187: Table B-9 Portlogshow Command Field Descriptions
Telnet Commands B-41 Table B-9 portlogShow Command Field Descriptions Description Field NOTE: Lower case entries are defined in the “cmd” section in Table 5-9. Upper case entries in the “cmd” field are summarized in Table 5-9 and detailed in the Fibre Channel ANSI Standard (FC-PH). The event’s date and time in milliseconds.
Page 188 B-42 StorageWorks Fibre Channel Storage Switch User's Guide Table B-9 portlogShow Command Field Descriptions continued Description Field Either the port number of the affected port, or the last byte of a well-known Port address (e.g. fc for the well- known Name Server address). The cmd field represents different values depending on the task and event.
Page 189 Telnet Commands B-43 Table B-9 portlogShow Command Field Descriptions continued Description Field For ioctl events, the cmd field entries in upper case are Fibre Channel ANSI Standard (FC-PH) as follows: AC - Active State LR1 - Link Reset: LR Transmit State LR2 - Link Reset: LR Receive State LR3 - Link Reset: LRR Receive State LF1 - Link Failure: NOS Transmit State...
Page 190 B-44 StorageWorks Fibre Channel Storage Switch User's Guide Table B-9 portlogShow Command Field Descriptions continued Description Field For ioctl events, the cmd field entries in lower case are Switch specific as follows: a1 - port is an E_Port a2 - port is an F_Port a3 - port is segmented a4 - domain name is known a5 - port enable...
Page 191: Portperfshow
Telnet Commands B-45 portPerfShow Figure B-28 shows the portPerfShow command which displays the throughput for all ports. The output is terminated by typing Return or Ctrl-C. The throughput number represents the number of bytes received plus the number of bytes transmitted and is displayed as bytes/second (B/s). Throughput numbers are shown either as bytes/second, kilobytes/second (the number is followed by 'k') of megabytes/second (the number is followed by 'm').
Page 192: Portshow
B-46 StorageWorks Fibre Channel Storage Switch User's Guide portShow Figure B-29 shows the portShow command which displays a summary of all ports. The fields are described in Table B-10. The command syntax is portShow <port#>. admin> portShow 2 portFlags: 0x20021 PRESENT L_PORT LED portType: portState: 2...
Page 193: Table B-10 Portshow Command Field Descriptions
Telnet Commands B-47 Table B-10 portShow Command Field Descriptions Type Field Description Port Definition The bitmap port status. portFlags The port type (G_port or portType FL_Port) The port SNMP state. Values portState include Online/Offline. The port physical state - Insync portPhys The port LED state portScn...
Page 194 B-48 StorageWorks Fibre Channel Storage Switch User's Guide Table B-10 portShow Command Field Descriptions continued Type Field Description Number of suspended interrupts Suspended Number of parity errors. Parity_err Error Statistics Number of link failures. Link_failure Loss of synchronization. Loss_of_sync Loss of signal (no light). Loss_of_sig Protocol error.
Page 195: Portstatsshow
Telnet Commands B-49 portStatsShow Figure B-30 shows the portStatsShow command when used with a port number gives a static view of port status when the Switch executed the command. For example, to update the command and check if an error count is increasing, reissue the portStatsShow command to capture another snapshot.
Page 196: Table B-11 Portstatsshow Command Field Descriptions
B-50 StorageWorks Fibre Channel Storage Switch User's Guide NOTE: The first column shown in Figure 5-31 is an address and it is not included in the explanations below. Table B-11 portStatsShow Command Field Descriptions Field Description Number of 4-byte words transmitted from the port. stat_wtx Number of 4-byte words received by the port.
Page 197 Telnet Commands B-51 Table B-11 portStatsShow Command Field Descriptions continued Field Description Received data: the number of 8b/10b encoding errors that have er_enc_in occurred inside frame boundaries. This counter is generally a nonzero value, although occasional errors may occur on a normal link and give a zero result.
Page 198 B-52 StorageWorks Fibre Channel Storage Switch User's Guide Table B-11 portStatsShow Command Field Descriptions continued Field Description Number of times the FL_Port has been sent CLS while in the fl_cls_rx OPEN state Number of times FL_Port could not send or forward CLS because fl_bb_stall receive BB_Credit was not available (Login BB_Credit = 1) or the number of times FL_Port could not send R_RDY immediately after...
Page 199: Reboot
Telnet Commands B-53 reboot Figure B-31 shows the reboot command which reboots the Switch to the stored configuration in flash memory and takes about 1 1/2 minutes. The Switch maybe in any operational state (enabled or disabled) before rebooting. admin> reboot Figure B-31.
Page 200: Switchenable
B-54 StorageWorks Fibre Channel Storage Switch User's Guide switchEnable The switchEnable command enables the Switch and provides Fabric information. The Switch may need to be enabled after maintenance and diagnostic tests. In Figure B-34, the Switch is enabled with a domain ID of 1. After the Fabric is reconfigured this Switch is the principle address manager that is capable of assigning domain IDs to other Switches in the same Fabric.
Page 201: Switchname
Telnet Commands B-55 switchName Figure B-35 shows the switchName command which displays or sets the Switch’s name. If a new name is specified and it is enclosed in quotes “” the command sets the Switch to that name. If no new name is included, the command displays the Switch’s name.
Page 202: Switchshow
B-56 StorageWorks Fibre Channel Storage Switch User's Guide switchShow Figure B-36 shows the switchShow command which displays Switch and port status. The fields are described in Table B-12. admin> switchShow switchName: open146 switchState: Online switchRole: Principal switchDomain: switchId: fffc41 switchWwn: 10:00:00:60:69:00:04:64 port 0: sw...
Page 203: Table B-12 Switchshow Command Field Descriptions
Telnet Commands B-57 Table B-12 switchShow Command Field Descriptions Field Description The Switch name. switchName There are three possibilities for switchRole including: switchRole Master: the principal Switch, as defined in FC-SW Slave: this switch is enabled and not the principal Switch Disabled: the Switch is disabled.
Page 204 B-58 StorageWorks Fibre Channel Storage Switch User's Guide Table B-12 switchShow Command Field Descriptions continued Field Description The GBIC type follows the port number. The four GBIC types GBIC type include: -- no GBIC present sw shortwave GBIC lw longwave GBIC cu copper GBIC The port state follows the GBIC type.
Page 205: Tempshow
Telnet Commands B-59 tempShow Figure B-37 shows the tempShow command which shows the Switch’s temperature as measured by five sensors on the motherboard. admin> tempShow Centigrade Fahrenheit value = 11 = 0xb Figure B-37. tempShow Command Example version Figure B-38 shows the version command. The fields are described in Table B-13.
Page 206: Table B-13 Version Command Field Descriptions
B-60 StorageWorks Fibre Channel Storage Switch User's Guide Table B-13 version Command Field Descriptions Field Description VxWorks operating environment version VxWorks version used on the processor Switch firmware version Firmware version Switch firmware release date and time Made on...
Page 207: Diaghelp
Telnet Commands B-61 diagHelp Figure B-39 shows the diagHelp command which displays the diagnostic help commands available for troubleshooting Switch problems. admin> diagHelp centralMemoryTest Central memory diagnostic crossPortTest Cross-connected port diagnostic portLoopbackTest Port internal loopback diagnostic portRegTest Port register diagnostic ramTest System DRAM diagnostic rdramTest...
Page 208: Diagnostic Commands
B-62 StorageWorks Fibre Channel Storage Switch User's Guide Diagnostic Commands Diagnostic commands enables you to monitor, test, and evaluate the Switch. centralMemoryTest Figure B-42 shows the centralMemoryTest command which is used to check the motherboard’s memory. A diagnostic pattern is written and read from memory to ensure all memory is functioning properly.
Page 209 Telnet Commands B-63 The command syntax is crossPortTest <nFrames>, <0 or 1>, where <nFrames> determines the number of frames to run If you do not include the <nFrames> parameter the test runs until you press Return. <0 or 1> determines if a single port looped back to itself is allowed: 0 –...
Page 210: Figure B-42. Crossporttest Command Example
B-64 StorageWorks Fibre Channel Storage Switch User's Guide admin> crossPortTest Running Cross Port Test ..***** One or more ports is not active, please doublecheck fibres on all ports. Port SNMP Physical Flags ------------------------------- 0: Offline Port_Flt PRESENT L_PORT 1: Offline No_Module PRESENT L_PORT CBL_LB 2: Offline...
Page 211: Portloopbacktest
Telnet Commands B-65 portLoopbackTest Figure B-44 shows the portLoopbackTest command which is used to validate the data path to the optical interface and is intended to verify that the G_port or FL_Port interface card is error free. This is an internal test and checks all of the Switch’s internal firmware and circuitry.
Page 212: Figure B-43. Portloopbacktest Command Example
B-66 StorageWorks Fibre Channel Storage Switch User's Guide admin> portLoopbackTest Running Port Loopback Test ..Diags: (Q)uit, (C)ontinue, (S)tats, (L)og: s Diagnostics Status: Sun May 18 21:49:58 1970 port#: 0 diags:OK OK OK state:UP UP UP fl0: 311 frTx 311 frRx LLI_errs.
Page 213: Table B-14 Portloopbacktest Command Field Descriptions
Telnet Commands B-67 Table B-14 portloopbackTest Command Field Descriptions Field Description The duration of the portLoopbackTest. Diagnostics Status The port number. port# Possible values include OK, BAD. diags Possible values include UP (active), DN (inactive). state st0-16 The tested ports. The display shows the diagnostics frames are transmitted and received and Low Level Interface counts (LLI_errs).
Page 214: Portregtest
B-68 StorageWorks Fibre Channel Storage Switch User's Guide portRegTest Figure B-45 shows theportRegTest command which is used to check each register located on the motherboard and interface card(s) chips. Registers are set under firmware control and are used to control the hardware route selection and other internal hardware functions.
Page 215: Rdramtest
Telnet Commands B-69 rdramTest Figure B-47 shows the rdramTest command which is used to check the memory on the FL_Port interface cards. A diagnostic pattern is written and read from memory to ensure all RDRAM memory is properly functioning. This command may not be executed on an operational Switch. Before issuing rdramTest, disable the Switch using the switchDisable command.
Page 216: Figure B-47. Spinsilk Command Example 1
B-70 StorageWorks Fibre Channel Storage Switch User's Guide NOTE: When running the Spin Silk Test, you must set the operating mode value to 0 or 1. Modes 2 and 3 do not send out the ELP used to discover Switches. If the ELP is not sent, the Switch does not know the port is connected to another port on the same Switch and the test fails.
Page 217: Figure B-48. Spinsilk Command Example 2
Telnet Commands B-71 spinSilk nMillions where nMillions is the number of frames for the test to execute expressed as millions of frames. If you do not include the nMillions parameter, the spinSilk test runs until <return> is pressed. admin> spinSilk 5 Running Spin Silk .....
Page 218: Diagclearerror
Figure B-50 shows the diagDisablePost command which disables POST processing. The boot time without POST processing is approximately 25 ~ 30 seconds. Compaq recommends that POST processing always be executed to ensure the operational status of the Switch during the power on stage. admin> diagDisablePost Updating flash ...
Page 219: Diagshow
Telnet Commands B-73 diagShow Figure B-52 shows the diagShow command which summarizes the diagnostics results run since the Switch was last booted, including POST results. The fields are described in Table B-15. NOTE: This command shows an FL_Port as being offline if you are running cross port connected testing, the reason is that you can have only one Principle per Switch.
Page 220: Figure B-51. Diagshow Command Example
B-74 StorageWorks Fibre Channel Storage Switch User's Guide admin> diagShow 4 Diagnostics Status: Thu Jul 30 11:08:26 1998 port#: diags: state: st0: 4 frTx 4 frRx LLI_errs. <looped-1> st1: 4 frTx 4 frRx LLI_errs. <looped-0> st2: 4 frTx 4 frRx LLI_errs.
Page 221: Table B-15 Diagshow Command Field Descriptions
Telnet Commands B-75 Table B-15 diagShow command field descriptions Field Description The port status Diag Port Status The port number port# Possible values include OK, BAD. diags Possible values include UP (online), DN (offline.) state st0-16 The tested chips. The display shows the diagnostics frames are transmitted and received and Low Level Interface counts (LLI_errs).
Page 222: Routing Commands
B-76 StorageWorks Fibre Channel Storage Switch User's Guide Routing Commands Routing commands allow you to view Switch routing information. bcastShow Figure B-53 shows the bcastShow command which displays broadcast tree information, and all ports that are currently transmitting and receiving broadcast frames.
Page 223: Table B-16 Bcastshow Bitmap Field Descriptions
Telnet Commands B-77 Table B-16 bcastShow Bitmap Field Descriptions Bitmap Field Description The multicast group. Group Member Ports All ports currently transmitting or receiving broadcast frames. Member ISL Ports Ports that belong to the interSwitch broadcast distribution tree, as selected by the dynamic broadcast path selection protocol.
Page 224: Fspfshow
B-78 StorageWorks Fibre Channel Storage Switch User's Guide fspfShow Figure B-54 shows the fspfShow command which displays Fibre Channel Shortest Path First (FSPF) information. The fields are described in Table B-17. admin> fspfShow version domainID isl_ports = 0x00000000 minLSInterval fspfQ = 0x103ab560 fabP = 0x103abde0...
Page 225: Interfaceshow
Telnet Commands B-79 interfaceShow Figure B-55 shows the interfaceShow command which displays FSPF interface information. This includes static information about the port (for example, variables allocated even when a port is down), and “neighbor” information which includes variables associated with the remote Switch connected to the port.
Page 226: Figure B-54. Interfaceshow Command Example
B-80 StorageWorks Fibre Channel Storage Switch User's Guide admin> interfaceShow idbP = 0x103a6490 Interface 9 data structure: nghbP = 0x1036d9b0 ifNo cost = 1000 delay upCount iState = UP Neighbor 9 data structure: state = NB_ST_FULL nghbCap = 0x0 nghbId idbNo remPort nflags...
Page 227: Table B-18 Interfaceshow Command Field Descriptions
Telnet Commands B-81 Table B-18 interfaceShow Command Field Descriptions Field Description The port number. idbP The neighbor (adjacent) Switch’s port nghbP The port number. It should be identical to the value specified in the ifNo command line. The cost of sending a frame over the ISL connected to this port. The cost value 1000 indicates a 1 Gbps link.
Page 228 B-82 StorageWorks Fibre Channel Storage Switch User's Guide Table B-18 interfaceShow Command Field Descriptions continued Field Description These fields are internal Fibre Channel Shortest Path First (FSPF) Debug fields information and is used by Customer Support for debug purposes only: &dbRetransList, &lsrRetransList, &lsrAckList, inactTIDt, helloTID, dbRtxTID, and lsrRtxTID.
Page 229 Telnet Commands B-83 Table B-18 interfaceShow Command Field Descriptions continued Field Description The number of attempted transmissions of Link State Updates to attLsuOut the neighbor Switch. nLsuOut is the number of Link State Updates actually transmitted to nLsuOut the neighbor Switch. The number of attempted transmissions of Link State attLsaOut Acknowledges to the neighbor Switch.
Page 230: Lsdbshow
B-84 StorageWorks Fibre Channel Storage Switch User's Guide LSDbShow Figure B-56 shows the LSDbShow command which displays domain Link State Database entries. The fields are described in Table B-19. The database record for any Fabric Switch can be displayed from any Switch. It also gives the same information regardless of Switch used to run it (unless there is a database update in progress, which occurs every 10 minutes in a stable network).
Page 231: Figure B-55. Lsdbshow Command Example
Telnet Commands B-85 admin> LSDbShow Domain=0, Link State Database Entry pointer=0x10393140 lsrP = 0x1036b650 earlyAccLSRs ignoredLSRs lastIgnored = Never installTime = 0x96a64 (617060) lseFlags = 0xa uOutIfs = 0x2000 uPathCost = 1000 uHopsFromRoot mOutIfs = 0x0 parent = 0x0 mPathCost mHopsFromRoot Link State Record: Link State Record pointer = 0x1036b650...
Page 232: Table B-19 Lsdbshow Command Field Descriptions
B-86 StorageWorks Fibre Channel Storage Switch User's Guide Table B-19 LSDbShow Command Field Descriptions Field Description Indicates that domain 1 is the local Switch’s domain domain ID. Link State Database Entry pointer. lsrP The number of LSRs (Link State Records) accepted earlyAccLSRs within the 5 sec window.
Page 233 Telnet Commands B-87 Table B-19 LSDbShow Command Field Descriptions continued Field Description The record’s Link State ID, equal to the Switch’s lsId domain ID as described by the record. Switch ID of the Switch that issued this LSR. advertiser Currently set to lsId. The incarnation number.
Page 234: Mcastshow
B-88 StorageWorks Fibre Channel Storage Switch User's Guide mcastShow Figure B-57 shows the mcastShow command without parameters it shows multicast tree information for all the multicast groups. Figure B-58 shows mcastShow with a parameter (group number). It shows information about one multicast group only.
Page 235: Table B-20 Mcastshow Bitmap Field Descriptions
Telnet Commands B-89 admin> mcastShow 1 Group Member Ports Member ISL Ports Static ISL Ports ----------------------------------------------------------- 0x00000011 0x00000011 0x00000000 value = 1 = 0x1 Figure B-57. mcastShow Command Example 2 Table B-20 mcastShow Bitmap Field Descriptions Bitmap Field Description Group The multicast group.
Page 236: Nbrstateshow
B-90 StorageWorks Fibre Channel Storage Switch User's Guide nbrStateShow Figure B-59 and Figure B-60 shows the nbrStateShow command which displays neighbor's summary information. This information can also be retrieved using interfaceShow. The command provides essential information to determine the Fabric topology in a concise way. By using this command, you can discover the domain ID of all Switches directly connected to the local Switch, and the port number on the local and remote Switch.
Page 237: Figure B-59. Nbrstateshow Command Example
Telnet Commands B-91 The command syntax is nbrStateShow <port number> to list the neighbor on the specified port. admin> nbrStateShow 1 Local Domain ID: 3 Local Port Domain Remote Port State ------------------------------------------------------- NB_ST_FULL value = 1 = 0x1 Figure B-59. nbrStateShow Command Example Table B-21 nbrStateShow Command Field Descriptions Field...
Page 238: Topologyshow
B-92 StorageWorks Fibre Channel Storage Switch User's Guide topologyShow Figure 5-61 and Figure 5-62 shows the topologyShow command which displays all paths to a domain including: Output port(s) used to route frames to the domain The routing cost to reach the domain The input ports routed through the output port The FSPF protocol supports equal cost multipaths, so there could be multiple 'parallel' paths between two Switches.
Page 239: Figure B-61. Topologyshow Command Example 2
Telnet Commands B-93 The command syntax is topologyShow <domain ID> to list the specified domain. admin> topologyShow 1 Local Domain ID: 1 Domain Metric Hops Out Port In Ports Flags Name ------------------------------------------------------------- 2000 0x00000050 "open148" 0x00000020 0x00000080 value = 1 = 0x1 Figure B-61.
Page 240: Table B-22 Topologyshow Command Field Descriptions
B-94 StorageWorks Fibre Channel Storage Switch User's Guide Table B-22 topologyShow Command Field Descriptions Field Description The destination domain Domain Metric The total cost to reach the destination domain, the sum of all links costs traversed by a frame to reach the destination domain.
Page 241: Urouteshow
Telnet Commands B-95 uRouteShow Figure B-63 shows the uRouteShow command which displays the port's unicast routing information which is the output port used to forward frames from a port to the domain. Only one output port is used to forward frames from one input port to a destination domain.
Page 242: Table B-23 Urouteshow Command Descriptions
B-96 StorageWorks Fibre Channel Storage Switch User's Guide Table B-23 uRouteShow Command Descriptions Field Description A bitmap field that indicates what ports are In Port routed through the out port to reach the destination domain. Domain The destination domain Out Port The out port(s) used to route frames to the domain.
Page 243: License Commands
Telnet Commands B-97 License Commands licenseHelp Figure B-64 shows the licenseHelp command which displays the license help commands. admin> licenseHelp licenseAdd Add a license key to this switch licenseRemove Remove a license key from this switch licenseShow Show current license key value = 1 = 0x1 Figure B-63.
Page 244: Licenseshow
B-98 StorageWorks Fibre Channel Storage Switch User's Guide licenseShow Figure B-66 shows the licenseShow command displays the optionally licensed products installed on the fibre channel Switch. The value returned will depend on the license keys installed, the name of each license will be displayed.
Page 245: Appendix C Agency Notices
Numbers For the purpose of regulatory compliance certifications and identification, your Fibre Channel Storage Switch (SWK FC STG Switch) is assigned a Compaq Series Number. The Compaq Series number for this product is: Series NA2101. The Fibre Channel Storage Switch Series Number can be found on the product label, along with the required approval markings and information.
Page 246: Class A Equipment
C-2 StorageWorks Fibre Channel Storage Switch User's Guide in both classes to bear a label indicating the interference potential of the device as well as additional operating instructions for the user. The rating label on the device shows which class (A or B) the equipment falls into.
Page 247: Modifications
