Motorola Netopia 3347-02 Datasheet

• Wireless gateway equipped
with 3D Reach ® Extreme
technology for increased
range and performance
• Multiple LAN options for
single-PC households and
home or small-office
networking
• Simple installation and set-up
• IPTV and Video-on-Demand
(VOD) support
• Robust security features
• Advanced Quality-of-Service
(QoS) features are designed
to help service providers
improve efficiency and
reduce costs
DATA SHEET
3347-02
Netopia ADSL2+ Four-Port Wireless Gateway
®
Full-featured, extended-range wireless gateway for broadband households
and small offices
The Motorola Netopia 3347-02 (North America) Four-
Port Wireless Gateway combines an ADSL2+
modem, four-port Ethernet router, and an enhanced
wireless design for home or small-business users to
connect anywhere in their home or business
environment. The 3347-02 features 3-D Reach
Extreme 802.11g/b Wi-Fi ®
following the same design philosophy used by
leading PC manufacturers. 3-D Reach Extreme uses
two radio antennas specifically tuned for both
vertical and horizontal range. 400 mW of power
provides superior wireless reach, coverage, and
reduced interference to minimize dropped
connections and dead zones.

(North America)

®
technology, developed
With this full-featured gateway, high-speed Internet
connectivity is only the beginning. Support for Wi-Fi
Multimedia (WMM) assures advanced QoS for
wireless delivery of voice-over-IP (VOIP), IPTV, and
streaming broadcast-quality video. With four 10/100
Ethernet ports, the 3347-02 can be used to set up a
home or small-office network to share a printer,
data, music, and video files. To prevent unauthorized
wireless access into the network, the 3347-02
supports the latest encryption, including WPA2,
WPA, and WEP .
The easy-to-install 3347-02 is just as easy to
manage. Supporting the DSL Forum's TR-069
specification, the 3347-02 can be managed and
updated remotely, without user interaction.
