AT&T
12/88
PagePac® 6 Voice Paging System
User and Installation Manual

Advertisement

Table of Contents
loading

Related Manuals for AT&T 146

Summary of Contents for AT&T 146

  • Page 1 AT&T 12/88 PagePac® 6 Voice Paging System User and Installation Manual...

  • Page 2: Ordering Information

    PagePac 6 is recommended for the following telephone systems (some installations may re- quire a separate adapter, see page 2). PAGEPAC® 6 COMPATIBILITY CHART AT&T TELEPHONE (STATION) TELEPHONE SYSTEM YES, Via Standard SPIRIT® SPIRIT® 308/316 page port 308/616 SPIRIT® Not offered by SPIRIT® 2448 2448 MERLIN®...
  • Page 3 INTRODUCTION TO THE AT&T PagePac® 6 VOICE PAGING SYSTEM AT&T PagePac 6 is a compact, powerful, voice-paging system that integrates single-zone pag- ing capability into your telephone system. PagPac 6 can be used with most AT&T telephone systems, from single-line residential systems to modern electronic key and PBX systems. Front PagePac®...

  • Page 4: Installation

    Speakers Trunk PagePac 6 Adapter *If using a C.O. Line Protector that provides both telephone and AC power connections, such as the Model 146, connect both the PagePac 6 modular cord and power cord to the protector. INSTALLATION Incoming Central Office...
  • Page 5 CONNECTING PAGEPAC 6 TO A PAGE PORT PagePac 6 Telephone System Page Jack Modular Line Cord To 120 VAC, 60 Hz Connections to a Page Jack (Circled numbers correspond to the steps in the installation procedure below.) Required Materials — PagePac 6 —...
  • Page 6 Two standard modular cords of sufficient length to make the connections shown in the figure above. *If using a C.O. Line Protector that provides both telephone and AC power connections, such as the Model 146, connect both the PagePac 6 modular cord and power cord to the protector.
  • Page 7 Port Saver 5 in. PagePac 6 Port Saver 6.5 in. Wall Mounting Arrangements for Port Saver & PagePac 6 Installation Procedure PagePac 6 and PagePac 6 Port Saver may be placed on a desk or shelf, or may be wall mounted (see illustrations above) using the keyhole slots in the bottom of the unit.
  • Page 8 CONNECTING PAGEPAC 6 USING A PAGEPAC TRUNK ADAPTER PagePac 6 Connections to a Line Jack Using the PagePac Trunk Adapter (Circled numbers correspond to the steps in the installation procedure.) Required Material PagePac 6 — — PagePac Trunk Adapter — Standard modular telephone cord of sufficient length to connect the Trunk Adapter to the telephone system line jack.
  • Page 9 Telephone System Incoming Line Jack Installation Procedure PagePac 6 can be placed on a desk or shelf, or wall-mounted using the keyhole slots in the bottom of the unit. After selecting a convenient location: 1. Connect the Trunk Adapter modular cord to the PagePac 6 PAGE jack. 2.
  • Page 10 CONNECTING SPEAKERS TO PAGEPAC 6 Both standard speakers (indoor cone-type) and horn speakers may be used with PagePac 6. For best performance, use only the type speaker recommended for your situation (see below), and do not exceed the number of speakers or speaker run length maximums shown below. PAGING AREA MOUNTING LOCATION SPEAKER TYPE AT&T ORDER NO.
  • Page 11 Third Run Speakers Second Run Speakers First Run Speakers 22050-910 (Optional) Output Cord Speaker connections to PagePac 6 Required Materials — PagePac loudspeakers recommended for use with PagePac 6 — 24 AWG speaker wire Standard installation tools—screwdriver, wire cutters/strippers, pliers, hammer, etc. —...
  • Page 12 CONNECTING A MUSIC SOURCE* TO PAGEPAC 6 MusicMate™ Y-Connector Output Cord (Supplied) DC Power Cord Connections Using MusicMate™ Music Source (FM Tuner, etc.) Music Source Connections to PagePac 6 Required Materials PagePac MusicMate™ or alternate source, such as FM tuner, tape deck, leased source, etc. —...
  • Page 13 Installation Procedure Connect MusicMate (Figure A), or alternate source (Figure B), to the PagePac 6 MUSIC IN terminals. When using MusicMate (Figure A), connect the MusicMate D.C. power cord to the PagePac 6 POWER jack. A phono-jack-to-screw-terminals adapter is provided with the MusicMate. Use it to connect the MusicMate output cord to the PagePac 6 MUSIC IN terminals.

  • Page 14: Operation

    Paging procedures differ slightly depending on the requirements of your telephone system and how it is connected to PagePac 6. If your system is connected using a PagePac 6 Port Saver, pay particular attention to the pertinent instruction section below. PAGING WHEN CONNECTED THROUGH A PAGE PORT OR A PAGEPAC TRUNK ADAPTER The exact procedure for paging on your particular telephone system is explained in the user’s...
  • Page 15 Placing a Call Lift the handset and listen for the distinctive dial tone. Dial 9 and listen for the regular dial tone. (Or, you may wait for the regular dial tone; this will take approximately 4 seconds.) Dial the number you want to call. NOTE: To dial emergency 911, dial 9 or wait for the regular dial tone, and then dial 911.

  • Page 16: Troubleshooting Procedures

    ADJUSTNG PAGE AND MUSIC VOLUME Volume controls on the rear of PagePac 6 allow you to adjust the volume of paging and background music independently. If your paging system fails to operate properly, follow the suggestions in the trouble analysis chart before calling for professional assistance.
  • Page 17 PROBLEM No sound from one or more speakers while others work. Paging and music do not work. Or, music works but paging does not. Trouble Analysis Table CORRECTIVE ACTION Check volume control on speaker. Check all connections to speaker. Replace bad speaker with good one. If speaker cannot be replaced immediately, wire around it to ensure service to the remaining speakers.
  • Page 18 Trouble Analysis Table (continued) PROBLEM Paging and music do not work. Or, music works but paging does not (continued). Paging and music are garbled. Paging works, but music does not. CORRECTIVE ACTION If Connected Using PagePac 6 Port Saver Disconnect the PagePac 6 Port Saver from the telephone line jack.
  • Page 19 If, for any reason, you need to know the pinouts for the modular jacks on the PagePac 6 or PagePac 6 Port Saver, pinout information is given below. Pin* Cord Lead† Not Used Not Used Access Control (C) Black Ring Green Yellow Access Control (C1)

  • Page 20: Warranty Information

    WARRANTY INFORMATION LIMITED WARRANTY AND LIMITATION OF LIABILITY AT&T warrants to you that the product will be free from defects in material and workmanship when title passes to you. If you notify AT&T that the product has failed to operate as warranted within one year of the date title passes to you, AT&T will, at its option, repair or replace the com- ponent or components of the product that failed to operate as warranted.
  • Page 21 FCC REGULATIONS PERTAINING TO THIS EQUIPMENT FCC (PART 15) Radio Frequency Interference The PagePac 6 generates and uses radio frequency energy and if not installed and used in strict accordance with the manufacturer’s instructions, may cause interference to radio and television reception.
  • Page 22 © Copyright 1988 AT&T All rights reserved Printed in U.S.A. 999-500-246 Issue 1, Dec. 1988...
