  • Page 1 SP360 4K Action Cam User Manual...

  • Page 2: Before You Start

    All trademarks mentioned in this manual are used for identification purposes only and are properties of their respective owners. This manual provides you with instructions on how to use your new KODAK PIXPRO Action Cam. Every effort has been made to ensure that the contents of this manual are accurate; however JK Imaging Ltd. reserves the right to make changes without notice.
  • Page 3 For Customers in the U.S.A. Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 4 For Customers in Europe This symbol [crossed-out wheel bin WEEE Annex IV] indicates separate collection of electrical waste and electronic equipment in the European countries. Please do not throw the equipment into domestic refuse. Please use the return and collection systems available in your country for proper, safe disposal of this product. “CE”...
  • Page 5 EN 301 489-17 V2.2.1:2012 Electromagnetic compatibility and Radio spectrum Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment; Part 17: Specific conditions for Broadband Data Transmission Systems Hereby, [Sintai Optical (Shenzhen) Co., Ltd], declares that these [Action Cam and Remote] are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Packaging: Please follow local regulations for the recycling of packaging. Batteries: Please dispose of used batteries at designated collection centers.

  • Page 6: Safety Notes

    Safety Notes Product Notes: • Do not disassemble or attempt to repair the product by yourself. • Do handle the product properly. This product may be damaged if dropped, punctured or crushed. • Avoid directly touching the lens element, please use professional lens cleaning paper together with lens cleaning agents to wipe the lens and keep the lens clean. • Do not use corrosive, alcoholic or organic-solvent-containing cleaners to wipe this product. • Do not use or store this product in high temperature environment. • Do not expose the lens to strong light sources (e.g. daylight, etc.) for extended periods. • Do not use or store the product in a strong magnetic field environment. • If the product is quickly transferred from a low temperature environment to a high temperature environment, water condensation may occur in the product due to physical changes. In this case, it is recommended to wait until the product returns to room temperature before you turn it on. • If a photo or video cannot be played back due to improper operation by the user, the Company shall assume no liability or responsibility for compensation.
  • Page 7 memory card into the card slot. • Before using a brand new memory card, please format the memory card first. • A photo or video taken with the product will be stored in the folder that is automatically generated on the memory card. Do not store photos or videos that were not taken using the product in these folders in case the files cannot be normally recognized in playback. • Directly editing the data on the memory card is not recommended. Copy the data to your computer disk before editing is recommended. • Please turn the product off before removing the memory card. Otherwise, the memory card could be damaged. • When the product is stored for a long period, please backup the data on the memory card and remove the memory card. Other Notes: • Do not disconnect the power or turn the product off during firmware updating process. Doing so may cause incorrect data to be written and the product may not power on later. • When using your product on an airplane, observe the relevant rules specified by the airline. • Due to the limitations of manufacturing technology, the LCD may have a few dead or bright pixels. These pixels do not affect the quality of the photos or videos. • If the LCD screen is damaged, please pay close attention to the liquid crystal in the screen. If any of the following situations arise, kindly take the recommended actions immediately as indicated below: 1. If liquid crystal comes in contact with your skin, please wipe your skin with a dry cloth, wash with soap thoroughly, and rinse with plenty of clean water. 2. I f liquid crystal gets into your eye, flush your eye with plenty of clean water immediately for at least 15 minutes. Please also seek for medical assistance.

  • Page 8: Table Of Contents

    Before You Start ............................1 Safety Notes ............................5 Contents ..............................7 Getting Ready............................9 Accessories Included ..............................9 KODAK PIXPRO SP360 4K View ...........................10 Mounting / Removing Lens Ring and Lens Cover ....................11 Installing Battery ..............................12 Installing Memory Card ............................13 Charging the Battery ...............................14 Configuration and Operation .........................16...
  • Page 9 Burst mode ..................................20 Introducing the Menu ............................21 Every Shooting Mode Settings ) ................ 22 General Settings ................................29 ..............................31 Remote Pair Setting Remote Control ..............................32 Using Interfacing............................38 Micro USB interface ..............................38 Charging ......................................38 Using an external power supply ..............................38 Data transmission ..................................

  • Page 10: Getting Ready

    Getting Ready Accessories Included Your product box should contain the product you purchased along with the following accessories. If anything is missing or appears to be damaged, please contact your retailer. (The AC Adapter style will vary according to the power requirement from different countries or regions. Below picture is for reference only) Rechargeable Li-ion battery Battery charger AC adapter...

  • Page 11: Kodak Pixpro Sp360 4K View

    KODAK PIXPRO SP360 4K View Lens Video recording button / Shooting button / OK button Microphone Status indicator Wi-Fi button Wi-Fi indicator NFC mark Menu button / Direction button (lower) Power button / Mode button / Direction button (upper) Battery cover...

  • Page 12: Mounting / Removing Lens Ring And Lens Cover

    Mounting / Removing Lens Ring and Lens Cover The processes of mounting/removing lens ring and lens cover are the same, with lens cover as an example as below: Removing lens cover: Mounting lens cover Turn the lens cover according to the illustrated direction until it separates from the Turn and firmly tighten the lens cover according to the illustrated direction.

  • Page 13: Installing Battery

    Installing Battery 1. Open the battery cover 2. Insert the battery Push the battery cover lock along the direction of arrow ① , push the battery cover Insert the battery into the battery compartment along the direction of arrow ④ (note along the direction of arrow ②...

  • Page 14: Installing Memory Card

    Installing Memory Card Open the side cover, then insert the memory card into the card slot (note the direction of the memory card gap), push the bottom end of the memory card with a fingertip into the slot completely, and then close the side cover. A memory card (microSD / microSDHC / microSDXC) is optional and is not included in the product package. It needs to be purchased separately. Please use an original memory card, which is Class 10 or higher and has a capacity of 8GB to 128GB.

  • Page 15: Charging The Battery

    Charging the Battery Please use the battery charger or AC adapter to charge the battery in an ambient temperature ranging from 10 ˚C to 35 ˚C. Charging the battery with a battery charger: 1. Place the battery into the battery charger according to the direction illustrated. Use the Micro USB cable to connect the battery charger and the AC adapter, and then plug the AC adapter into an electrical outlet.
  • Page 16 Charging the camera with a computer: 1. Place the battery into the camera. 2. Use the Micro USB cable to connect the camera (off) to a computer (on). 3. The indicator light will become orange while it is charging. The indicator will go out once charging is finished. The camera cannot be recharged when power is on.

  • Page 17: Configuration And Operation

    Configuration and Operation Main Interface Introduction The Main Interface 1. Mode Movie mode Snap Shot Photo mode Loop recording mode Time-lapse movie mode High-speed movie mode Burst mode Memory card 3. Movie size: Photo size: 4. Battery status 5. Motion detection (on) 6.

  • Page 18: Power On / Off

    Power On / Off Power on: When the power is off, press and hold the button for more than one second to turn on the product. Power off: When the power is on, press and hold the button for more than one second to turn off the product. If the product cannot be powered off normally, you can remove the battery from the camera to force it to power off.

  • Page 19: Modes Introduction

    Modes Introduction In the main interface, press the button to enter the mode selection interface. Press the button to select any one mode; press the button to the main interface of the current mode. 6 modes are available: Movie mode , Snap shot photo mode , Loop recording mode , Time-lapse movie mode...

  • Page 20: Snap Shot Photo Mode

    Snap Shot Photo mode Enables photo shooting. It is suitable for recording in most conditions. Operation method: Press the button for photo. Loop recording mode Loop recording refers to recording independent video segments in the unit of 2 minutes. The camera is only capable of saving a video of 60 minutes once maximally. If the recording at a time exceeds 60 minutes, the new video will automatically cover the earliest record in the folder in the unit of 2 minutes.

  • Page 21: High-Speed Movie Mode

    High-speed movie mode The product shoots ultra-high speed movies, and plays back with normal 30fps speed. Operation method: Press the button to start recording. Press the button again to stop recording. Sound cannot be recorded in this mode. Burst mode Enables ten photos to be captured continuously before auto pause.

  • Page 22: Introducing The Menu

    Introducing the Menu 1. In the main interface, press the button to enter the sub-menu interface. There are three items: Every Shooting Mode Settings ( ), General Settings, Remote Pair Settings. Press the button to select the item, and press the button to enter the corresponding advanced setting interface.

  • Page 23: Every Shooting Mode Settings

    Every Shooting Mode Settings The advanced Setting in every shooting mode Loop Recording Time-lapse movie High-speed Movie Snap Shot Photo Movie Settings Burst Settings Settings Settings Settings Settings The sub-menu interface The advanced Setting interface...
  • Page 24 Take the recording setting menu as an example; the setting operating manners of other shooting modes are the same as that of the recording setting menu. Sub-menu Advanced Setting Selectable items...
  • Page 25 Display mode Set image storage form. There are 2 options: • Global 235° 360° • Front...
  • Page 26 Movie size Set video resolution. There are 15 options : • 2880×2880 (30fps)(1:1) • 3840×2160 (30fps)(16:9) • 720×720 (120fps)(1:1) • 2048×2048 (30fps)(1:1) • 1920×1080 (60fps)(16:9) • 1280×720 (120fps)(16:9) • 1440×1440 (60fps)(1:1) • 1920×1080 (30fps)(16:9) • 848×480 (240fps)(16:9) • 1440×1440 (30fps)(1:1) •...
  • Page 27 Field of view Field of view means the image receiving angle for the product. There are 3 options: • Ultra Wide • Middle • Narrow Ultra Wide Middle Narrow Ultra Wide Ultra Wide Middle FWVGA Narrow Notes: 1. This function can be set only under front mode. 2.
  • Page 28 Time-lapse movie Set interval recording time. There are 6 options: 1 second • 2 seconds • 5 seconds • 10 seconds • 30 seconds • 60 seconds • Motion detection Motion detection means that if the product detects moving objects entering into the view, it will automatically start recording. During the recording process, if there is no moving object detected for 10 continuous seconds, the recording will pause automatically.
  • Page 29 Night view When shooting at night or in the dark, enabling this function may enhance image brightness. There are 2 options: • Enable • Note while using this function: When in a bright environment, the image may be too bright. Frame drop may occur. It is recommended to use a tripod to avoid blurred images.

  • Page 30: General Settings

    General Settings Sub-menu Advanced setting Selectable items...
  • Page 31 Volume Set the volume of the product. There are 2 options: • Enable • Power off When this function is enabled, if there are no actions taken within a set time frame (except while recording or connected to Wi-Fi), the product will automatically shut down.

  • Page 32: Remote Pair Setting

    Format Format can clear all data stored in the memory card. There are 2 options: • Confirm • Cancel If select , press the button to start formatting, and return to the advanced Setting interface after finishing. Reset settings Reset settings can recover all product settings to the factory defaults (except for date and time). There are 2 options: •...

  • Page 33: Remote Control

    Remote Control A remote control can be used for remotely controlling the camera at a long distance. The remote control is optional. If you need one, contact the local retailer to buy or access http://kodakpixpro.com for details of customer service. You can wear the remote control on your wrist to perform long-distance control on the camera by operating the remote controller.

  • Page 34: How To Use

    Installing the Battery: Open the battery cover with a coin in counterclockwise direction, insert the battery in place (with the anode facing upward), and then turning in the opposite direction to close the cover. Positive CR2450 Negative How to Use: 1.
  • Page 35 Press and hold the buttons on the remote control simultaneously until pairing is successful. While pairing, the remote control shall be closer to the camera. 1.2. Method of one remote control for multiple cameras: In the main interface of camera, press the button, select , press the button, select “Multi Control", press the...
  • Page 36 Press and hold the buttons on the remote control at the same time until pairing is successful. While pairing, the remote control shall be closer to the camera. Repeat the above setup for each camera. Each camera must be set to the same channel, one remote control can control 5 cameras simultaneously at most. 2.
  • Page 37 When appears on the interface, indicates that the camera is out of control of the remote control at the moment. indicates that the remote control is under the control of one camera at the moment. indicates that one remote control controls multiple cameras at this time. It indicates that the camera has been set at this channel.
  • Page 38 Precautions: : 1. If the Wi-Fi (NFC), HDMI connection or computer connection of the camera are already enabled, the remote control function is unavailable. 2. When only one camera needs to be controlled, the “Multi Control” is not recommended. When using "Multi Control", the effective working distance of the remote control may be shortened.

  • Page 39: Using Interfacing

    Using Interfacing Micro USB interface Charging Using an external power supply In case of low battery power, or when a long-term power supply is needed, an external power supply (AC adapter, vehicle power supply, portable power supply or other power unit) can be used instead of a battery. At this time, the setting of functions, photography, and other operations can be performed. When powered on, use the Micro USB cable to connect the camera to an external power supply.
  • Page 40 The folder structure of a microSD card on which this unit has performed recording is as follows. SP360 4K Example folder structure of a microSD card: ● Folder numbers range from 100 to 999. Four or eight alphabetic characters after a three-digit number indicate the file type. DCIM A. Still pictures in JPEG format (Each folder stores a maximum of 999 still pictures) B~M.

  • Page 41: Webcam

    4. Open the video software (Skype) in the computer, and select “Options…” from “Tools”. Click on “Video settings” and select “PIXPRO SP360 4K UVC” as the video input device. By clicking on “Webcam settings”, you may change various settings.
  • Page 42 5. Change the desired settings and click on “OK” to exit. If you choose a resolution of 1280×720, the image will be displayed at an aspect ratio of 16:9. In the image position adjustment menu list, O stands for available, and X for unavailable. 16:9 ○...

  • Page 43: Micro Hdmi Interface

    Micro HDMI interface The television (on) up to the HDMI standard and the camera (on) are connected by use of a Micro HDMI wire (bought independently). After the connection succeeds, the documents in the memory cards of the camera are displayed on the television, while is displayed on the camera.
  • Page 44 The playback function can be realized by use of the television remote control: 1. Press the left and right keys to switch the documents. 2. Press to switch the video document and the photo 3. Press to hide or display the screen information. 4.

  • Page 45: Wi-Fi Mode

    For Android devices, search and download the App "PIXPRO SP360 4K" in Google play, and install it by following the instructions on the interface. For iOS devices, search and download the App "PIXPRO SP360 4K" in App Store, and install it by following the instructions on the interface.
  • Page 46 Connect camera to smart device (or PC) with Wi-Fi. Operation method: 1. Camera: 2. Smart Device or PC: Check SSID (Service Set Identifier) (PIXPRO-SP360-4K_XXXX) and password Enable Wi-Fi mode, it will automatically search the nearby Wi-Fi hotspots. Select (initial password: 12345678) indicated on the label in the battery compartment of the one with the same SSID (PIXPRO-SP360-4K_XXXX) and input the password.
  • Page 47 If the Wi-Fi connection is cut off while recording, the camera will continue to record and enter the connectionless recording interface. When displays in the interface, press the button, and press the button to select , and then press the button to exit the Wi-Fi connection.
  • Page 48 Connect camera to smart device with NFC 1. Enable NFC mode on your smart device. 2. Use your smart device to lightly touch the NFC mark on the camera. If the smart device has a prompt tone or vibration, it means the connection is successful. 3.

  • Page 49: Appendices

    Appendices Specifications Design and specifications are subject to change without notice. Type 1/2.3" BIS CMOS Image Sensor Effective Pixels 12.40 Megapixels Total Pixels 12.76 Megapixels Focal Length 0.85mm Equivalent to 35mm film 8.2mm F Number F2.8 Lens Lens Construction 7 groups 9 elements Optical Zoom Fix Focus Field of View Max. 235 Degree (without lens cover) Focusing Range 50cm~∞...
  • Page 50 Photo Exif 2.3 (JPEG) File Format Movie MP4 [Image: H.264; Audio: AAC(Stereo)] Modes Movie, Snap Shot Photo, Loop Recording, Time-lapse movie, Burst, High-speed Movie Splash proof Equivalent to JIS/IEC IPX5 (Body) Shockproof Up to 2m (with lens cover) Dustproof Equivalent to JIS/IEC (IP6X) Freeze-proofing -10°C 1.0 inch TN LCD...
  • Page 51 Power Rechargeable Li-ion Battery LB-080, 3.6V 1250mAh, In-Camera Charging Shooting Capability (Battery Approx. 160 shots (Based on CIPA Standards) (Wi-Fi on) Performance) Approx. 55 minutes for Video (@3840×2160/30fps) (Wi-Fi on) Operation Environment Temperature: -10 ~ 40°C, Humidity: 0 ~ 90% Dimensions (W×H×D) Approx.48.0×50.0×52.5 mm (Without lens cover) (Based on CIPA Standards) Approx.

  • Page 52: Prompts And Warning Messages

    Prompts and Warning Messages Message Description Processing mode T here are too many files, which may cause a delay to power on. A fter copying the files to the computer, When pressing the button for shooting, the memory card cannot be accessed because choose to delete or format. there are too many folders. No memory card is detected in the camera. Insert the memory card.
  • Page 53 Message Description Processing mode The camera is set as "Mass Storage", connecting to the computer USB. User should do nothing. The camera is set as "Web Cam", connecting to the computer USB. User should do nothing. Connecting to the HDMI device. User should do nothing.

  • Page 54: Trouble Shooting

    Trouble Shooting Problem Possible causes Solution Charge the battery. The battery has been depleted. Product does not turn on Please follow the charging instructions in the manual The battery is installed incorrectly. to install the battery. Blurred images There is dirt on the lens or the lens cover. Clean with a clean, lint-free dry cloth.

  • Page 55: Special Accessories

    Special Accessories There are different options of SP360 4K accessories available. Accessory bundles vary per retailer. To purchase additional accessories separately, please contact your local retailer customer service support, or visit http://kodakpixpro.com for more customer service details. Taking the status of using the lens ring as an example in the introduction of the section, you can select to use the lens cover according to the actual use conditions (for instance, if stronger waterproof and dustproof properties are required).
  • Page 56 Standard Housing: For use with other accessories when waterproofing is not required Installation method: 1. The standard housing is pulled open from the bottom and then sleeves the 2. Install the holder on the accessories, and use the setscrew to tighten. camera.
  • Page 57 Waterproof Housing: For use with other accessories underwater, in rain, on the seashore, or in other circumstances where waterproofing is required Installation method: 2. Press the lock downward until it locks tightly. Install the waterproof housing on 1. Remove the camera's lens cover, place the camera and anti-fog inserts into the waterproof housing.
  • Page 58 Flat Adhesive Mount: For tacking onto a skateboard or other flat Curved Adhesive Mount: For tacking onto a helmet or other curved objects objects Installation method: There are two types of adhesive mounts: flat and curved. You may select based on the shape of the object to be used. Both types can be assembled in the same way: 1. Assemble the standard housing (or the waterproof housing) ( 55/56).
  • Page 59 Bar Mount: For mounting on bicycle handlebars, sailing masts, and other tube-like objects Installation method: 2. Assemble the standard housing (or the waterproof housing) ( 55/56). 1. Set the bar clamp to the handlebar and rotate the screws to tighten. 3.
  • Page 60 Suction Cup Mount: For attachment to automotive windshields (or smooth surfaces) Installation method: 3. Clean the suction mount and the windshield before attaching the suction cup to 1. Assemble the standard housing (or the waterproof housing) ( 55/56). the windshield. Press down the handle to attach it to the windshield. 2.
  • Page 61 Vented Helmet Strap Mount-A: For mounting on hollow objects like bicycle helmets Installation method: 2. Spread out the band before threading both ends into the helmet. Thread both 1. Align the locator pole on the mount to the locator hole on the camera, and align ends of the band into the buckle, and then press down on the buckle clamp.
  • Page 62 Vented Helmet Strap Mount-B: For mounting on hollow objects like bicycle helmets Installation method: 1. Align the mount’s locator hole with the camera's locator hole and align the screw 2. Spread out the band before threading both ends into the helmet. Thread both on the mount with the camera's tripod socket. Turn the thumbscrew to tighten. ends of the band into the buckle, and then press down on the buckle clamp. Band Buckle Buckle clamp...
  • Page 63 Head Strap Mount: For wearing on one’s head Installation method: 1. Assemble the standard housing (or the waterproof housing) ( 55/56). 2. Insert the base of the standard housing (or the waterproof housing) to the mount before using the setscrew to tighten. 3.
  • Page 64 Surfboard Adhesive Mount: To be tacked onto watersports equipment like surf boards Plane Support (Large) Plane Support (Small) Installation method: 1. Assemble the waterproof housing ( 56). 2. Assemble the waterproof housing and plane support (large) in accordance with the direction illustrated in the picture, and tighten the setscrew. 3.
  • Page 65 Quick Clip: suitable to be clipped on a belt or harness Installation method: 1. Align the locator pole on the quick cip to the locator hole on the camera, and align the screw of the quick clip to the camera tripod-mounting hole, and screw it in to tighten.
  • Page 66 L-type Bracket Adhesive Mount : suitable for sticking on the curved surfaces such as non-porous helmets (with lens upward) Installation method: 1. Align the screws on the fixed seat with the mounting holes of the camera tripod, and tighten them. 2. Stick the double-sided adhesive at the bottom of the fixed seat to the objects to be used.
  • Page 67 L-type Bracket Mount : it is used in conjunction with L-type Helmet Adhesive Mount (with lens forward) Installation method: 1. Align the screws on the mount with the mounting hole of the camera tripod, and rotate the screws for fixation using a tool like coins. 2. Assembled into L-type helmet adhesive mount as shown in figure, and tighten the screw. 3. Stick the double-sided adhesive at the bottom of the fixed seat to the objects to be used.
  • Page 68 Selfie stick: It needs to be used together with other accessories Installation method: 1. Assemble the standard housing (or the waterproof housing) ( 55/56). 2. Assemble the standard housing (or the waterproof housing) and selfie stick 3. Twist the selfie stick in accordance with the direction indicated in the picture, in accordance with the direction indicated in the picture, then tighten the pre- then draw out, twist reversely and fix the camera.
  • Page 69 Dual Camera Base Mount-A and Remote Control Mount: used together with selfie stick for taking selfies or 360° shooting To synchronise the images obtained with the dual camera base mount, it is necessary to disable the EIS function of the camera before photographing. Otherwise, beautiful images cannot be correctly synchronised.
  • Page 70 2. Install one remote control mount on one side of the handle, put the remote control, which has been matched with SP360 4K camera, on the mount. 3. Tie the rope at the tail end of selfie camera, wrap the rope around your wrist. Draw out the selfie stick to adjust the length.
  • Page 71 Licensed Product The Kodak trademark and trade dress are used under license from Kodak. © 2015 JK Imaging Ltd. All Rights Reserved. JK Imaging Ltd., 17239 So. Main Street, Gardena, CA 90248 USA JK Imaging Europe, 71 Clarendon Road, Watford, WD17 1DS, UK http:/ /kodakpixpro.com...
