Bosch BGS5 Operating Instructions Manual

Hide thumbs Also See for BGS5:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual , Operating Instructions Manual
BGS5
en
Operating instructions
de
Gebrauchsanweisung

Advertisement

Table of Contents
loading

Related Manuals for Bosch BGS5

Summary of Contents for Bosch BGS5

  • Page 1 BGS5 Operating instructions Gebrauchsanweisung...

  • Page 2: Table Of Contents

    Table of content Safety information ........4 Intended use ........4 Safety information .
  • Page 3 Table of content Inserting the filter unit and the dust container ... .21 Filter care ........22 Cleaning the plate filter .

  • Page 4: Safety Information

    Safety information Please keep this instruction manual. When passing the vacuum cleaner on to a third party, please also pass on this instruction manual. Intended use This vacuum cleaner is intended for domestic use and not for com- mercial use. Only use this vacuum cleaner in accordance with the instructions in this instruction manual.

  • Page 5: Safety Information

    Safety information Safety information This vacuum cleaner complies with the recognised rules of techno- logy and the relevant safety regulations. The appliance may be used by children over the age of 8 years and by persons with reduced physical, sensory or mental capacity or by persons with a lack of experience or knowledge if they are supervised or have been instructed on the safe use of the appliance and the have understood the potential dangers of using...
  • Page 6 Safety information If using the appliance for longer than 30 minutes, pull out the power cord completely. When disconnecting the appliance from the mains, pull on the plug itself to remove it; do not pull on the power cord. Do not pull the power cord over sharp edges or allow it to be- come trapped.
  • Page 7 Safety information ! Please note The mains socket must be protected by at least a 16 amp cir- cuit breaker. If a circuit breaker is tripped when you switch on the vacuum cleaner, this may be because other electrical appliances which have a high current draw are connected to the same power cir- cuit.

  • Page 8: Your Vacuum Cleaner

    Your vacuum cleaner 10 11 20 21...
  • Page 9 Your vacuum cleaner 1 Adjustable floor tool with 13 Crevice nozzle accessory connection 14 "Clean" filter cleaning button 2 Telescopic tube with sliding switch and accessory 15 “Sensor Control” indicator connection 16 On/Off button with 3 Accessories holder electronic suction 4 Flexible hose regulator 5 Brush ring (to fit on the...

  • Page 10: Replacement Parts And Special Accessories

    Replacement parts and special accessories ® A TURBO-UNIVERSAL tool for uphol- stery BBZ42TB All-in-one brushing and vacuuming of upholstered furniture, mattresses, car seats, etc. Especially suitable for picking up pet hair. The brush roller is driven by the suction air flow through the vacuum cleaner.

  • Page 11: Initial Use

    Initial use Connecting the flexible hose Figure ● Push the flexible tube adapter into the air intake opening on the appliance and lock it in place. You will hear an audible Click 'click'. ● To remove the flexible hose, press the two catches together and pull out the hose.

  • Page 12: Inserting The Telescopic Tube Into The Floor Tool

    Initial use Inserting the telescopic tube into the floor tool Figure ● Push the telescopic tube into the connecting piece of the floor tool until it locks in place. To release the connec- tion, press on the locking collar and pull out the telescopic tube.

  • Page 13: Connecting The Appliance

    Initial use Connecting the appliance Figure Holding the power cord by the plug, pull ● out to the required length and insert the plug into the mains socket. Switch on /off Figure To switch the vacuum cleaner on or off, ●...

  • Page 15: Vacuuming

    Vacuuming Vacuuming with accessories Attach the nozzles to the suction pipe or hand grip as required: Figure ● Crevice nozzle for vacuuming crevi- ces and corners, etc. ● Upholstery nozzle for vacuuming upholstered furniture, curtains, etc. ● Upholstery nozzle with fixed brush ring for vacuuming window frames, cupboards, profiles, etc.

  • Page 16: Parking Aid

    Vacuuming Parking aid Figure You can use the parking aid on the side of the vacuum cleaner if you wish to stop vacuuming for a short time. ● After switching off the appliance, slide the hook on the floor tool into the par- king aid.

  • Page 17: Sliding The Telescopic Tube

    When your work is finished Sliding the telescopic tube Figure ● Unlock the telescopic tube by moving the sliding switch in the direction of the arrow and slide one tube into the other.

  • Page 18: Emptying The Dust Container

    When your work is finished Emptying the dust container Figure In order to achieve good vacuuming results, the dust container should be emptied after every use or, at the latest, when dust or dirt has visibly collected on the fluff filter or when dust at one point in the container has reached the height of the marking.

  • Page 19: Removing The Dust Container

    When your work is finished Removing the dust container Figure ● Open the appliance lid by pulling the locking tab. ● Use the handle to remove the dust container from the appliance.

  • Page 20: Taking Out The Filter Unit

    When your work is finished Taking out the filter unit Figure ● Release the filter unit of the dust con- tainer by pressing the release button. ● Take the filter unit out of the dust container and empty the dust contai- ner.

  • Page 21: Inserting The Filter Unit And The Dust Container

    When your work is finished Inserting the filter unit and the dust container Figure ● Insert the filter unit into the dust con- tainer, making sure it is correctly sea- ted. The arrow on the filter cover must point in the direction of the locking tab.

  • Page 22: Filter Care

    Filter care Cleaning the plate filter This function constantly monitors whether your vacuum cleaner is rea- ching its optimum power level. The indicator light lets you know when you need to clean the plate filter, so that the vacuum cleaner can reach its opti- mum power level once more.

  • Page 23: Activating The „Selfclean"-Function

    Filter care...

  • Page 24: Washing Off The Plate Filter

    Filter care Washing off the plate filter Figure If the plate filter is particularly dirty, the dirt can also be washed off. ● Turn the bottom part of the filter unit anticlockwise as far as it will go. Take the plate filter out of the filter unit.

  • Page 25: Cleaning The Fluff Filter

    Filter care Cleaning the fluff filter The fluff filter should be cleaned at regular intervals in order to ensure optimum operation of the vacuum cleaner. Figure ● Open the appliance lid and remove the dust container from the applian- Figure ●...

  • Page 26: Replacing The Hepa-Filter

    Filter care Replacing the HEPA-filter You can order a new filter from our after-sales service using the following replacement part number: 573928 Figure ● Open the appliance lid and re- move dust container. Figure ● Use the locking tab to open the side flap.
  • Page 27 Filter care ● Reinsert the filter unit into the appli- ance and ensure that it audibly clicks into place. Click ● Close the side flap until you hear the locking tab click into place again. Click ● Insert the dust container into the appliance and close the appliance lid.

  • Page 28: Cleaning Instructions

    Cleaning instructions Always switch off the vacuum cleaner and disconnect the power cord from the mains before cleaning the vacuum cleaner. The vacuum cleaner and plastic accessories can be cleaned with an ordinary plastic cleaner. Caution: do not use a scourer, glass-cleaning agent or multipurpose cleaning product.

  • Page 29: Disposal

    Disposal "This appliance is labelled in accordance with European Directive 2012/19/EU con- cerning used electrical and electronic appliances (waste electrical and electro- nic equipment - WEEE). The guideline determines the framework for the return and recycling of used appliances as appli- cable throughout the EU."...

  • Page 30: Costumer Service

    Milton Keynes MK12 5PT To arrange an engineer visit, to order spare parts and accessories or for product advice please visit: www.bosch-home.co.uk or call Tel.: 0844 892 8979* *Calls from a BT landline will be charged at up to 3 pence per minute. A call...

  • Page 31: Conditions Of Guarantee

    Conditions of guarantee For this appliance the guarantee conditions as set out by our representatives in the country of sale apply. Details regarding same may be obtained from the dealer from whom the appliance was purchased. For claims under guarantee the sales receipt must be produced.
  • Page 32 Robert Bosch Hausgeräte GmbH Carl-Wery-Str. 34 81739 München Germany www.bosch-home.com 8001 001 858- 04/2014 9000 707 987 – 05/12...
