Page 1
My VErizon you’re now connected to Verizon 4G LTE. Lightning fast, Lightning strong. For more information, visit verizonwireless. com/4GLTE. rEGiSTEr at verizonwireless.com/ myverizon, to learn how to use your phone. Go to My Verizon ≠ Click on Support ≠ Click on Get Help with Your ≠...
Page 2
A User Guide is available on demand—simply download at support.vzw.com/phones or call 1-877-268-7589 to order a copy. NOTES: Devices and software are constantly evolving— the screen images and icons you see here are for reference only.
BASiCS PhonE FEATUrES 1. EArpiEcE 2. prOxiMiTY SENSOr 3. FrONT cAMErA LENS 4. TApScrEEN 5. QuicK KEYS ( pHONE/ cONTAcTS/ MESSAGiNG/ AppS) 6. BAcK KEY 7. MicrOpHONE 8. HOME KEY 9. MENu KEY NOTES: All screen shots in this guide are simulated. Actual displays may vary. Tap the Apps Key then tap Guided Tours access the brief &...
PhonE FEATUrES (rEAr AnD SiDE ViEWS) 10. rEAr cAMErA 13. VOLuME KEYS LENS 14. pOWEr/ LOcK KEY 11. BAcK cOVEr 15. uSB/cHArGiNG 12. SpEAKEr pOrT 16. HEADSET JAcK...
FirST STEPS rEMOViNG THE BAcK cOVEr & BATTErY Turn the power off and use the fingertip cutout at the bottom of the phone to remove the back cover (as shown below). Then use the fingertip cutout at the bottom left corner of the battery compartment to lift the battery out.
TO rEMOVE THE MicrOSD cArD Turn the power off and remove the back cover. Locate the microSD card slot. Gently pull the microSD card out to remove it. iNSTALLiNG THE 4G SiM cArD* Turn the power off. remove the back cover and take the battery out.
*A Subscriber identity Module (SiM Card) is a “smartcard” that houses personal information, such as your mobile phone number, calling plan, and account information, such as contacts, text messages, and call history. The Verizon Wireless 4G LTE SiM Card is compatible with any Verizon Wireless 4G LTE certified device.
Page 8
1. Connect the USB Cable into the Wall/ USB Charger. When connecting, as shown below, the LG logo on the USB Cable should face toward you. Wall/USB USB Cable charger 2. Plug the USB Cable (as shown below) into the phone’s USB/Charging Port.
pOWEriNG YOur pHONE ON/OFF it’s important to fully charge the battery before turning on your phone. 1. To turn on the phone, press and hold the power/Lock Key for a couple of seconds until the screen lights up. 2. To turn off the phone, press and hold the power/Lock Key until the menu appears.
hoME SCrEEn The home screen is your starting point to access all the features on your phone. it displays application shortcuts, icons, widgets, and other features. Status Bar Shows device status information, including the time, signal strength, battery status, and notification icons.
Page 11
Quick Keys The Quick Keys are located at the bottom of the home screen and Applications screen. : opens the phone application which displays the dialpad so you can dial an unsaved number. it also provides additional tabs to access the Call logs, Contacts, and your Favorites.
Home screen canvas indicator The bar near the bottom of the screen indicate which home screen canvas you are viewing. SETTiNG up YOur DEVicE Follow the onscreen instructions to quickly set up your phone and email accounts. For more information visit verizonwireless. com/smartphones.
Page 13
Setting up your Google Account your Gmail, Google contacts, and Google calendar events will all be loaded to your phone automatically after setting up your Google Account. 1. At the setup screen, tap Existing or New. 2. Enter your username and password or any other necessary information (if creating an account).
Backup Assistant plus Backup Assistant and Media Manager are now Backup Assistant Plus. Protect your contacts and access your media when you need it on the go or at home. Go to verizonwireless.com/baplus. MAKE A cALL 1. From the home screen, tap the phone Key to open the dial pad.
MAKE A cALL FrOM OuTSiDE THE u.S. 1. From the home screen, tap the Menu Key , then tap Settings > call. 2. Tap Assisted dialing. 3. Tap reference country and select the country you are visiting from the list. 4. When you come back to the U.S., tap current country and select united States of America.
VoiCEMAiL SETTiNG up VOicEMAiL 1. From the home screen, tap the phone Key and dial *86 (*VM). Then tap the call . you can also tap and hold 2. Follow the setup tutorial. 3. Select a password. 4. record a voice signature and greeting. AccESSiNG YOur VOicEMAiL FrOM YOur pHONE 1. From the home screen, tap the phone Key...
AccESSiNG YOur VOicEMAiL FrOM ANY pHONE 1. Dial your wireless number. When you hear the greeting, press the to interrupt it. 2. Follow the prompts to enter your password and retrieve your messages. rESETTiNG YOur VOicEMAiL pASSWOrD To learn how to reset your password or discover other features, visit verizonwireless.com/myverizon.
3. Swipe the screen in any direction to unlock it. The last screen you were working on opens. To access a shortcut, swipe the icon in any direction. The screen will unlock and access the application. USinG SPEAKErPhonE 1. During a call, tap 2. The Speaker Key lights up to indicate that the speakerphone is on.
SELEcTiNG A riNGTONE 1. From the home screen, tap the Menu Key , then tap Settings and Sound. 2. on the riNGTONE & NOTiFicATiONS section, tap phone ringtone. 3. Tap the ringtone to select it and listen to it. 4. Tap OK to save your settings. SETTiNG riNGTONE TO ViBrATE 1. From the home screen, tap the Menu Key and tap Settings and Sound.
to turn the Bluetooth function 3. Tap on or off. The button will turn blue to indicate that Bluetooth is on. you will also see the text ON. pAiriNG YOur BLuETOOTH HEADSET WiTH YOur pHONE To pair your phone with a Bluetooth device you must pair your phone with another device before you can connect to it.
APPS AnD MorE Play it up with music, ringtones, wallpapers, apps and games. Keep up with Twitter and Facebook. For details and pricing, go to verizonwireless.com. Data charges may apply. inSTALLinG APPS More than hundreds of thousands of apps available to download from Google Play. 1. From the home screen, tap play Store SEnD yoUr MESSAGE 1. From the home screen, tap the...
5. Tap Send to send the message. VErizon TonES Search, preview, purchase and manage ringback tones and ringtones from your favorite artists all in one place. Go to verizonwireless.com/mediastore. VErizon ViDEo Watch full episodes of your favorite shows. Get hundreds of TV shows, live sports and events.
MoBiLE WEB Take the internet on the go. you can reach the latest news, get the weather and follow your stocks. From the home Screen, tap Browser VErizon SAFEGUArDS Family and Safety Apps & Services. Get the most robust parental controls. Go to verizonwirelss.com/safeguards.
Page 24
you should use caution when determining whether or not Location information should be made available to others and you should review any applicable third party policies before providing access. To limit potential unauthorized access to your Location information, Verizon Wireless offers various mechanisms and settings to manage access to location data.
GLoBAL TrAVEL ProGrAM Voice service available in more than 220 countries and data available in more than 205 countries — including more than 150 countries with 3G speed. This is the perfect short-term solution for the occasional or infrequent global traveler when traveling outside of the U.S.
CUSToMEr inForMATion yoUr WirELESS DEViCE AnD ThirD PArTy SErViCES Verizon Wireless is the mobile carrier associated with this wireless device, but many services and features offered through this wireless device are provided by or in conjunction with third parties. Verizon Wireless is not responsible for your use of this wireless device or any non-Verizon Wireless applications, services and products...
hEArinG AiD CoMPATiBiLiTy inForMATion This phone has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. however, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids.
Page 28
ACCESSoriES Give your phone the solutions it deserves by pairing it with accessories (sold separately) that compliment your tech-savvy lifestyle. Take your multimedia experience to the next level with the Media Charging Dock. Keep your phone and your apps within arm’s reach while on the go by placing it in the navigation Mount.
Page 29
MEDiA cHArGiNG DOcK Use the Media Charging Dock to keep your phone and extra battery charged while enjoying your favorite multimedia content on the phone’s large 4.5” display. or use Clock Mode, activated when your phone is docked, to keep you on schedule with the large, easy to read numbers.
Page 30
NAViGATiON MOuNT Whether you’re taking a road trip or a short drive, the navigation Mount will hold your phone in place while mounted to your car’s windshield or dashboard. once your phone is attached, Car Mode is enabled on your handset which gives you access to useful apps like navigation, Contacts, and Maps.
Page 31
pOucH Give your phone the protection it deserves – outfit it with a pouch accessory (sold separately). Choose from two different pouches to keep your phone looking stylish and safe from scratches whether it’s in a bag or in your pocket. Clock auto launches when the phone is inserted.
WirELESS cHArGiNG BATTErY cOVEr Attach the optional Wireless Charging Battery Cover to your handset for a cable- free charging experience. Center your phone on a compatible Qi enabled Wireless Charging Pad (sold separately) for optimal charging.
Page 33
WirELESS cHArGiNG pAD Enjoy cable-free charging when you use the Wireless Charging Pad, along with a compatible phone and Wireless Charging Cover (sold separately). The wireless charging pad can accommodate one phone at a time and includes Power and Charging Status LEDs. A placement guide and built-in magnet help you center your phone for optimal charging and audio feedback confirms your phone’s...
