Thank you for choosing Residential Air Conditioners,please read this owner's
manual carefully before operation and retain it for future reference.
Split Air Conditioner
Owner's Manual
Residential Air Conditioners

Advertisement

Table of Contents
loading

Summary of Contents for Gree GWC09KF-D3DNXXA

  • Page 1 Change for Life Split Air Conditioner Owner's Manual Residential Air Conditioners Thank you for choosing Residential Air Conditioners,please read this owner’s manual carefully before operation and retain it for future reference.
  • Page 2 MODEL: GWC09KF-D3DNXXA GWC12KF-D3DNXXA GWH09KF-D3DNXXA GWH12KF-D3DNXXA GWC09KF-A3DNXXA GWC12KF-A3DNXXA GWH09KF-A3DNXXA GWH12KF-A3DNXXA GWC09KF-D3DNXXC GWC12KF-D3DNXXC GWH09KF-D3DNXXC GWH12KF-D3DNXXC Note:“XX” stand for different front panels “A1~A9” or “B1~B9” or “C1~C9”...
  • Page 3: Table Of Contents

    CONTENTS Operation and maintenance ■ ............1 Notices for operation ■ ..............3 Notices for use ■ ........5 Names and functions of each part ■ ..........6 Operation of remote controller ■ ............11 Emergency operation ■ ..............12 Clean and care ■ .............14 Troubleshooting Installation service ■...
  • Page 4: Operation And Maintenance Notices For Operation

    Operation and maintenance-notices for operation ★ Earth: The ground ★ ★ For safety, be sure to turn off the cir- Select the most appropriate tem- be connected! perature. cuit beaker before performing any maintenance or cleaning or when the product is not used for an extended period of time Keep room cool- er than outside...
  • Page 5 Notices for operation ★ The airflow direction can be adjusted appro- ★ If the supply cord is damaged, it must be replaced priately. At operating, adjust the vertical airflow by the manufacturer or its service agent or a direction by adjusting the louvers of upward/do- similarly qualified person in order to avoid a wnward direction.
  • Page 6: Notices For Use

    Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function: If the unit is running in COOL mode and in low temperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0...
  • Page 7: Working Temperature Range

    Notices for use Working temperature range Indoor sideDB/WB( Outdoor sideDB/WB( Maximum cooling 32/23 43/26 Maximum heating 24/18 27/--- The operating temperature range (outdoor temperature) for cooling only unit is 18℃~ 43℃; for heat pump unit is -7℃~ 43℃. For Models: GWC09KF-D3DNXXC,GWC12KF-D3DNXXC,GWH09KF-D3DNXXC,GWH12KF-D3DNXXC The operating temperature range (outdoor temperature) for cooling only unit is 18℃~ 43℃;...
  • Page 8: Names And Functions Of Each Part

    Names and functions of each part Indoor unit Air in ⑵ ⑹ ⑸ ⑷ ⑶ Air out ⑴ SET TEMP Wireless ⑴ Remote control remote control Cool Front panel ⑵ Heat ⑶ Filter Receive window ON/OFF Guide louver ⑷ ⑸ Wall pipe ⑹...
  • Page 9: Operation Of Remote Controller

    Operation of remote controller ON/OFF Press it to start or stop operation. MODE Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT). : Press it to decrease temperature AUTO setting. HEALTH X-FAN HUMIDITY : Press it to increase temperature FILTER setting. TURBO HOUR ON/OFF Press it to set fan speed.
  • Page 10: Digital Display

    Operation of remote controller AUTO HEALTH X-FAN HUMIDITY FILTER TURBO HOUR ON/OFF Up & down swing icon: MODE icon: is displayed when pressing If MODE button is pressed, button. current operation mode icon up & down swing (AUTO), ( COOL), Press this button again to clear the (DRY), (FAN) or...
  • Page 11 Operation of remote controller Remote controller description ON/OFF : Press this button to turn on the unit. Press this button again to turn off the unit. MODE : Each time you press this button,a mode is selected in a sequence that goes from AUTO, , as the following: COOL, DRY, FAN,and HEAT COOL...
  • Page 12 Operation of remote controller HEALTH SAVE: Press HEALTH part of this button to turn on or off HEALTH function. Pressing SAVE part of this button, is displayed and the unit goes into SAVE operation mode. Press SAVE part of the button again to cancel SAVE function. During SAVE operation, the temperature and fan speed is not adjustable.
  • Page 13 Operation of remote controller SLEEP : Press this button to go into the SLEEP operation mode. Press it again to cancel this function. This function is available in COOL, HEAT (Only for models with heating function) or DRY mode to maintain the most comfortable temperature for you. LIGHT: Press LIGHT button to turn on the display's light and press this button again to turn off the display's light.
  • Page 14: Emergency Operation

    Emergency operation Displayer indicator light control of indoor unit It's a special selective button for the users ,who are not accustomed to the light at sleeping. Get the displayer indicator light on: When setting the light function,the mark will ● display on the remote controller screen by pressing this button.
  • Page 15: Clean And Care

    Clean and care Caution Disconnect the power supply before cleaning and maintenance. ● ● Do not splash water on the units for cleaning, as electric shocks may occur. ● Wipe the units with a dry soft cloth, or a cloth slightly moistened with water or cleaner (not with ●...
  • Page 16 Clean and care Check before use ① Be sure that nothing obstructs the air outlet and intake vents. ② Check that whether ground wire is properly connected or not. ③ Check that whether the batteries of air conditioner are changed or not. ④...
  • Page 17: Troubleshooting

    Troubleshooting CAUTION Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money. Phenomenon Troubleshooting Not operate immediately when the air Once the air conditioner is stopped, it will ●...
  • Page 18 Troubleshooting Phenomenon Troubleshooting Has the power been shut down? ● The unit can not run. ● Is the circuit protection device tripped off or not? Is voltage higher or lower? ● (Tested by professionals) Is the TIMER correctly used? ● Breaking off ●...
  • Page 19 Troubleshooting Phenomenon Troubleshooting Indoor unit cannot deliver air. In HEAT mode, when the temperature of indoor ● heat exchanger is very low, that will stop deliver air in order to prevent cool air. (Within 2min) In HEAT mode, when the outdoor temperature ●...
  • Page 20: Notices For Installation

    Notices for installation Important Notices 1. The unit installation work must be done by qualified personnel according to the local rules and this manual. 2. Before installation, please contact with local authorized maintenance center, if unit is not installed by the authorized maintenance center, the malfunction may not solved, due to discommodious contacts.
  • Page 21 Notices for installation Outdoor Unit Installation Position Selection 1. Select a location from which noise and outflow air emitted by unit will not inconvenience neighbors, animals, plants. 2. Select a location where there should be sufficient ventilation. 3. Select a location where there should be no obstructions cover the inlet and outlet vent. 4.
  • Page 22 Notices for installation Earthing requirements 1. Air conditioner is type I electric appliance, thus please do conduct reliable earthing measure. 2. The yellow-green two-color wire in air conditioner is earthing wire and cannot be used for other propose. It cannot be cut off and be fix it by screw, otherwise it would cause electric shock.
  • Page 23: Installation Dimension Diagram

    Installation dimension diagram Installation dimension diagram Space to the ceiling 15cm Above Space to the wall Above 15cm Above 15cm Space to the wall Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct ●...
  • Page 24: Install Indoor Unit

    Install indoor unit Install the rear panel 1.Always mount the rear panel horizontally. Due to the water tray of indoor unit has been adopted the both-way drainage design, the outlet of water tray should be adjusted slightly down when installing, that is taking the outlet of the water tray as the center of a circle, the included angle between the evaporator and level should be 0 or more, that is good for condensing water drainage.
  • Page 25: Install The Indoor Unit

    Install indoor unit NOTE: When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed. The electric wiring must be correctly connected, wrong connection may cause spare parts ●...
  • Page 26: Install Outdoor Unit

    Install outdoor unit Electric wiring Remove the handle on the right side plate of outdoor unit. For some model: N(1) Take off wire clamp. Connect and fix the power connection cord to the terminal board. Wiring should fit that of indoor unit.
  • Page 27: Check After Installation And Test Operation

    Check after installation and test operation Check after installation Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? capacity It may cause condensation and dripping.
  • Page 28: Installation And Maintenance Of Healthy Filter

    Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig.
  • Page 29: Configuration Of Connection Pipe And Additional Volume Of Refrigerant

    Configuration of connection pipe and additional volume of refrigerant 1. Standard length of connection pipe 5m、7.5m、8m 2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m.
  • Page 30 Configuration of connection pipe and additional volume of refrigerant Sheet 2. Additional refrigerant charging amount for R22 R407C R410A and R134a Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle Liquid pipe Gas pipe Cooling only, Cooling only Cooling and cooling and heating (g / m)
  • Page 31 GREE ELECTRIC APPLIANCES , INC . OF ZHUHAI Add: West Jinji Rd, Qianshan, Zhuhai, Guangdong, China, 519070 Tel: (+86-756) 8522218 Fax: (+86-756) 8669426 E-mail: gree@gree.com.cn www.gree.com 66162761...
