Nautilus 19-4944 Service Manual

Weight assisted chin-up/dip
Hide thumbs
Table of Contents

Advertisement

Quick Links

TM
CHIN-UP/DIP
SERVICE
MANUAL
REVISED: January 15, 1999
SERIAL NO.'S
______________
through
______________
®
22
25
23
Contents
Parts Manual
1
2
3
4
5
6
PARTS LIST
Maintenance Manual
Follows page 6
See last pages of this manual for 2ST
Floor Plan Kit and 2ST Strength Circuit
Exercise Order Diagram.
709 Powerhouse Road • Independence, Virginia 24348
800-235-2233 • Fax: 540-773-2298
19
79
24
K
2
19-4944
TM
®
PARTS AND SERVICE
5
1
9
6
7
3
4

Advertisement

Table of Contents
loading

Related Manuals for Nautilus 19-4944

Summary of Contents for Nautilus 19-4944

  • Page 1: Table Of Contents

    REVISED: January 15, 1999 See last pages of this manual for 2ST Floor Plan Kit and 2ST Strength Circuit SERIAL NO.'S Exercise Order Diagram. ______________ ® through PARTS AND SERVICE 709 Powerhouse Road • Independence, Virginia 24348 ______________ 800-235-2233 • Fax: 540-773-2298 19-4944...

  • Page 2: Frame Assembly

    Weight Assisted Chin-Up/Dip ® FRAME ASSEMBLY...

  • Page 3: Linkage Assembly

    Weight Assisted Chin-Up/Dip ® LINKAGE ASSEMBLY 35 16 28 32...

  • Page 4: Handle Bar Assembly

    Weight Assisted Chin-Up/Dip ® HANDLE BAR ASSEMBLY...

  • Page 5: Belt & Pulley Assembly

    Weight Assisted Chin-Up/Dip ® BELT & PULLEY ASSEMBLY...

  • Page 6: Weight Stack Assembly

    WEIGHT ASSISTED CHIN-DIP WEIGHT STACK USE CAUTION WHEN WORKING WITH WEIGHT REF# PART# DESCRIPTION STACK ! WS06 220 lb. WEIGHT STACK (20-220) A....01-1185 ..BOLT HH5 3/8 X 3 1/2 BLACK B....03-1035 ..3/8 NUT NTE BLACK C ...04-5070 ..RUBBER WASHER 3/4 X 1 1/2 X 1/2 D ...05-4020 ..BUSHING PLASTIC (WTS.) E....05-4035 ..TOP WEIGHT BUSHING F....06-8150 ..SNAP RING 5100-125 EXTERNAL...
  • Page 7 19 ..12-1026 ..KEEP HANDS AWAY 78 ..12-1080 ..INSPECTION STICKER DECAL 20 ..12-1106 ..DECAL "DO NOT DISENGAGE WEIGHTS" 79 ..12-1088 ..DECAL NAUTILUS NAMEPLATE 2 1/2 x 9 1/4 long 21 ..12-1107 ..DECAL WARNING NWACD 80 ..19-1291 ..DECAL SERIAL # BAR CODE 22 ..12-2794 ..PLACARD NWACD...

  • Page 8: Warranty Information

    NAUTILUS® exercise equipment is originally installed. This warranty shall apply only within the boundaries of the continental United States. NAUTILUS® shall not be liable for any loss or WEIGHT-PIN damage, including incidental or consequential damages resulting directly or indirectly from the use or loss of use of our NAUTILUS®...

  • Page 9: Welcome

    Nautilus' strict requirements. Should you, the owner of a Nautilus machine, need to replace any parts because of normal wear and tear, or should your machine ever need maintenance, Nautilus invites you to call our Virginia Headquarters office for information on parts and service.

  • Page 10: Parts & Service

    Always warm-up before and cool down after Never operate the machine without shields in exercising. place. Use only Nautilus selector pins in weight stack. Move slowly during each exercise. Do not jerk Never drop or insert any other object into or "throw" the weight.

  • Page 11: Cleaning

    Hydraulic Unit Adjustment 3. SHIELD REMOVAL Nautilus® 2ST machines are equipped with quick- release shield fasteners. To remove Quick-Release Note: The hydraulic unit only needs adjustment if the shielding, gently pull shielding away from the frame. seat will not stay in position.
