INSTALLATION INSTRUCTIONS USER GUIDE Box wall cooker hood HC60BCXB2, HC90BCXB2, and HC120BCXB2 models GB IE... -
Page 3: Table Of Contents
CONTENTS Introduction Safety and warnings Installation instructions About your cooker hood – Energy efficiency Operating instructions Cleaning and maintenance Parts and accessories Manufacturer’s Warranty Customer Care ImpORTANT! Registration SAVE THESE INSTRUCTIONS Register your product with us so we can The models shown in this user guide may provide you with the best service possible. -
Page 5: Introduction
INTROduCTION Thank you for purchasing a Fisher & Paykel product. Thousands of hours go into the design, engineering, testing and perfecting of each Fisher & Paykel appliance. The care and attention given to creating these beautiful products doesn’t stop once it has found its home with you. This use and care manual will answer most of your questions about the set-up, use and on-going maintenance of your Fisher &... -
Page 6: Safety And Warnings
SafETy aNd waRNINGS waRNING! weight Hazard The cooker hood is heavy. Please ensure adequate care is taken when installing the 13.5 kg cooker hood to prevent personal injury. The (HC60) cooker hood must be installed onto a solid 21.5 kg wall, stud, beam or truss. - Page 7 SafETy aNd waRNINGS to and request permission from the person in charge of the building. • Exhaust air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels. • There shall be adequate ventilation of the room when the cooker hood is used at the same time as appliances burning gas or other fuels.
- Page 8 SafETy aNd waRNINGS • always switch the power off prior to installation, servicing or cleaning the cooker hood. • If the supply cord of this equipment is damaged it must only be replaced by the manufacturer, its service agent or similarly qualified person in order to avoid a hazard.
-
Page 9: Installation Instructions
INSTaLLaTION INSTRuCTIONS Contents of packaging INSTALLATION INSTRUCTIONS USER GUIDE Box wall cooker hood HC60BCXB2, HC90BCXB2, and HC120BCXB2 models GB IE Cooker hood Installation instructions Chimney User guide manual Upper chimney Upper chimney bracket Chimney bracket Ducting adapter Expansion plug 30 mm self (150 mm Ø) - Page 10 INSTaLLaTION INSTRuCTIONS Product dimensions Power cord location Ø...
- Page 11 INSTaLLaTION INSTRuCTIONS HC60BCXB2 HC90BCXB2 HC120BCXB2 PROduCT dIMENSIONS Overall height of product 595 – 1035 595 – 1035 595 – 1035 Overall width of product 1198 Overall depth of product Height of hood Height of stainless strip Width of flue Depth of flue...
- Page 12 INSTaLLaTION INSTRuCTIONS Height of cooker hood INSTaLLaTION dIMENSIONS Installation height Ducted min. 635 – max. 1035 Recirculation min. 675 – max. 1035 Height top of hob to base of product Electric hob min. 600 – max. 750 Gas hob min. 650 – max. 750...
- Page 13 INSTaLLaTION INSTRuCTIONS Venting options Attention should be given to ensure that any applicable regulations concerning the discharge of exhaust air are fulfilled. The cooker hood can be installed to operate with the exhaust air ducted externally from the kitchen, or installed to operate with the exhaust air recirculating within the kitchen. Ducted For ducted installation it is recommended that 150 mm diameter, rigid or semi-rigid ducting is used.
- Page 14 INSTaLLaTION INSTRuCTIONS Installation WARNING! This product is heavy and requires two persons for installation. WARNING! failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. The manufacturer is not liable for any damage caused by not following these instructions. Preparing for installation: Before installing your cooker hood: Please read the instructions carefully.
- Page 15 INSTaLLaTION INSTRuCTIONS 250 mm Upper chimney extension bracket attachment points 235 mm Chimney bracket attachment points 250 mm Upper hood attachment points Lower hood attachment points Fig.2 HC60BCXB2 HC90BCXB2 HC120BCXB2 42.5...
- Page 16 INSTaLLaTION INSTRuCTIONS Fig.3 Attach ducting adapter Place the ducting adapter ● ● onto the hood and screw it in place using the 10 mm screws.
- Page 17 INSTaLLaTION INSTRuCTIONS Attach hood to wall Remove filters and easy clean plate from hood as shown in Fig.4. ● ● Fig.4...
- Page 18 INSTaLLaTION INSTRuCTIONS Fig.5 Hang hood off upper hood mounting screws with 2 mm gap. Hang off the keyhole ● ● attachment points on the back of the hood (see Fig.5). Tighten screws. Attach lower hood mounting screws to fix hood to wall. ●...
-
Page 19: About Your Cooker Hood - Energy Efficiency
COOkER HOOd – ENERGy EffICIENCy Product fiche EN61591 HC60BCXB2 HC90BCXB2 MOdEL HC120BCXB2 Annual Energy Consumption (kWh/annum) Time Increase Factor Energy Efficiency Index 44.8 Energy Efficiency Class Fluid Dynamic Efficiency 33.1 Fluid Dynamic Efficiency Class Lighting Efficiency Lighting Efficiency Class Grease Filtering Efficiency 91.2... -
Page 20: Operating Instructions
OPERaTING INSTRuCTIONS Touch control panel CONTROL PaNEL fEaTuRES Power on/off Turn the cooker hood on or off. The fan automatically turns on to operate at level 1. Fan speed 1 – 4 Adjust the fan speed levels from 1 – 4 with 1 being the lowest level and 4 being the highest. -
Page 21: Cleaning And Maintenance
CLEaNING aNd MaINTENaNCE ImpORTANT! Never use abrasive or oil based cleaners Maintenance Before performing any cleaning or maintenance on your cooker hood, ensure that the power supply is switched off to the hood. The cooker hood should be cleaned regularly using a mild, liquid detergent to avoid a build up of grease occurring. - Page 22 CLEaNING aNd MaINTENaNCE Carbon filters – for use in recirculation mode Active carbon filters are disposable items designed to remove grease and odours from cooking vapours before the air is channelled back into the kitchen. The active carbon filters must be replaced periodically to work properly, at least once every three months, depending on the frequency with which the cooker hood is used.
-
Page 23: Parts And Accessories
PaRTS aNd aCCESSORIES ITEM REfERENCE NuMBER LED bulb x2 792556 Aluminium filter 791938 Recirculation carbon filter 50031 Recirculation diverter 50032 Ducting kit 150 mm (eaves) 50033 Ducting kit 150 mm (wall) 50034... -
Page 24: Manufacturer's Warranty
MaNufaCTuRER’S waRRaNTy You automatically receive a 2 year Manufacturer’s Warranty with the purchase of this cooker hood covering parts and labour for servicing within the United Kingdom and Ireland. fisher & Paykel undertakes to: Repair or, at its option, replace without cost to the owner either for material or labour any part of the product, the serial number of which appears on the product, which is found to be defective within TWO YEARS of the date of purchase. -
Page 25: Customer Care
CuSTOMER CaRE Before you call for service or assistance... Check the things you can do yourself. Refer to your user guide and check that: Your product is correctly installed. You are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to your nearest Authorised Service Centre, Customer Care, or contact us through our local website listed on the back cover. - Page 26 CuSTOMER CaRE Complete and keep for safe reference: Model Serial No. Purchase Date Purchaser Dealer Suburb Town Country...
-
Page 28: Www.fisherpaykel.com
www.fisherpaykel.com Copyright © Fisher & Paykel 2015. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time. You should therefore check with your dealer to ensure this booklet correctly describes the product currently available.
