RLM 419P
Laminators
Instructions for Use
1. Set-up
The laminator should be installed on a
table where you have access to thefront
and rear side of the unit. Special care
must be taken to avoid any UV light
emission to the laminate. Even white
light from normal room illumination
will expose the laminate. We recom-
mend that you install yellow safelight
tubes or at least dim the room illumina-
tion during use and cover the laminator
after it has cooled down. A good venti-
lation of the room, or even a separate
air exhaust close to the laminator are
recommended.
Unpack the unit from its box and set it
on the table. Unpack all the accessories
as well. If you received the unit in a
wooden box there should be two round
knobs coming with it that need to be
mounted: One goes on a shaft at the
outer right side of the housing, the se-
cond one goes to the lower right frontof
the unit.
Do not yet mountthe inlet roller table.
Remove the coil holders from the unit.
To do so, first remove the take-up rol-
lers that are sitting on top of them and
put them aside. Pull the right end of the
hexagon rod back to the left and lift it
out of the holder. Use a 2.5 mm hex
screw key to remove the right flange
from each of the two rods. Shift the left
flanges on both rods so that they have
exactly the same distance from the left
end of the rod.
Connect the unit to your 230 V 50 Hz
main supply and check that the main
switch is off.
2. Control elements
The laminator has control switches on
the upper left and right side of the hou-
sing. To the right you see the main sup-
ply switch, the drive switch RUN and
the speed adjustmentpotentiometer.To
the left there is the digital temperature
control and the HEATER switch. The
transport and heater switches are illu-
minated when turned on.
The thermostat has two displays and
four buttons. The upper display shows
the actual temperature, the lower one
shows the set value. Press the mode
button once and use the up and down
arrow keys to set the desired tempera-
ture. Finally press the mode button
again. The out/off buttonserves to turn
the heaters off, butis notused in normal
operation.Use the HEATER switch in-
stead. The OUT LED right to the upper
display shows if the heaters are actually
on or off.
Page 1
