D-Link DBT-120 Quick Installation Manual

Hide thumbs Also See for DBT-120:
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
This product works with the
This product works with the
This product works with the
This product works with the
This product works with the
following operating systems:
following operating systems:
following operating systems:
following operating systems:
following operating systems:
Windows XP, Me, 2000, 98 Second
Windows XP, Me, 2000, 98 Second
Windows XP, Me, 2000, 98 Second
Windows XP, Me, 2000, 98 Second
Windows XP, Me, 2000, 98 Second
Edition, Macintosh OS X v10.2
Edition, Macintosh OS X v10.2
Edition, Macintosh OS X v10.2
Edition, Macintosh OS X v10.2
Edition, Macintosh OS X v10.2

Before You Begin

You must have at least the following:
•
Windows XP/Me/2000/98SE or Macintosh OS X v10.2
One Available USB Port
•
•
CD-ROM Drive
Check Your Package Contents
These are the items included with your purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of
their respective holders. Software and specifications subject to change without notice. DBT-120.06132003
• DBT-120 USB Bluetooth Adapter
• CD-ROM (containing Drivers,
Installation Guide, Manual,
and Warranty)
• USB Extension Cable
DBT-120
DBT-120
DBT-120
DBT-120
DBT-120
Personal Air
Bluetooth
™
USB Adapter

Advertisement

Table of Contents
loading

Related Manuals for D-Link DBT-120

Summary of Contents for D-Link DBT-120

  • Page 1: Before You Begin

    • USB Extension Cable If any of the above items are missing, please contact your reseller. ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DBT-120.06132003...

  • Page 2: Installing The Bluetooth Software

    Install the driver and software on the D-Link Insert D-Link PersonalAir CD BEFORE installing the DBT-120 Driver CD in the CD- DBT-120 USB Bluetooth ROM drive. Adapter into your computer. If this Autorun screen does not automatically appear, click on Start >...
  • Page 3 Installing the Bluetooth Software for Windows (continued) Click Next Click Install Only Windows XP and Windows 2000 Users will see this screen. Click...
  • Page 4 DBT-120, you can obtain the security code from this site: http://66.45.42.85/ dlink/. You will be asked for your DBT-120’s BD Address, which is a unique 12-digit number that identifies your product. The BD Address is located in the MAC: field on the label of the DBT-120.

  • Page 5: Using The Bluetooth Configuration Wizard

    Installing the Bluetooth Software for Windows (continued) Click Finish Only Windows 2000, Windows Me, and Windows 98SE Users will see this screen. Click Using the Bluetooth Configuration Wizard After you have completed the driver and software installation and reboot your computer, a Bluetooth icon will appear on your desktop and in the bottom right hand corner of your desktop screen (systray).
  • Page 6 Using the Bluetooth Configuration Wizard (continued) The Bluetooth Configuration Wizard launches the first time that you double click on My Bluetooth Places. Click Next Type a unique name for your Computer. Select Desktop Laptop Click Next Click Next...
  • Page 7 Using the Bluetooth Configuration Wizard (continued) Select the Services that your DBT-120 will provide to other Bluetooth products. Click Next You can choose to configure your other Bluetooth devices at this point. Otherwise, click Skip to finish the configuration for your DBT-120.
  • Page 8 Bluetooth devices and your setup is complete! For detailed explanations on using the Bluetooth software for Windows and troubleshooting tips, please refer to the DBT-120 Manual on the CD included with this product. DBT-120 Installation for Macintosh OS X v 10.2 Macintosh OS X 10.2 has built-in Bluetooth support for a true plug and play...

  • Page 9: Technical Support

    Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link Technical Support through our website, or by phone.
