Page 2: Fcc Information
FCC INFORMATION: This equipment has been tested and no found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not used these instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment of and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio radio/TV technician for help. FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. Modifications not authorized by the manufacturer may void users authority to operate this device. Note: Refer all servicing to qualified service personnel. Servicing is required when the unit has been damaged any way such as the following: the power‐supply cord or plug has been damaged, liquid has been spilled in to the unit, the unit has been exposed to rain or moisture, the unit has been dropped or the unit does not operate normally. 1. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquid, such as vases, shall be place on the apparatus. 2. Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall reaily operable. -
Page 3: Battery Recharge
Battery Recharge The unit has a built in Li‐ion rechargeable battery, recharge it before use as follow: Connect the Mirco USB plug from the USB Connection Cable to the Micro USB Port on the rear of unit. Connect the full size USB plug to the USB port on a computer or any USB charger having DC 5V output. (During charging, the Red Indicator will illuminate. When finished, it will turned off). Notes: Your battery will last longer if you following these simple guidelines for charging and storing. A. Recharging and store the unit within the temperature range of 5°C~35°C (40°F~95°F). B. Do not over charge (longer than 24 hours). Excessive charging or running the unit until battery goes empty will damage battery. C. Battery life naturally shortens slowly over time. D. The rechargeable battery incorporated in this product is not user replaceable. Location of Controls: Button Button Button Button Indicators Built‐in Microphone Micro USB Port (For charge only) USB Port TF (SD) Card Slot 10. AUX (in) Jack 11. Reset Button (Inside the AUX in Jack) -
Page 4: Operaton
OPERATON: General operation: Press and hold the Button approximate 0.5 second to turn it on. Press the Button repeatedly until the desired mode hearing from speaker as below: Blue tooth ready for connection Blue tooth connected Radio Line in ( =Aux in ) USB Memory Card Press and hold the or Button to adjust volume level. In BT; TF (SD) Card and USB Device playback mode: Press and release the or Button repeatedly to skip tracks. Press t the Button to pause; press again to resume normal playback. When finished listening, press and hold the Button to shut off. BT (Bluetooth) mode The first time you use the speaker or pair it to a new Bluetooth device, please follow these instruction: 1. Power on the unit as previous procedures. 2. Press the Button repeatedly until “Blue tooth ready for connection” hear from speaker. The Blue Indicator will light and blinking. 3. Power on the external Bluetooth Device and enter searching mode. Start paring following the on screen instructions from the external Bluetooth device. After pairing, “Blue tooth connected” will hear from speaker and the Blue Indicator will stop blinking. -
Page 5: Usb Device Playback Mode
Radio: Power on the unit as previous procedures. Press the Button repeatedly unit “Radio” hear from the speaker. Press the Button to searching and stored the available FM stations. During searching, the Blue Indicator will blink. When finished searching, the Blue Indicator will stop blinking. 3. Press and release the or Button repeatedly t plays the previous/next available FM station. M Antenna: The FM Antenna is built in the unit. If reception is weak, relocation or redirection the unit to improve the radio reception USB Device playback mode: In power off mode, insert the USB Device into the USB Port on the rear of unit as the figure below: Power on the unit as previous procedures. Press the Button repeatedly unit “USB” hear from speaker. The unit will start playback the music on the USB Device automatically. TF (SD) Card playback mode: In power off mode, insert the TF (Micro SD) Card into the TF (Micro SD) Card Slot on the rear of unit as the figure below: Power on the unit as previous procedures. Press the Button repeatedly unit “Memory card” hear from speaker. The unit will start playback the music on the TF (Micro SD) Card automatically. NOTES: Up to 16 GB USB Device (not included) or TF (Micro SD) Card (not included) the unit support to play. - Page 6 Before replacing USB Device or TF (Micro SD) Card, make sure the unit has been powered off. When inserting the USB Device or TF(Micro SD) Card, make sure the direction you selected is correct. Never insert violently to avoid damaging the USB Device or the unit. If it doesn’t work, please check if the direction is correct. You also need to download the desired music in MP3 format into the USB Device and/or TF (SD) Card before installing into the unit. AUX IN: To listening from the external Audio players such like MP3 Player, Discman …etc. 1. In power off mode, connect the 3.5mm stereo jack from the supplied Audio Connection Cable to the AUX Out/Line Out/Phone Jack on the external Audio Player. 2. Connect the other end to the AUX (in) Jack on the rear of unit as the figure below: Power on the unit as previous procedures. Press the Button repeatedly unit “Line in” hear from speaker. Plays the music on the connected Audio Player as usual. (Make sure the volume level of the connected Audio Player is high level. Otherwise, sound from this unit is weak). RESET: If the unit is halt or abnormal operation, press the Reset Button in the AUX (in) Jack by a small driver (not included) to shut it off. Press and hold the Button approximate 0.5 second to turn it on again.
-
Page 7: Troubleshoothing
Troubleshoothing: Can’t power on Built in battery consumed Recharge the battery No sound or sound weak Volume of the unit was set to Increase the volume by press minimum position and hold the Button Volume of paired/connected Rise the volume level of the device in low level connected/paired device Sound distortion Volume level too high Reduce the volume level by press and hold the Button Volume level of the Reduce the volume level of connected/paired device too the connected/paired device high EQ of the connected/paired Set the EQ of the device was set to super bass connected/paired device to others modes BT not functioning The external BT device too Place the external BT device far from the unit close to the unit The USB Device/Micro SD The USB Device/Micro SD card Try the others USB Card can’t be play may not match the speaker Device/Micro SD Card Gernal Specification: Power Source... -
Page 9: Fcc Statement
FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
