HOW TO CHANGE THE CERAMIC FILTERS This model is used two ceramic filters of CF1 and CF3. You must use same type of color marked ceramic filters in order to meet same specifications. Therefore, the ceramic filter must change two pieces together since it’s supply two pieces in one package as a spare parts.
SECTION 3 ELECTRICAL ADJUSTMENTS FM SECTION ICF-303L: ICF-303: AM SECTION LW SECTION BAND switch : FM BAND switch : AM BAND switch : LW FM RF signal telescopic generator antenna terminal AM RF signal AM RF signal Put the lead-wire Put the lead-wire generator generator...
Page 6
ICF-303/303L SECTION 4 DIAGRAMS 4-1. PRINTED WIRING BOARD LW FERRITE-ROD ANTENNA(303L) AM FERRITE-ROD ANTENNA(303) MAIN BOARD CLEAR CLEAR (303L) RF IN(+) RF IN(-) ANT 1 TUNE FM TELESCOPIC 303L ANTENNA 303L BPF1 LW ANT SP 1 SHIELD PLATE SPEAKER (303) TUNING AM IF AM OSC(303)
ICF-303/303L 4-2. SCHEMATIC DIAGRAM Note: • U : B+ Line. • All capacitors are in µF unless otherwise noted. pF: µµF • Voltages are taken with a VOM (Input impedance 10 MΩ). 50 WV or less are not indicated except for electrolytics •...
Ver 1.1 SECTION 5 SECTION 6 MAIN EXPLODED VIEW ELECTRICAL PARTS LIST NOTE: NOTE: • The mechanical parts with no reference • Items marked “*” are not stocked since • Color Indication of Appearance Parts • Abbreviation • Due to standardization, replacements in When indicating parts by reference number in the exploded views are not supplied.
Page 9
Ver 1.1 MAIN Ref. No. Part No. Description Remark 1-422-131-00 COIL, FM OSCILLATION (EXCEPT EE,IT,EA) 1-428-241-11 COIL, AIR-CORE (EE) 1-459-954-21 COIL (WITH CORE) (IT,EA) 1-406-028-00 COIL, OSC (MW) 1-410-294-11 INDUCTOR 38uH (303L) 1-412-316-11 INDUCTOR 120uH (303L) < RESISTOR > 1-216-198-00 RES,CHIP 1/8W 1-216-073-00 METAL CHIP 1/10W...
IDF-303/303L REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 1999. 07 2004.
