One for All URC-4330 User Manual

Mode Keys for 4 Device:
CBL/SAT VCR DVD TV
Press VCR, DVD, TV, or
CBL/SAT once to select
a home entertainment
device to control.
Use the keypad (0 ~ 9)
4 DEVICE to directly select
channels (for example,
UNIVERSAL REMOTE CONTROL
09 or 31).
Press MUTE once to
turn sound off
or on.
SET POWER
Press PREV CH once to
CBL/SAT VCR DVD TV
recall the last-viewed
SLEEP TV/VID
channel and to page
back one screen on the
main menu.
Press ENTER once
after entering channel
numbers on some TV
CH +
models.
VOL VOL
MUTE
- + Use MENU to choose
CH -
options from your
selected device's
REW PLAY FF
menu.
STOP PAUSE
REC
Use VOL+ (or VOL-)
to raise (or lower) the
sound volume.
Use CH+ (or CH -) to
select the next higher
(or lower) channel.
USER'S GUIDE
Press SLEEP to activate
your device's sleep
INTRODUCTION
timer (not available
for all devices).
The One For All 4 Device Universal
Remote Control is designed to operate Use the transport keys
three (or four) home entertainment to control your VCR,
devices, depending on the model pur- CD or DVD player, or
chased (see Key Charts, Mode Keys on
VOD. To record a
the right). program, press the
record key (
The remote control requires four fresh
twice.
AAA alkaline batteries (not included) and
easy programming to control your devices.
use TV/VID to switch
For best results, please read and perform the TV's input to view
all instructions listed here.Also, keep TV or video program.
these instructions for future reference.
INSTALLING BATTERIES
FEATURES AND FUNCTIONS
1. On the remote control's back, push the
tab and lift off the battery cover.
Use the Key Charts to learn how to use the
universal functions of the One For All 4 2. Obtain four (4) fully-charged AAA
Device Universal Remote Control.
alkaline batteries. Match the + and –
marks on the batteries to the + and
Key Charts
– marks in the battery case, then
Use SET for all insert the new batteries.
programming
3. Press the battery cover back into
sequences.
place. The tab should click when the
The LED (red light) cover is locked.
blinks to show that
4. Test the unit by pressing POWER
the remote control is
and any mode key (e.g., TV). If the
working and is
batteries are inserted correctly, the
sending signals.
LED will blink once.
NOTE: When batteries need replacement,
the remote control will stop operating.
Press POWER once to
Remove the old batteries and insert new
turn on or off the
ones within 30 minutes to ensure all of
selected device. your programming information is restored.
PROGRAMMING repeat steps 2-3, trying each code for
your brand until you find one that
DEVICE CONTROL
works. If it still does not work, try
Searching For Your Code.
The One For All 4 Device remote control
is preprogrammed at the factory to
NOTE: If the device does not have a
operate an RCA TV and VCR, a Motorola
POWER key, press the ( PLAY ) key.
(GI) cable box, and a Toshiba DVD play-
5. If you've located a TV/VCR setup
er. To control devices other than the
code that works your TV/VCR
default brands, perform the following
Combo and a separate TV code is
steps; otherwise skip this section:
also listed, you'll need to program
NOTE: For TV/VCR Combo control, see the
this code into the remote control to
next section.
access volume control .
1. Turn on a device (e.g.,VCR) and, if
applicable, insert media, (e.g.,
cassette or disc). SEARCHING FOR YOUR CODE
NOTE: Please read steps 2-4 completely
If your device does not respond to the
before proceeding. Highlight or write down
remote control after trying all codes
the codes and device you wish to program
listed for your brand, or if your brand is
before moving on to step 2.
not listed at all, try searching for your
2. On the remote control, press a device
code. For example, to search for a code
key once (i.e., VCR, DVD, TV, or
for your TV:
CBL/SAT ). Press and hold SET until
1. On the remote control, press TV once.
the LED blinks twice, then release
SET.
2. Press and hold SET until the LED
blinks twice, then release SET.
3. Use the Manufacturer's Codes to
locate the type of device and brand
3. Enter 9 - 9 - 1. The LED will
name and then enter the first four-
blink twice.
digit code for your component. If
4. Aim the remote control at the the
performed correctly, the LED will
TV and slowly alternate between
blink twice.
pressing POWER and TV. Stop when
NOTE: If the LED did not blink twice, then
the TV turns off.
repeat steps 2 through 3 and try entering
NOTE: In the search mode, the remote
the same code again.
control will send IR codes from its library
4. Aim the remote control at the device
to the selected device, starting with the
and press POWER once. The device
most popular code first.
should turn off. If it does not respond,
5. To lock in the code, press and hold
repeat steps 2-3, trying each code for
SET until the LED blinks twice, then
your brand until you find one that
release SET.
works. If it still does not work, try
Searching For Your Code.
6. To search for the codes of your other
devices, repeat steps 1 through 5, but
NOTE: If the device does not have a
substitute the appropriate device key
POWER key, press the ( PLAY ) key.
for the device you are searching for.
)
REC
5. Repeat steps 1 through 4 for each
CHECKING THE CODES
device you want to control.
PROGRAMMING
If you have set up the remote control
using the Searching For Your Code
TV/VCR COMBO CONTROL
procedure, you may need to find out
Perform the following instructions to
which four-digit code is operating your
control a TV/VCR Combo:
equipment:
1. Turn on the TV/VCR Combo and For example, to find out which code is
insert a video cassette. operating your TV:
NOTE: Please read steps 2-4 completely
1. On the remote control, press TV once.
before proceeding. Highlight or write down
2. Press and hold SET until the LED
the codes and device you wish to program
blinks twice, then release SET.
before moving on to step 2.
2. On the remote control, press VCR. 3. Enter 9 - 9 - 0. The LED will
Press and hold SET until the LED blink twice.
blinks twice, then release SET.
4. To view the code for the first digit,
3. Use the Setup Codes For TV/VCR press 1 once.Wait 3 seconds, count
Combos (on the back side) to locate the LED blinks (e.g., 3 blinks = 3)
and write down the number.
the brand name and then enter the
first four-digit code for your device.
NOTE: If a code digit is "0", the LED will
If performed correctly, the LED will
not blink.
blink twice.
5. Repeat step 4 three more times for
NOTE: If the LED did not blink twice, then
remaining digits. Use 2 for the
repeat steps 2 through 3 and try entering
second digit, 3 for the third digit,
the same code again.
and 4 for the fourth digit.
4. Aim the remote control at the device
6. To check for codes of other devices,
and press POWER once. It should turn
repeat steps 1 through 5, but substi-
off. If the device does not respond,
tute the appropriate device key for
each device you are checking. 1. On the remote control, press and
As before, write down each four- hold SET until the LED blinks twice,
digit code. then release SET.
2. Enter 9 - 9 - 3 and then press any
mode key once (except TV). The LED
RE-ASSIGNING DEVICE KEYS
will blink twice.
The One For All 4 Device can be set to
3. Now, whenever you press VOL+,
control a second TV,VCR, or DVD player.
VOL–, or MUTE, volume will be
controlled by your mode choice.
For example, to control two TVs, a VCR,
and a cable box, you will need to re-
Unlocking Volume Control:
assign the unused DVD key to operate
NOTE: Perform these instructions when you
the second TV as follows:
want independent volume control for each
1. On the remote control, press and
programmed device (e.g., TV volume control
hold SET until the LED blinks twice, in TV mode, CBL/SAT volume control in
CBL/SAT mode, etc.)
then release SET.
1. On the remote control, press and
2. Enter 9 - 9 - 2. The LED will
hold SET until the LED blinks twice,
blink twice.
then release SET.
3. Press TV once, then press DVD once.
2. Enter 9 - 9 - 3 and then press VOL+.
4. The DVD key is now ready to be
The LED will blink four times.
programmed for your second TV.
3. Volume will again be controlled
See Programming Device Control.
according to its default states.
To re-assign other device keys, repeat
steps 1 through 4 by substituting the key
sequence from the below chart for the
TROUBLESHOOTING
most popular components:
For assistance, please contact us in any
To Re-Assign Key
of the following ways:
Sequence Perform
• Consumer Help Line: (330) 405-8612
VCR as 2nd TV key: SET - 9 - 9 - 2
- TV - VCR • Internet: http://www.oneforall.com
VCR as 2nd CBL key: SET - 9 - 9 - 2
- CBL/SAT - VCR
PROBLEM: LED does not blink when
you press a key.
VCR as 2nd SAT key: SET - 9 - 9 - 2
- CBL/SAT - VCR
SOLUTION: Replace batteries with
four new AAA alkaline
VCR as 2nd DVD key: SET - 9 - 9 - 2
batteries.
- DVD - VCR
PROBLEM: LED blinks when you
VCR back to VCR: SET - 9 - 9 - 2
press a key, but home
- VCR - VCR
entertainment component
does not respond.
DVD as 2nd TV key: SET - 9 - 9 - 2
- TV - DVD SOLUTION: Make sure the remote
control is aimed at your
DVD as 2nd CBL key: SET - 9 - 9 - 2
home entertainment
- CBL/SAT - DVD
device and is not farther
than 15 feet away.
DVD as 2nd SAT key: SET - 9 - 9 - 2
- CBL/SAT - DVD
PROBLEM: The unit does not control
home entertainment
DVD as 2nd VCR key: SET - 9 - 9 - 2
devices or commands are
- VCR - DVD
not working properly.
DVD back to DVD: SET - 9 - 9 - 2
SOLUTION: Try all listed codes for the
- DVD - DVD
component brands being
set up. Make sure they
When a re-assignment is done, the LED
can be operated with an
will blink twice to confirm your choice.
infrared remote control.
At that time, you will need to program
the remote control for the new device PROBLEM: TV/VCR combo does not
(see Programming Device Control). respond properly.
SOLUTION: Use the VCR codes for
your brand. Some combo
CHANGING VOLUME LOCK
units may require both a
TV code and a VCR code
The One For All 4 Device is set to
for full operation.
control the volume of your TV in the TV,
VCR, CBL/SAT, and DVD modes. If you
PROBLEM: Changing channels does
want the volume to be controlled by a
not work properly.
mode other than TV (e.g., CBL/SAT),
SOLUTION: If original remote control
change the Volume Lock as follows:
required pressing ENTER
To Change Volume Lock To
to change channels, press
Another Mode:
ENTER on the remote
control after entering the MANUFACTURER'S CODES
channel number.
Setup Codes for TVs:
PROBLEM: Tried "Search Method"
AOC 0030, 0019, 0052
and still could not find a
Admiral 0093, 0463
working code.
Aiko 0092
SOLUTION: Clear the device key as Akai 0030
Alaron 0179
follows: Press and hold
Ambassador 0177
SET until the LED
America Action 0180
blinks twice, then release.
Ampro 0751
Next enter 9 - 9 - 2. Then
Anam 0180
press the device key to be
Audiovox 0451, 0180, 0092, 0623
cleared twice. Now repeat
Baysonic 0180
the "Search Method. " Belcor 0019
Bell & Howell 0154
PROBLEM: CH and CH do not
Bradford 0180
work for your RCA TV.
Brockwood 0019
Broksonic 0236, 0463
SOLUTION: Due to RCA design (1983-
CXC 0180
1987), only the original
Candle 0030, 0056
remote control will oper- Carnivale 0030
ate these functions. Carver 0054
Celebrity 0000
PROBLEM: Remote control does not
Cineral 0451, 0092
turn on Sony or Sharp Citizen 0060, 0030, 0056, 0039, 0092
TV/VCR Combo. Concerto 0056
Contec 0180
SOLUTION: For power on, these prod-
Craig 0180
ucts require programming Crosley 0054
Crown 0180, 0039
TV codes. For Sony, use
Curtis Mathes 0047, 0054, 0154, 0051, 0451, 0093,
TV code 0000 and VCR
0060, 0030, 0145, 0056, 0039, 0166, 0466,
code 0032. For Sharp, use
1147, 1347
TV code 0093 and VCR
Daewoo 0451, 0019, 0039, 0092, 0623, 0624
code 0048. Daytron 0019
Denon 0145
Dumont 0017, 0019
Dwin 0720, 0774
Electroband 0000
Emerson 0154, 0236, 0463, 0180, 0178, 0019,
0179, 0039, 0177, 0623, 0624
Envision 0030
Fisher 0154
Fujitsu 0179, 0683
Funai 0180, 0179, 0171
Futuretech 0180
GE 0047, 0051, 0451, 0093, 0178, 0135,
1147, 1347
Gibralter 0017, 0030, 0019
GoldStar 0030, 0178, 0019, 0056
Gradiente 0053, 0056
Grunpy 0180, 0179
Hallmark 0178
Harley
Davidson 0179
Harman
/Kardon 0054
Harvard 0180
Hitachi 0145, 0056, 0151
Infinity 0054
Inteq 0017
JBL 0054
JCB 0000
JVC 0053
KEC 0180
KTV 0180, 0030, 0039
Kaypani 0052
Kenwood 0030, 0019
LG 0056
LXI 0047, 0054, 0154, 0156, 0178
Luxman 0056
MGA 0150, 0030, 0178, 0019
MTC 0060, 0030, 0019, 0056
Magnavox 0054, 0030, 0179, 1254
Marantz 0054, 0030
Matsushita 0250
Megatron 0178, 0145
Memorex 0154, 0250, 0463, 0150, 0178, 0056
Midland 0047, 0017, 0051, 0039, 0135
Mitsubishi 0093, 0150, 0178, 0019
Motorola 0093
Multitech 0180
NAD 0156, 0178, 0166
NEC 0030, 0019, 0056
NTC 0092
Nikko 0030, 0178, 0092
