Using This Manual

1-2 Introduction
This manual will help you install, program and operate the
AT&T Door Phone Controller. It contains important information
on what features are available and how to use them. We urge
you to read this manual prior to installing the AT&T Door
Phone Controller; this will ensure that you are using the
product to its fullest capability.
Section 1 (this section) provides basic information on what the
AT&T Door Phone Controller is and what are its features. Also
included is a GIossary of Terms, a necessity for persons not
familiar with telephone equipment operation and installation.
Section 2, Installation, provides important installation
information. This section has step-by-step procedures for
connecting the AT&T Door Phone Controller to such optional
equipment as
Remote door unlocking devices
Door ajar switch
Auxiliary alert device
Remote open button
Section 2 also provides an easy to use flow chart, which directs
the installer to the next appropriate section, depending on what
type of telephone equipment (residential, PBX, etc.) will be
used along with your AT&T Door Phone Controller.
Sections 3 through 6 – after reading Section 2 and the flow
chart at the end of that section, the installer is referred to one
of these sections. Depending on which section is referenced,
all the necessary programming, switch setting and operating
information will also be included.
Section 7 provides troubleshooting tips for when installation is
complete and the AT&T Door Phone Controller is not operating
correctly.
Tear-out Reference Card at the end of this manual provides
all the necessary option selection information along with
complete DIP switch settings and their definitions.
