2015 Quick Reference Guide

Advertisement

Table of Contents
loading

Related Manuals for Subaru 2015 Forester

Summary of Contents for Subaru 2015 Forester

  • Page 1 2015 Quick Reference Guide...

  • Page 2: Driver's Area

    DRIVER’S AREA Tilt / telescopic steering wheel Hazard warning flasher Adjust the seat position and pull the tilt/telescopic To turn on, press the button. lock lever down. Move the steering wheel to the Use in emergency conditions. desired level. Pull the lever up to lock the steering wheel in place.

  • Page 3: Fog Lights - If Equipped

    FORESTER Headlights / Turn signal Headlights To turn on, rotate knob to; : Instrument panel illumination, headlights, parking lights, front side marker lights, rear side marker lights, tail lights and license plate lights are on. : Instrument panel illumination, parking lights, front side marker lights, rear side marker lights, tail lights and license plate lights are on.

  • Page 4: Rear Window Wiper And Washer

    Rear window wiper and washer Wiper Washer To operate, rotate knob to; Rotate knob to . The washer and : Continuous wiper operate until you release the knob. : Intermittent : Off -In the intermittent position, when you move the select lever to the R position (CVT) or the shift lever to the reverse position (MT), the rear wiper will switch to continuous operation.

  • Page 5: Continuously Variable Transmission (If Equipped)

    FORESTER Continuously variable transmission (if equipped) Select lever button With the brake pedal depressed, shift while pressing the button in Shift while pressing the button in Shift without pressing the button Models with Models with Manual mode “L” position P = Park To move select lever from Park: L position: L is for using engine braking when going down Firmly depress brake pedal.

  • Page 6: Audio Control Buttons

    SI-DRIVE switches (if equipped) This system consists of three modes: Intelligent (I), Sport (S), and Sport Sharp (S#). By operating the SI-DRIVE switches, the character of the power unit changes. Intelligent (I) mode: Perform either of the following procedures. - Press the S/I switch when the Sport (S) mode is selected. - Press the S#/I switch when the Sport Sharp (S#) mode is selected.

  • Page 7: Cruise Control (If Equipped)

    FORESTER Cruise control (if equipped) For models with the EyeSight system: Refer to the Owner’s Manual supplement for the EyeSight system. Cruise control enables you to maintain a constant vehicle speed without holding your foot on the accelerator pedal and it is operative when the vehicle speed is 40 km/h (25 mph) or more.
  • Page 8 METERS / INDICATORS D G H SELECT The design may be slightly different from the illustrations depending on the models and destinations. For models with the EyeSight system: Refer to the Owner’s Manual supplement for the EyeSight system. Speedometer Tachometer Fuel gauge Odometer / Trip meter Trip meter A/B selection and reset knob...
  • Page 9 FORESTER MAIN WARNING AND INDICATOR LIGHTS Refer to the Owner’s Manual for countermeasures when each warning light comes on. If necessary, consult your authorized Subaru dealer. Seatbelt warning Front passenger’s seatbelt warning PASSENGER Remind the driver to fasten seatbelt. Remind the front passenger to fasten seatbelt.

  • Page 10: Head Restraint Adjustment

    SEAT, SEATBELT Front seat adjustment Power seat (driver’s seat – if equipped) Forward and backward adjustment: Move switch forward or backward. Seat cushion angle: Pull up or push down the front end of switch. Seat height adjustment: Pull up or push down the rear end of switch.

  • Page 11: Folding Down

    FORESTER Folding down Front seatbelt Seat heater anchor height rear seatback HIGH HIGH HIGH HIGH To fold rear seatback down, HIGH: Rapid heating To raise: Slide the anchor up. pull release knob and fold LOW: Normal heating To lower: Pull the release knob seatback down.

  • Page 12: Power Windows

    DOOR LOCKS AND WINDOWS Remote keyless entry Unlocking : Press . Driver’s door will be unlocked.To unlock all doors and rear gate, briefly press the button a second time within 5 seconds. Locking : Press . All doors and the rear gate will be locked. Unlocking rear gate : Press .

  • Page 13: Power Rear Gate (If Equipped)

    FORESTER Power rear gate (if equipped) Power rear gate button on Power rear gate button Power rear gate button the Instrument panel on the rear gate on the remote transmitter To open the rear gate: Perform any of the following procedures when the rear gate is closed. - Press and hold the power rear gate button on the instrument panel.

  • Page 14: Climate Control

    CLIMATE CONTROL Type A Control panel Type B for Type B Airflow mode selection dial / button Turn dial or press the button to select the desired air flow mode. For type A, to defrost windshield, place the dial in the position.

  • Page 15: Maintenance

    FORESTER AUTO button (for type B only) FULL AUTO mode operation: When the AUTO button is pressed, the indicator light FULL AUTO on the display illuminates. In this state, fan speed, air flow distribution, air-inlet control, and air conditioner compressor operation are automatically controlled.
  • Page 16 Colours shown may vary due to reproduction variations in the printing process, and some vehicle parts cannot be shown in certain photographs. Subaru Canada, Inc. reserves the right to discontinue or make changes at any time, without notice or incurring obligations, to colours, materials, equipment, accessories, features, specifications and models, or to change their prices.
