Pioneer KEH-P6910R Installation Manual

KEH-P6910R
This product conforms to new cord colors.
о од о д л о .
Printed in Thailand
о л д
<CRD3116-A/N> EE <99I00F0P01>
Installation
Note: Installation with the rubber bush
• Before finally installing the unit, connect the
wiring temporarily, making sure it is all connect-
Holder
ed up properly, and the unit and the system work
After inserting the holder into the dashboard,
properly.
then select the appropriate tabs according to
• Use only the parts included with the unit to
the thickness of the dashboard material and
ensure proper installation. The use of unautho-
bend them. (Install as firmly as possible
rized parts can cause malfunctions.
using the top and bottom tabs. To secure,
• Consult with your nearest dealer if installation
bend the tabs 90 degrees.)
requires the drilling of holes or other modifica-
tions of the vehicle.
• Install the unit where it does not get in the dri-
Dashboard
ver's way and cannot injure the passenger if there
is a sudden stop, like an emergency stop.
182
• If installation angle exceeds 30° from horizontal,
the unit might not give its optimum performance.
53
30°
Removing the Unit
Pull out to remove the frame.
(When reattaching the frame, point the
side with a groove downwards and
attach it.)
Rubber bush
Screw
Insert the supplied extraction keys into the
unit, as shown in the figure, until they click
into place. Keeping the keys pressed against
the sides of the unit, pull the unit out.
<ENGLISH>
Frame
