Page 1: Table Of Contents
ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.
Page 2 Paradyne or its authorized distributor or reseller under the following terms and conditions: 1. Ownership: The Software is the sole property of Paradyne and/or its licensors. The Licensee acquires no title, right or interest in the Software other than the license granted under this Agreement.
Page 3: Introduction To The Tne1544 And Tne1584
12000 and 4000 IP Broadband Access Concentrators that provide up to 6 Mbps (TNE1544) or 12 Mbps (TNE1584) of symmetrical bandwidth using T1 lines. The TNE1544 features four T1 ports, and the TNE1584 eight T1 ports, each capable of up to 1.5 Mbps bandwidth. When used with any Paradyne loop bonding compatible product, one to eight ports may be used to deliver high-speed bandwidth at any given distance.
Page 4: Package Contents
Package Contents Unpack and Inspect the network extender. If there is any visible damage, do not attempt to connect the device. Contact your sales or service provider. Powering Up the Network Extender The DC power terminal block on the network extender has five terminals: two positive, two negative, and one ground.
Page 5 5. Verify that the Power LED on the front of the network extender is illuminated. 04-17606 04-17605...
Page 6: Connecting The T1 Lines
Multiple T1 lines also act as a backup should any of the lines become disabled. A network extender can only establish loop bonded connections with other Paradyne equipment with the loop bonding feature. See Product to Product T1 Loop Bonding Compatibility (document number COMP-A2-GK43).
Page 7: Connecting The Ethernet Lines
A single line connection can be established between a subscriber unit and any Paradyne T1 provider unit, regardless of loop bonding capability. Likewise, a single line connection can also be established between a provider unit and any of Paradyne’s T1 subscriber units, regardless of loop bonding capability.
Page 8: Led Indicators
LED Indicators Table 2. LEDs (1 of 2) State Indication Additional Information 10/100 Pulsing Standard operation Traffic is flowing without any Ethernet Green problems. Connections Solid Ethernet connection is If the Ethernet Lnk LED is Lnk/Act Green established illuminated but not the Ethernet 100 LED then a 10 Mbps connection has been established.
Page 9 Table 2. LEDs (2 of 2) State Indication Additional Information Flashing T1 connection is Traffic is flowing. Connections Green* established and active Lnk/Alm Solid T1 link A connection exists but there (Ports 1–4 Green is indication of a problem with or 1–8) the T1 line.
Page 10: Web Interface
Web Interface The network extender’s integral Network Management System (NMS) lets you configure and monitor the network extender using a standard web browser. To manage a Provider unit using NMS, connect your PC to any Ethernet port of the Provider unit. By default, the Subscriber unit can be managed by NMS through an active T1 line from the Provider side of the network.
Page 11 5. Write down the current IP Address and Subnet Mask in the Internet Protocol (TCP/IP) Properties dialog box. When you are done using NMS, you will need to reconfigure your PC with these values. 6. In the Internet Protocol (TCP/IP) Properties dialog box, click in the radio button labeled “Use the following IP address”...
Page 12: Command Line Interface
From this screen you can: Click on . . . To configure . . . Management Config. IP Address, Subnet Mask, Default Gateway, Inband Management VLAN ID and Priority Advanced Config. System Name and Location, Management IP Address Filter, TFTP and Telnet access HTTP Password General and Superuser Passwords SNMP Config.
Page 13 Connecting a PC Directly Initial configuration using the CLI requires a direct physical connection from your PC to the COM port of the DSLAM, management card, or Network Extender you are configuring. (However, the web interface is recommended for subsequent configuration.) Procedure 1.
Page 14: Rj45 Pin Assignments
RJ45 Pin Assignments T1 RJ45 Pin Assignments If you are using a shielded T1 cable for your network connection, it must be grounded through pins 3, 6, 7 and 8. Table 3. T1 RJ45 Pin Assignments Function Pin 1 Rx Ring Pin 2 Rx Tip Pin 3...
Page 15 DB9 to RJ45 Adapter Pinouts To connect the COM port to the DB9 serial port of a PC, use an adapter wired as shown: Table 5. DB9 to RJ45 Adapter Pinouts RJ45 Port Direction PC RS232 Serial Port → Transmit Data Receive Data ←...
Page 16: Specifications
T1 Line Code: B8ZS, AMI Bandwidth/Distance Up to 1.5 Mbps per T1 port TNE1544: Up to 6 Mbps using loop bonded T1 circuits TNE1584: Up to 12 Mbps using loop bonded T1 circuits Regulatory EMC: FCC Part 15; ICES-003; EN 300 386-2; CE Marking Compliance Safety: UL1950, CSA C22.2 No.
Page 17: Emi Notices
The authority to operate this equipment is conditioned by the requirements that no modifications will be made to the equipment unless the changes or modifications are expressly approved by Paradyne Corporation. If the equipment includes a ferrite choke or chokes, they must be installed per the installation instructions.
Page 18: Important Safety Instructions
Important Safety Instructions 1. Read and follow all warning notices and instructions marked on the product or included in the manual. 2. Do not allow anything to rest on the power cord and do not locate the product where persons will walk on the power cord. 3.
Page 19: Product Documentation Online
Complete documentation for Paradyne products is available at www.paradyne.com. Select Support → Technical Manuals. To order a paper copy of a Paradyne document, or to speak with a sales representative, please call 1-727-530-2000. Copyright © 2005 Paradyne Corporation. Printed in U.S.A.
Page 20 (" " *TNE1-A2-GN14-00*...
