DESCRIPTION
• Metal construction with various finishes identified by suffix
• 1/2" IPS connections will accept standard ball
nose connection for 3/8" tubing
• Includes pop-up type waste assembly
OPERATION
• Lever style handles
• Hot side counterclockwise to open (clockwise to close)
• Cold side clockwise to open (counter-clockwise to close)
FLOW
• Aerator is limited to 1.5 gpm max (5.7 L/min)
CARTRIDGE
• 1224 cartridge design
• Nonmetallic and stainless steel material
STANDARDS
• Third party certified to: CSA B-125.1, ASME A112.18.1,
ICC A117.1 and all applicable requirements referenced therein
• Certified to ANSI/NSF 61/9
• Complies with California Proposition 65 and with
the Federal Safe Water Drinking Act
•
ADA
for lever handles
WARRANTY
• Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
3-5/8"
(92mm)
9-1/4"
(235mm)
Lift
Rod
4"
(102mm)
6-1/4"
(159mm)
CRITICAL DIMENSIONS
(DO NOT SCALE)
S p e c i f i c a t i o n s
Two-Handle Lavatory Faucet
Models: 84912 series
NOTE: THIS FAUCET IS DESIGNED TO BE
INSTALLED THRU 3 HOLES, 1" MIN. DIA.
5-5/8"
(143mm)
3-3/4"
(95mm)
2-3/8"
(60mm)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
BANBURY
®
2-7/16"
(62mm)
www.moen.com
