DESCRIPTION
• Metal construction with chrome plated finish
• 1/2" IPS connections
• Includes hot and cold indicators
• Includes pop-up type waste assembly
OPERATION
• Lever style Porcelain handles
• Maximum handle rotation angle is 180˚ to full
on for either handle.
• Hot side counterclockwise to open (clockwise to close).
• Cold side clockwise to open (counterclockwise to close).
FLOW
• Aerator is limited to 2.2 gpm (8.3 L/min)
CARTRIDGE
• 1224 Cartridge design
• Nonmetallic and stainless steel material
STANDARDS
• Third party certified to CSA B125 and
ASME A112.18.1M and all applicable requirements
referenced therein
• Certified to ANSI/NSF 61/9
• Complies with California Proposition 65 and with
the Federal Safe Water Drinking Act
WARRANTY
• Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
1-7/8"
(48mm)
3/4" (19mm)
MAX. DECK
THICKNESS
MOUNTING
NUT/WASHER
4-3/4"
(121mm)
CRITICAL DIMENSIONS
S p e c i f i c a t i o n s
ADA
Two Handle Lavatory Faucet
Models: 84429, 84430SLPC
NOTE: THIS FAUCET IS DESIGNED TO BE
4"
(102mm)
HOT
1/2" NPT
LIFT ROD
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
with Waste Assembly
INSTALLED THRU 3 HOLES,
1" (25mm) MIN. DIA.
3-3/8"
(80mm)
COLD
1/2" NPT
www.moen.com
