- Page 1 SW-150 Miller & Kreisel Sound Corporation 9351 Deering Avenue Chatsworth, CA 91311-5858 (818) 701-7010 fax (818) 701-0369 www.mksound.com ©2001 Miller & Kreisel Sound Corp.
-
Page 2: Table Of Contents
In-wall Operation Manual Table of Contents Introduction ...3 Figure 1 - Major Components of the SW-150 ...3 Speaker Hookup ...4 Figure 2 - SW-150 Rear View ...4 Application ...4 Post Construction Installation ...5 Mounting Speaker in Wall ...6 Pre-Construction Installation ...8 Satellite &... -
Page 3: Introduction
If you have any questions about your in-wall speaker system, please contact your M&K dealer or call the M&K factory directly at (818) 701-7010, from 8:30 AM to 5:00 PM Pacific Time, Monday through Friday. We will be happy to help you with any question. -
Page 4: Figure 2 - Sw-150 Rear View
Left Surround, Right Surround, and Back Surround Channel Speakers for high-performance multichannel systems. Especially well-suited for use as surround speaker in systems using M&K S-150 and S-150 speakers for Left, Right, and Center Channels. FIGURE 2 - SW-150 Rear View... -
Page 5: Post Construction Installation
2. Cut opening precisely with a drywall saw, drywall router, etc. Sand edges and clean debris from installation area. 4. Tape speaker wire to the back wall so the end is within the opening as shown. 5. Fold the first section of the foam strip and insert the corner through the wall opening. -
Page 6: Mounting Speaker In Wall
10. Angle the speaker toward the wall and slip the bottom portion of the mounting arms into the wall opening. 12. Center the speaker within the wall opening... - Page 7 In-wall Operation Manual 13. Make sure that the baffle is level by checking with a leveling device. 15. The grille ca be painted with Latex paint to match the wall color if desired. Make sure that the paint is thin enough and applied carefully so that it does not clog the openings on the grille.
-
Page 8: Pre-Construction Installation
7. SATELLITE/SUBWOOFER PHASING TEST When using a subwoofer with your SW-150, a phasing test must be performed to insure good bass blending. This test insures optimum sound in the critical bass frequencies where your Subwoofer and Main speakers overlap. -
Page 9: Speaker Damage And How To Avoid It
The best way to avoid speaker damage is to use common sense. Use moderate boosts of tone controls or equalizers, at the very most. Listen carefully for any harshness and break-up, especially at high volume levels, and turn down the volume when needed. -
Page 10: Sw-150 Specifications
25 and 400 watts RMS 400 watts RMS unclipped peaks 77 Hz - 20 KHz ± 2 dB 92dB 11 gauge steel 12.14” x 10.45” 11.25” x 9.875” 3.16” SW-150 Baffle (Front View) 12.14" 10.45" Grille (Side View) SW-150 (Side View) 3.16" 0.39"... - Page 11 In-wall Operation Manual...
