FOR YOUR RECORDS Write the model and serial numbers here: You’ve just purchased a new #_______________________________ Eccotemp L10 portable tankless #_______________________________ water heater. This will open a world of enjoyment to going tankless. You can find them on a label on the appliance and/or packaging.
Page 3
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 IMPORTANT SAFETY INFORMATION READ ALL INSTRUCTIONS BEFORE USING Be sure to read and understand the entire Use and Care Manual before attempting to install or operate this water heater.
Page 4
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 DANGER! NATURAL GAS AND LIQUEFIED PETROLEUM MODELS Both LP and natural gas have an odorant added to aid in detecting a gas leak. Some people may not physically be able to smell or recognize this odorant. If you are unsure or unfamiliar with the smell of LP or natural gas, ask the gas supplier.
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Functions and Features • Water controlled automatic ignition: Water pressure between 20-80 PSI and 0.75-1.0 GPM opens the ignition circuit for easy and convenient operation.
Page 7
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Construction and parts for the L10 Flame sensor pin PLEASE NOTE: THIS MODEL IS NOT RECOMMENDED NOR HAS IT BEEN TESTED FOR ANY PERMANENT INSTALLATIONS. THIS MODEL IS PART OF OUR PORTABLE SERIES AND NEEDS TO BE TAKEN DOWN AND STORED IN A WARM DRY PLACE AFTER EVERY USE.
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Getting Started 1. Check box for damage. Damages caused in shipment must be reported immediately. 2. Make sure you have all the parts. Please note: Included parts and accessories may vary depending on county and regulations.
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Before going to the USE section: Check around area for flammables, especially gasoline or other vapors which may ignite. The exhaust and top of the portable tankless water heater will get HOT! Make sure there are no foreign objects around the portable tankless water heater or have fallen into the top.
Page 10
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Adjustment The temperature of the outgoing water is dependent on the temperature of the incoming water balanced with the amount of heat applied. Use extreme caution in setting the outlet water temperature.
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 DO NOT RETURN TO STORE Please visit our Helpdesk at www.eccotemp.com or contact us via email at support@eccotemp.com if you encounter a problem! Troubleshooting Portable tankless water heater will not start –...
Page 12
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Troubleshooting Continued... c. Out of, or low on gas. Propane gas cylinders sometimes are contaminated with air, especially new tanks upon their first filling. Cycle the portable tankless water heater on and off by using the shower head switch several times (5) to purge the air from the gas.
Page 13
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 L5 Series i12 Series 45 Series Eccotemp Product Comparison Chart Outdoor Only Indoor Only Indoor / Outdoor L5 Series i12 Series 45 Series Specifications...
Page 14
All shipments of any type of product coming to Eccotemp for any reason must have an RGA for any repairs to be made. Please contact Eccotemp to obtain an RGA number prior to shipping anything to Eccotemp. Failure to do so could result in loss of product.
Page 15
Eccotemp Systems LLC | Email: Support@eccotemp.com | Address: 315 - A Industrial RD Summerville, SC 29483 Extended Warranty : Warranty Features: * No hassle complete replacement of your item it breaks * Coverage begins after the manufacturer warranty expires. * Does not include accidents.
Page 18
Escriba el modelo y los números de serie aquí: Acaba de comprar un nuevo #_______________________________ calentador de agua Eccotemp #_______________________________ L10 portátil sin tanque. ¡Esto le descubrirá un mundo nuevo al Puede encontrarlos en una etiqueta sobre el librarse por fin del tanque! dispositivo y/o en el empaquetado.
Page 19
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 20
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Esto podría causar una rotura en el regulador de gas. Propósito y Beneficios del L10 El Eccotemp L10 es un calentador de gas portátil de propano líquido capaz de generar de 2 a 2,65 galones de agua caliente en casi cualquier lado. El calentador de agua portátil sin tanque tiene conexiones de tubería estándar de 1/2”...
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 23
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 25
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 26
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 28
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 29
ES PARTE DE NUESTRA SERIE DE PRODUCTOS PORTÁTILES Y NECESITA SER RETIRADO Y ALMACENADO EN UN LUGAR SECO DESPUÉS DE CADA USO. ESTE MANUAL Y TODO EL CONTENIDO DE ECCOTEMP ESTÁ SUJETO A CAMBIOS SIN NINGÚN TIPO DE AVISO. Soporte Producto: Eccotemp.com/help-desk Comprar Online: Eccotemp.com/products...
Page 30
Este producto no se para ser usado como una piscina o calentador de spa. Costes de Envío Relacionados: Dentro de los primeros 30 días de la compra , Eccotemp cubrirá todos los gastos de envío por tierra relacionados con cuestiones de garantía, excluyendo Alaska, Hawái, Canadá y cualquier punto fuera de los EE.UU.
Page 31
RGA para cualquier reparación a hacerse. Por favor, póngase en contacto con Eccotemp para obtener un número RGA antes de enviar cualquier cosa a Eccotemp. Si no lo hace, podrá resultar en la pérdida de producto. Eccotemp no será responsable del reemplazo debido a la pérdida o daño si estos pasos no se siguen correctamente.
Page 34
POUR VOS DOSSIERS Écrivez le modèle et les numéros de série ici: Vous venez d’acheter un nouveau #_______________________________ chauffe-eau portable Eccotemp L10 #_______________________________ sans réservoir. Cela vous permettra de profiter d’un monde de plaisir Vous pouvez les trouver sur une étiquette sans réservoir!
Page 35
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 IMPORTANTES INFORMATIONS DE SÉCURITÉ : LISEZ LES INSTRUCTIONS AVANT UTILISATION Assurez vous de lire et de comprendre le manuel d’utilisation et d’entretien avant d’essayer d’installer ou de faire fonctionner ce chauffe-eau.
Page 36
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 DANGER! LES MODELES AU GAZ NATUREL ET PETROLE LIQUEFIE Les deux modèles pétrole liquéfié et gaz naturel ont un odorant ajouté pour aider à la détection d’une fuite de gaz.
Le L10 n’est pas un jouet. Des personnes utilisent des chauffe-eau sans réservoir portatif similaires à travers le monde pour chauffer l’eau autour de leurs maisons, de façon sécurisée et fiable.
Page 38
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 FONCTIONS ET CARACTERISTIQUES • L’eau contrôlée par allumage automatique: la pression de l’eau entre 20-80 PSI /0.75-1.0 GPM ouvre le circuit d’allumage pour une utilisation facile et pratique.
Page 39
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 CONSTRUCTION ET PARTIES DU L10 Plaque arrière Collecteur d’air Echangeur de chaleur Capteur de température Brûleur principal Broche d’allumage Broche d’allumage II Broche d’allumage II Vanne de réglage de gaz...
Page 40
ATTENTION ! LES RESERVOIRS DES CHAUFFES-EAU L5, L7, L10 ONT UN ADAPTATEUR ½’ A 3/8’ DANS LA BOITE DE QUINCAILLERIE POUR LA FIXATION DU TUYAU DE GAZ LIQUIDE DU CHAUFFAGE. CET ADAPTATEUR DOIT ETRE INSTALLE AVEC UN PRODUIT D’ETANCHEITE. UNE BOBINE DE RUBAN D’ETANCHEITE EST INCLUE AVEC LE CHAUFFE-EAU.
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 Avant d’aller à la section UTILISATION : Vérifiez autour de la zone pour les produits inflammables, en particulier l’essence ou d’autres vapeurs qui peuvent s’enflammer. L’échappement et le dessus du chauffe-eau deviennent chaud! Assurez-vous qu’il n’y ait pas de corps étrangers dans le chauffe-eau ou d’éléments qui soient...
Page 42
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 AJUSTEMENTS La température de l’eau sortante est dépendante de la température de l’eau entrante pondérée avec la quantité de chaleur appliquée. Utilisez avec extrême prudence la régulation de la température de sortie d’eau.
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 NE PAS RETOURNER LE MATERIEL AU MAGASIN Veuillez visiter notre bureau d’aide au www.eccotemp.com ou contactez-nous par courriel à support@eccotemp.com si vous rencontrez un problème! DEPANNAGE Le chauffe-eau portable sans réservoir ne démarre pas - il n’y a pas de clics audibles au...
Page 44
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 DEPANNAGE PSI/2,7-4,1bar pour une utilisation adéquate si vous utilisez une pompe 12/18/120/240 volts. Vous référer à la partie ajustement dans la section précédente. c. Sans ou avec très peu de gaz. Les bouteilles de gaz propane sont parfois contaminées avec de l’air, en particulier les nouveaux réservoirs sur leur premier remplissage.
Page 45
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 L5 Series i12 Séries 45 Séries TABLEAU COMPARATIF DES PRODUITS ECCOTEMP En extérieur seulement A l’intérieur seulement Intérieur / Extérieur L5 Séries i12 Séries 45 Séries...
Page 46
RGA pour les réparations à effectuer. Veuillez contacter Eccotemp pour obtenir un numéro de RGA avant de renvoyer tout produit à Eccotemp. Ne pas le faire pourrait entraîner la perte du produit. Eccotemp ne sera pas responsable pour le remplacement en raison de perte ou de dommage si ces mesures ne sont pas suivies correctement.
Page 47
Eccotemp Systems LLC | Email: Support@eccotemp.com | Adresse: 315 - A Industrial RD Summerville, SC 29483 Garantie prolongée : Caractéristiques de la garantie : * Pas de tracas, remplacement complet de votre article s’il se casse. * La couverture commence après l’expiration de la garantie du fabricant.
