PART LIST—Model No. IETL15910
Note: To identify the parts listed below, refer to the EXPLODED DRAWING attached in the centre of this manual.
Key No. Qty.
Description
1
2
Foot Rail Insert
2
1
Right Foot Rail
3*
1
Idler Assembly
4
2
Isolator
5
1
Catch
6
1
Platform
7
2
Controller Screw
8
1
Walking Belt
9
2
Frame Pivot Bolt
10
1
Latch Assembly
11
1
Front Wheel/Pulley
12
1
Magnet
13
7
Front Wheel Nut/Frame Pivot Nut
14
2
Spacer Insert
15
2
Frame Pivot Spacer
16
1
Reed Switch Clip
17
1
Reed Switch
18
1
Lift Frame
19
4
Wire Clip
20
1
Idler Arm
21
1
Left Foot Rail Endcap
22
1
Motor Belt
23
1
Idler Pulley
24
1
Motor
25
1
Pulley Spacer
26
22
Screw
27
4
Hood Bracket
28
1
Pulley Nut
29
1
Idler Spring
30
2
Lift Motor Nut
31
1
Lift Motor Bolt (top)
32
2
Motor Bolt
33
1
Outlet Bracket
34
4
Plastic Stand-Off
35
1
Power Supply w/clips
36
1
Choke Bracket
37
1
Controller
38
1
Electronic Mounting Bracket
39
1
Motor Hood
40
5
Hood Screw
41
1
Motor Belly Pan
42
2
Belt Guide
43
10
Screw
44
13
Plastic Fastener
45
1
Frame Belly Pan
46
1
Lift Motor Bolt (Bottom)
47
1
Ground Wire
48
2
Rear Foot
49
4
Isolator Washer
50
4
Isolator Nut
30
R0601A
Key No. Qty.
Description
51
1
Chest Pulse Strap
52
4
Roller Adj. Washer
53
2
Rear Roller Adjustment Bolt
54
1
Rear Endcap
55
1
Frame
56
1
Allen Wrench
57
2
Rear Platform Screw
58
1
Rear Roller
59
4
Foot Screw
60
2
Frame Pivot Washer
61
2
Adj. Rod Spacer
62
1
Left Foam Grip
63
2
Handrail Endcap
64
1
Pulse Sensor
65
1
Upright
66
4
Base Mounting Screw
67
1
Lock Knob
68
1
Lock Knob Sleeve
69
1
Lock Knob Spring
70
1
Lock Pin Collar
71
1
Pin Clip
72
1
Lock Pin
73
2
Incline Pivot Bolt
74
1
Wire Harness Grommet
75
12
Console Screw (long)
76
2
Wheel Spacer
77
2
Front Wheel
78
2
Wheel Bolt
79
1
Right Foam Grip
80
1
Console Base (Top)
81
1
Console
82
1
Key/Clip
83
1
Console Base (Bottom)
84
1
Left Foot Rail
85
1
Upright Wire Harness
86
1
Shock
87
2
Upright Endcap
88
2
Pulley Washer
89
1
Right Foot Rail Endcap
90
1
Latch Warning Decal
91
1
Incline Motor
92
1
Audio Wire Nut
93
2
Incline Motor Spacer
94
2
Static Decal
95
2
Tie Holder
96
3
Tie
97
5
8" Cable Tie
98
2
Bumper
99
1
Choke
100
1
On/Off Switch
17. The heart rate monitor is not a medical de-
vice. Various factors, including the user's
movement, may affect the accuracy of heart
rate readings. The heart rate monitor is in-
tended only as an exercise aid in determining
heart rate trends in general.
18. Using the included hand weights and not hold-
ing the handrails may compromise your ability
to maintain your balance. Exercises using
hand weights should be attempted only by ex-
perienced users.
19. Never leave the treadmill unattended whilst it
is running. Always remove the key, unplug
the power cord, and move the on/off switch to
the off position when the treadmill is not in
use. (See the drawing on page 4 for the loca-
tion of the on/off switch.)
20. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 5, and HOW TO FOLD
AND MOVE THE TREADMILL on page 24.)
You must be able to safely lift 20 kg (45 lbs)
to raise, lower, or move the treadmill.
21. When folding or moving the treadmill, make
sure that the pin on the lock knob is inside of
the catch (see page 24).
22. When using iFIT.com CD's and videos, an
electronic "chirping" sound will alert you
when the speed and/or incline of the treadmill
is about to change. Always listen for the
"chirp" and be prepared for speed and/or in-
WARNING:
Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
The decals shown at the right (1) and below (2) have been-
placed on the treadmill. If the decal is missing, or if it is not
legible, please call our Customer Service Department to order
a free replacement decal (see HOW TO ORDER REPLACE-
MENT PARTS on the back cover of this manual). Apply the
decal in the location shown.
cline changes. In some instances, the speed
and/or incline may change before the per-
sonal trainer describes the change.
23. When using iFIT.com CD's and videos, you
can manually override the speed and incline
settings at any time by pressing the speed
and incline buttons. However, when the next
"chirp" is heard, the speed and/or incline will
change to the next settings of the CD or video
program.
24. Always remove iFIT.com CD's and videos
from your CD player or VCR when you are not
using them.
25. Inspect and tighten all parts of the treadmill
every three months.
26. Never drop or insert any object into any
opening.
DANGER:
27.
Always unplug the power
cord immediately after use, before cleaning
the treadmill, and before performing the main-
tenance and adjustment procedures de-
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorised service representative. Servicing
other than the procedures in this manual
should be performed by an authorised service
representative only.
28. This treadmill is intended for in-home use
only. Do not use this treadmill in any commer-
cial, rental, or institutional setting.
SAVE THESE INSTRUCTIONS
3
