Linn Majik DSM Quick Start

MAjIK DSM
QUICKSTART
Thank you for purchasing the Linn Majik DSM player. This guide provides basic un-
packing and connecting information to get you started - contact your Linn Specialist for
full installation support.
IMPORTANT:
Please refer to the printed Safety Information booklet for important safety information
and refer to www.linn.co.uk/majikdsm for further documentation and help on using
your Linn Majik DSM player.
Unpacking
• Remove product from packaging and place on a flat surface
• Please retain all packaging for future transport of Majik DSM
Contents
• 1 x Majik DSM player
• 1 x mains lead
• 1 x slimline infra-red (IR) handset (with 2 x CR2032 batteries)
• 1 x Safety Information booklet
Positioning
• Place unit on a flat, stable and rigid surface
• Place unit within range of your network router or switch
IMPORTANT:
Linn recommend the use of separate dedicated network components, includ-
ing router, switch and wireless access point. Alternatively, a dedicated integrated
router/switch/wireless device is preferable to simply connecting the unit directly
to your home broadband router. Linn do not recommend a wireless connection
between DS player and network. See www.linn.co.uk/networks for more info
• Avoid positioning the unit in direct sunlight as this can interfere with the infra-red
(IR) sensor on the front panel
• Do not stack components and avoid placing near other heat sources
• Do not block vents or site the unit in a cabinet which prevents air flowing from front
to back
• Allow at least 4" (10 cm) all the way around the unit for air circulation
Connecting
1. Connect each left and right channel on the Majik DSM to the equivalent terminal on
your loudspeaker using your preferred connection method (spade / banana plug / bare
wire) and ensuring a good tight connection is made in each case
2. Connect the Majik DSM Ethernet socket to your network using a standard Ethernet
cable
3. If you have any external sources you wish to connect to your Majik DSM, such as a
Blu-Ray or DVD player, satellite TV or games console, connect these to the appropriate
analogue, HDMI, SPDIF or TOSLINK IN socket.
• If connecting HDMI video sources to your Majik DSM, you
must also connect an HDMI cable from HDMI OUT back
to your display device to ensure video is displayed
4. Connect any additional source components to the back
panel using your preferred connection method - use
socket 4/PH for any turntable you wish to connect (and
do not connect line level source components to this
socket)
• Your Majik DSM is configured as an MM (Moving Magnet) phono stage as default -
please contact your Linn Specialist if you wish to change this to MC (Moving Coil) or
convert socket 4/PH to line level
5. Connect your mains cable but do not power on the unit yet
6. If you have a NAS or ripping NAS then you should also ensure this is connected to
your network and powered on ( see www.linn.co.uk/nas for more info)
