Summary of Contents for Fortinet FortiCam OB20
- Page 1 FortiCam OB20 QuickStart Guide...
- Page 2 Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests. Fortinet disclaims in full any covenants, representations, and guarantees pursuant hereto, whether express or implied.
-
Page 3: Table Of Contents
Table of contents Package contents Hardware installation Functions and indicators Technical specifications Register for support Cautions and warnings Regulatory compliance Fortinet Product License Agreement / EULA and Warranty Terms... -
Page 4: Package Contents
Package contents Your box should contain: FortiCam OB20 camera QuickStart Guide Shielding cover Water proof connectors Dry bag Screw bag Allen key QuickStart Shielding Cover Water Proof Connectors Dry Bag Screw Bag Allen Key Guide FortiCam OB20 QuickStart Guide Page 1... -
Page 5: Hardware Installation
Hardware installation FortiCam OB20 outdoor cameras can be mounted on walls using the accessory bracket (SKU: FCM-OB1-MNT), which can be ordered separately from Fortinet. For best results, choose a location where the cable can enter the wall or ceiling directly behind the camera (i.e. it does not run outside, along the surface), and where the camera is not easily reached. - Page 6 (1)Attach the bracket hinge to the side of the camera with two screws. (2)Push back the spring on the mortise lock and hook the camera onto the bracket. Connect all the cables to the camera through the bracket. Page 3...
- Page 7 Secure the two screws on the wall mount bracket. Attach the bracket to the plate and adjust the angle of the camera as desired. To connect the PoE cable The camera use PoE connection for data transmission and power supply. Make sure you have a PoE switch first.
- Page 8 Pin 1: Transmit out+ (Tx+) Pin 2: Transmit out- (Tx-) Pin 3: Receive In+ (Rx+) Pin 4: DC 48V Pin 5: DC 48V Pin 6: Receive in- (Rx-) Pin 7: GND 48V Pin 8: GND 48V Install the waterproof connector at the end of the PoE cable and connect the cable to the connector.
- Page 9 To reboot the camera On the camera, unplug the PoE cable. Or remove the lens cover, press and hold the reset button for 1 second. Reset Button To reset to factory default settings Press and hold the reset button for 10 seconds. Page 6...
-
Page 10: Functions And Indicators
Functions and indicators 1. IR LED (24pcs) 2. Lens 3. Light Sensor 4. RJ45 Connector 2 (For audio line in/out, RS485, DI/DO) 5. RJ45 Connector 1 (For Ethernet, 802.3at PoE Plus and 802.3af PoE) Page 7... -
Page 11: Technical Specifications
Technical specifications Hardware Specifications Format Indoor/outdoor, infrared night vision 2 mega-pixel, 1/2.8” Sony CMOS Sensor Type F1.3, 0.001 Lux (IR OFF, B/W), 0.002 Lux Iris (F1.4,Color) f = 3 mm–10.5 mm (motorized, autofocus) Focal Length View Angle H:90°–30° V:49°–17° D:103°–34° IRLED / IRC 15m / yes RTSP / HTTPS... - Page 12 Height x Width x 70 x 70 x 213 Length (mm) 2.43 lbs (1100 g) Weight Power PoE (802.3af or 802.3at) Power Required Power 8.6 watts (802.3af) or 18.2 watts (802.3at) Consumption (AVG) Compliance FCC Class B, CE Mark, weatherproof (IP67) Extension DI/DO Terminal: This is needed to connect the camera with external input/output devices.
-
Page 13: Register For Support
Register for support Register your Fortinet product to receive: • Technical support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles menaces La reistrazione ti permette di usufruire di: •... -
Page 14: Cautions And Warnings
Safety Mechanical Loading — To avoid personal injury or damage to the appliance, Fortinet recommends that 2 or more people together install the appliance into the rack. Balance the equipment to avoid uneven mechanical loading and tipping. Do not place heavy objects on the appliance. - Page 15 For products with RPS connections: The RPS connection is intended to be connected to the power source from Fortinet IEC certified/UL Listed equipment. The power rating of the product must be less than or equal to the output rating of the power source.
-
Page 16: Regulatory Compliance
Regulatory compliance Federal Communication Commission (FCC) – USA This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 17: Fortinet Product License Agreement / Eula And Warranty Terms
(except as provided in section 5 (“Transfer”) and section 15 (“Open Source Software”) below), non-exclusive, revocable (in the event of your failure to comply with these terms or in the event Fortinet is not properly paid for the applicable Product) license to use the Software... - Page 18 If you are a Fortinet contracted and authorized reseller or distributor of Products, you may transfer (not rent or lease unless specifically agreed to in writing by Fortinet) the Software to one end user on a permanent basis, provided that: (i) you ensure that your customer and the end user receives a copy of this...
- Page 19 Fortinet’s functional specifications. Except as otherwise agreed by Fortinet in writing, the replacement Software is provided only to the original licensee, and is subject to the terms and conditions of the license granted by Fortinet for the Software. The Software War- ranty Period shall extend for an additional ninety (90) days after any replacement software is delivered.
- Page 20 In the event of any disputes arising out of this Agreement or Fortinet’s limited warranty, the parties submit to the jurisdiction of the federal and state courts located in Santa Clara County, California, as applicable. 9. Limitation of Liability.
- Page 21 For any Open Source Software covered under the GPL, the source code is made available on this CD or download package. If any Open Source Software licenses require that Fortinet provide rights to use, copy or modify a Open Source Software program that are broader than the rights granted in this agreement, then such rights shall take precedence over the rights and re- strictions herein.
- Page 22 a) You must cause the modified files to carry prominent notices stating that you changed the files and the date of any change. b) You must cause any work that you distribute or publish, that in whole or in part contains or is derived from the Program or any part thereof, to be licensed as a whole at no charge to all third parties under the terms of this License.
- Page 23 those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Program. If any portion of this section is held invalid or unenforceable under any particular circumstance, the balance of the section is intended to apply and the section as a whole is intended to apply in other circumstances.
- Page 24 code for all modules it contains, plus any associated interface definition files, plus the scripts used to control compilation and installation of the library. Activities other than copying, distribution and modification are not covered by this License; they are outside its scope. The act of running a program using the Library is not restricted, and output from such a program is covered only if its contents constitute a work based on the Library (independent of the use of the Library in a tool for writing it).
- Page 25 tions of the Library will still fall under Section 6.) Otherwise, if the work is a derivative of the Library, you may distribute the object code for the work under the terms of Section 6. Any executables containing that work also fall under Section 6, whether or not they are linked directly with the Library itself. 6.
- Page 26 then as a consequence you may not distribute the Library at all. For example, if a patent license would not permit royalty-free redistribution of the Library by all those who receive copies directly or indirectly through you, then the only way you could satisfy both it and this License would be to refrain entirely from distribution of the Library.
