SERVICE MANUAL
SERVICE MANUAL
MBZE45 FLAGSHIP / EVER FRESH
MBZE45 FLAGSHIP / EVER FRESH
FULL NO FROST FRIDGE-FREEZER
FULL NO FROST FRIDGE-FREEZER
2005
2005
All the parts included in this document are the property of Indesit Company S.p.A.
All rights reserved. This document and the information it contains are supplied without liability for possi-
ble errors or omissions; no part of this document can be reproduced, used or copied without written
permission or without being authorised by the terms of a contract clause.
Service Manual
MBZE 45 - 2005
Edition
18.06.2005
G
Language
English
B
Advertisement
Table of Contents
Related Manuals for Indesit MBZE45
Summary of Contents for Indesit MBZE45
- Page 1 2005 2005 All the parts included in this document are the property of Indesit Company S.p.A. All rights reserved. This document and the information it contains are supplied without liability for possi- ble errors or omissions; no part of this document can be reproduced, used or copied without written permission or without being authorised by the terms of a contract clause.
- Page 2 CONTENTS OF THE MANUAL: NOTE FOR THE ENGINEER This manual is a supporting document for technical personnel. It contains a description of the various product types, the general operating principle, and indications concerning assistance. Technical personnel should anyway consult the specific model on (servicenet.indesitcompany.com) to access data and updates of electrical diagrams, technical bul- letins, and spare parts.
-
Page 3: Table Of Contents
CONTENTS 1. OPERATING LOGIC Product specifications EVER FRESH function/Display/Alarms Description of the Pneumatic Circuit 2. COMPONENTS 3. WIRING DIAGRAMS 9-11 4. ASSISTANCE 12-16 Disassembly Removing the HOME BAR Door Adjusting the HOME BAR Door Removing the HOME BAR Seal Removing the Fridge Door 13-16 Service Manual Edition... -
Page 4: Operating Logic
1. OPERATING LOGIC: 1.1. PRODUCT SPECIFICATIONS: NF EVER FRESH VFD User Interface Input-Output On FR door: 6 Buttons: (1) ON/OFF for switching appliance on and off; (2) EVER FRESH for activation and deactivation of EVER FRESH function; (3) ALARM RESET to reset alarms;... -
Page 5: Ever Fresh Function/Display/Alarms
1.2 EVER FRESH FUNCTION / DISPLAY / ALARMS: Select the vacuum position on the container cover and position the container in the central part of the shelf inside the fridge compartment (vacuum sta- tion) in correspondence with the mobile container- vacuum pump connection;... -
Page 6: Description Of The Pneumatic Circuit
1.3 DESCRIPTION OF THE PNEUMATIC CIRCUIT: The pump is connected to the vacuum station (under the glass shelf) by a 7 mm diameter silicone rubber hose lodged in the cabinet by embedding in foam and coupled to the shelf at the rear of the fridge wall The vacuum pump compartment also contains: 1 The vacuum switch responsible for detecting vacuum conditions inside the container and con-... -
Page 7: Components
2. COMPONENTS: EVER FRESH device. IThe EVER FRESH device fitted to Full No Frost fridge-freezer allows the user to store food for longer periods by pressing the relevant button on the dis- play and positioning the vacuum container in the specific area of the fridge compartment. - Page 8 HOME BAR device. There is a flap on the fridge door allowing the user to extract bottles from the door shelf inside the com- partment without opening the fridge door. The electrical wiring of the Home Bar door perim- eter heating element transits behind the control panel and inside the fridge door.
-
Page 9: Wiring Diagrams
3. WIRING DIAGRAMS: 3.1 MAIN WIRING DIAGRAM: Service Manual Edition Language MBZE 45 - 2005 2005.06.114 English... - Page 10 3.2 PNEUMATIC CIRCUIT: Service Manual Edition Language MBZE 45 - 2005 2005.06.114 English...
- Page 11 3.3 CONNECTION DIAGRAM: Service Manual Edition Language MBZE 45 - 2005 2005.06.114 English...
-
Page 12: Assistance
4. ASSISTANCE: 4.1. DISASSEMBLY: Removing the Home Bar Door: To remove the Home Bar door: 2. Insert a screwdriver into the channel in the fixing pins and force them inwards. N.B. When removing the door use caution because the 1. Remove the 6 screws securing the 2 arms spring could cause the pin to be ejected from its seat Adjusting the Home Bar Door: To adjust the opening force of the home bar door,... -
Page 13: Removing The Home Bar Seal
Removing the Home Bar Seal: The seal is glued to the door; if it needs replacing use single-component neutral cure silicone adhe- sive/sealant (e.g.: Dow Corning 7091) Removing the Display PCB: To gain access to the display PCB under the control panel window open the home bar door and undo the 2 screws at the bottom of the control panel window. - Page 14 2. Disconnect the wiring from the PCB and control panel connector. N.B.: When routing the connector through the hole in the instrument panel cover (and when re-inserting it) perform the operation as shown in the photos (1- 2-3) Service Manual Edition Language MBZE 45 - 2005...
- Page 15 4. Disengage the door from the hinge and lift N.B. Important: when refitting the pin in its seat, keep the door slightly raised and use a pair of long-nosed pliers. 3. Unscrew the pin with a 10 mm wrench, keeping the door slightly raised to facilitate the operation (e.g.
- Page 16 N.B. When refitting the wiring behind the con- trol panel ensure the cables are fitted correctly into their original locations Service Manual Edition Language MBZE 45 - 2005 2005.06.114 English...
- Page 17 Indesit Company viale Aristide Merloni, 47 60044 Fabriano - Italy tel. +39 0732 66 11 - telex 560196 - fax +39 0732 66 2954 - www.indesitcompany.com Service Manual Edition Language MBZE 45 - 2005 2005.06.114 English...
