Page 1: Service Manual
HTN19R12/HTN19R12S COLOUR TELEVISION Service Manual MODEL : HTN19R12/HTN19R12S (America) ■ Features 48cm super flat picture tube Auto search 181 program presetting and memory CCD & V-CHIP Haier Group Edition:2004/4/17 NO:M-MR-AE-HTN19R12-76814... -
Page 2: Table Of Contents
CONTENT CONTENT Contents…………………………………………………………………….1 Product code illumination and series introduction…………………2 3． ． ． ． Features…………………………………………………………………..3 4． ． ． ． Safety Precaution……………………………………………………….4 5． ． ． ． Warning and cautions…………………………………………………..5 6． ． ． ． Net Dimension…………………………………………………………..11 7． ． ． ． Parts and Functions……………………………………………………12 8．... -
Page 3: Product Code Illumination And Series Introduction
Product code illumination and series introduction 2. Product code illumination and series introduction HTN 19 R12 Color television appearance Appearance serial CRT catercorner 20inch (51cm) BRAND... -
Page 4: 3． ． ． ． Features
FEATURES 3. FEATURES 序号 序号 序号 序号 序号 序号 序号 序号 FUNCTION FUNCTION NO. of built-in speakers Main IC 76814 Audio output power(W) flat picture Total power input（W） Color system NTSC3.58 Voltage range（V） 120V Audio system Power frequency（Hz） 60HZ NO.of channels Time of sleep timer(MINS) 120MIN OSD language... -
Page 5: 4． ． ． ． Safety Precaution
SAFETY PRECAUTIONS 4. SAFETY PRECAUTIONS INPORTANT SAFETY NOTICE These parts are identified by many electrical and mechanical parts in this chassis have special safety-related characteristics. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards. -
Page 6: 5． ． ． ． Warning And Cautions
Warning and Cautions 5． ． ． ． Warning and Cautions 1. When you clean the TV set, please pull 4. To prevent the TV set from firing and out the power plug from AC outlet. Don't electric shock, don't clean the cabinet and the screen with make the TV set rain benzene, petrol and other chemicals. - Page 7 Warning and Cautions Explanation on the display tube Generally, it is not needed to clean the tube surface. However, if necessary, its surface can be cleaned with a dry cotton cloth after cutting off the power. Don’t use any cleanser. If using hard cloth, the tube surface will be damaged.
- Page 8 Warning and Cautions all solid-state device heat sinks are correctly installed. 8. Always connect the test receiver ground lead to the receiver chassis ground before connecting the test receiver positive lead. Always remove the test receiver ground lead last. 9. Use with this receiver only the test fixtures specified in this service manual. CAUTION: Do not connect the test fixture ground strap to any heat sink in this receiver.
- Page 9 Warning and Cautions General Soldering Guidelines 1. Use a grounded-tip, low-wattage soldering iron and appropriate tip size and shape that will maintain tip temperature within the range of 500 F to 600 2. Use an appropriate gauge of RMA resin-core solder composed of 60 parts tin/40 parts lead.
- Page 10 Warning and Cautions Carefully bend each IC lead against the circuit foil pad and solder it. Clean the soldered areas with a small wire-bristle brush.(It is not necessary to reapply acrylic coating to the areas). “Small-Signal” Discrete Transistor Removal/Replacement Remove the defective transistor by clipping its leads as close as possible to the component body.
- Page 11 Warning and Cautions 1. Clip each fuse or resistor lead at top of the circuit board hollow stake. 2. Securely crimp the leads of replacement component around notch at stake top. 3. Solder the connections CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures.
-
Page 12: 6． ． ． ． Net Dimension
Net Dimension 6． ． ． ． Net Dimension Figure 2... -
Page 13: 7． ． ． ． Parts And Functions
Parts and Funcitions 7． ． ． ． Parts and Funcitions Front and side panel of the TV set POWER EARPHO NE VIDEO AUDIO TV/AV MENU VO LUME CHANNEL Figure 3 When using S terminal, please pull out video 1 input terminal... -
Page 14: 8． ． ． ． Remote Controller Functions
Remote Controller Functions 8. Remote Controller Functions M EN U VOL- VOL+ DISPLAY RECALL TV/AV RATING MUTE P.STD SLEEP Figure 4... -
Page 15: 9． ． ． ． Program Diagram
Program Diagram 9. Program Diagram I. Features HTN19R12 color TV sets (designed for the US market) incorporate the monolithic integrated circuit LA76814K developed by SANYO in 1999 and the CPU LC863432B-535A designed for LA76814K control. LA76814K intergrates the sound accompany filter and trap filter in the chip, resulting in minimized application of peripheric components, maximized integtration and reliable performance. - Page 16 Program Diagram 8. Sound noise limit sensitivity: VHF≤39dB（μV） UHF≤42dB（μV） ≥2W 9. Sound output power: 10. X-ray radiation value: <0.1mR/Hr 11. Voltage: AC 100～130V ≤70W 12. Energy consumption: 13. Net dimensions: 472mmX445mmX432mm 14. Net weight: 17.5Kg 2. User’s instructions Note: This TV set has been installed a caption decoder and control to US Federal Communications Commission. Customized Power On setup This TV set is designed for customized initiation.
- Page 17 Program Diagram CONTRAST Contrast increase Contrast decrease BRIGHT Brightness increase Brightness decrease COLOR Color increase Color decrease SHARP Sharpness increase Sharpness decrease TINT Tint increase Tint decrease 4． Press MENU button again to quit the main MENU. SETUP 1． Press SETUP button, the main menu will appear on the screen. 2．...
- Page 18 SPECAIL 1． Press MENU button Press MENU button Press MENU button and the main menu appear on the screen. 2． Press CH+ or CH- button to move the icon to SPECIAL, and designate C.CAPTION. Then icon of C.CAPTION turns to bright green. When OFF is displayed, C.CAPTION is inactivated while when ON is displayed, C.CAPTION is activated.
- Page 19 Program Diagram CH- to search up and down for relative items. If MENU button is pressed again, OPTION MENU will appear. 5． When NO-INFO RATING is selected, press MENU button for option of UNBLOCK or BLOCK state. 6． When NO RATED is selected, press MENU button for option of UNBLOCK or BLOCK state. 7．...
- Page 20 Program Diagram 5. Items under or above the designated icon in the submenu can be selected. 6. Press RATING button again to quit V-CHIP menu. BLOCK OFF 1． Press RATING button, and the RATING main menu will appear on the screen. 2．...
-
Page 21: Maintenance Service And Trouble Shooting
Maintenance Service and Trouble Shooting 10. Maintenance Service and Trouble Shooting 1 TROUBLESHOOTING PROCESS No light and sound Check to see if Fuse3 is normal Abnormal Normal Check to see 103V Check VD504, C507, etc. voltage is normal V513, etc. Normal Abnormal Check to see if the... - Page 22 Maintenance Service and Trouble Shooting No raster Whether G2 voltage is normal Abnormal Normal Check heating voltage Check base voltage H-drive Normal Abnormal Normal Abnormal Heater Resistor Check to see if b.e Check the circuit Check the voltage open voltage of V433 is from pin13 of N201 to of all pins of XP902 existed?
- Page 23 Maintenance Service and Trouble Shooting Horizontal bright line Make R451 open. Multimeter is at range RΧ1K. Red probe connects to ground. Touch No.5 of N401 with black probe. Bright line flashes for a moment There is trouble in V-output circuit There is trouble in V-circuit Check Check the voltage at Pin2 of N401...
- Page 24 Maintenance Service and Trouble Shooting Lack of red Check to see if V902 is open or not well welded Change V902 or Check to see if voltages of XP902 weld V902 again are normal Replace CRT、 Check ircuit between Pin19 of N201 and XS202 Picture exists but no sound Cut of C601，connect red pen of multi-meter(R*1K)with...
-
Page 25: Circuit Diagram
Circuit Diagram 11. Circuit Diagram Pane hint picture Sound Power Amplifier Picture/Sound IF Amplifier, Video and audio signal Processing, RGB Output Circuits and H &V Sync pulse Horizontal Scan segregation Output Vertical Scan Output Main Processor Audio/Video In/Out Infrared Receiver Remote Controller Figure 5... - Page 27 PCB Diagram PCB Diagram Figure 8...
-
Page 28: Circuit Explanation
Circuit Explanation 12. Circuit Explanation 1. Principle integrated circuits A1. HTN19R12 color TV set composed of the following sections (1) Small signal processing: super monolithic integrated circuits N204(LA76814A). and memory N901 (AT24C08). (2) Sound power amplifying: integrated circuits N701 ( LA4525). - Page 29 Circuit Explanation Blank Earth MUTE control 0.02 Crystal oscillation port 2.75 Blank 5.07 Crystal oscillation port Power (+5V) AV option control 2 0.01 Plate control input 0.25 Av option control 1 0.01 AFT signal input Control signal input Right channel sound volume Blank 0.01 PWM output port...
- Page 30 Circuit Explanation CHROMA AFC-F 4.94 3.49 FM filter 1.90 0.54 AFT output CW：3.58MHz OUT Circuit Explanation 2.77 2.87 Data bus Auto color filter 4.85 Clock bus 4.76 2.43 Beam input Video output option 3.92 R input 0.14 2.55 input Outside video input 0.15 input Power...
- Page 31 Circuit Explanation 2. Notices for adjustment Range Ref. B/W BALANCE S-BRI 0-127 R-BIA 0-255 G-BIA 0-255 B-BIA 0-255 R-DRV 0-127 G-DRV 0-15 B-DRV 0-127 C. B/W ADJUST H. PHASE 0-31 H.BLK.LEFT H.BLK.RIGHT V. SIZE 0-127 V. LINE 0-31 V. POSE 0-63 V.
- Page 32 Circuit Explanation GRAY MOD (0/1) Description Range Ref. B.GAM.SEL (0~3) RG.GAM.DEF (0/1) FBPBLK.SW (0/1) BRIGHT ABL.TH Bright. Abl. Threshold (0~7) EMG.ABL.DEF Emg. Abl. Def (0/1) BRT.ABL.DEF Brt. Abl. Def (0/1) MID.STP.DEF Mid. Stp.Def (0/1) R-Y/B-Y G.BL R-Y/B-Y Gain Balance (0~15) 0-15 LA76814, no this function R-Y/B-Y ANG...
- Page 33 Circuit Explanation BAND SELECT 3.Circuit signals processing (1) MF amplifying circuit Received by antanna and processed by the high frequency tuner, the television signals will be transmitted by the tunner as 45.75MHZ signals to sound surface filter through C112 coupling after being amplified by V102, and then the MF signals of trapped wave in sound carrier wave from sound surface filter F45U will be sent to pin 5 and 6 of LA76814.
- Page 34 Circuit Explanation high pressure, screen grid and focus voltages, the transformer provides 180V video amplifier voltage by winding 2. VD411, C411, R412, VD412, R414 and C412 form the X ray protection circuit. R233, C231, R232, R403 and C408 form the beam restriction circuit. The winding 9 of the transformer provides CRT filament voltage.
- Page 35 Circuit Explanation 1. N701 LC863424B Leads Function Voltage (V) Leads Function Voltage (V) Auto adjust Enable Pin OSD red signal output 0.09 Blank OSD greem signal output 0.09 IIC data OSD blue signal output 0.09 IIC clock OSD blank signal output 0.01 Earth Blank...
- Page 36 Circuit Explanation Reference current FM filter output 2.23 1.69 AGC filter 2.22 Clock output 0.002 Hi AGC output 2.59 N.C. 0.002 MF input 1.30 OSD gain control 3.05 MF input 2.83 Earth Earth 2.83 X ray protection 0.06 Power ACC KILLER FILTER 0.39 FM filter 4.94...
-
Page 37: Adjustment
Adjustment 13. Adjustment 1. Safety precautions 1. It is safe to adjust after using insulating transformer between the power supply and chassis input to prevent the risk of electric shock and protect the instrument. 2. Never disconnect leads while the TV receiver is on. 3. -
Page 38: Information Of Resistors And Capacitors
Information of Resistors and Capacitors 17. Information of Resistors and Capacitors RESISTORS & CAPACITORS-PARTS NO.CODE Notes: 1.part numbers are indicated on most mechanical parts. Please use this part number for parts orders. 2.The unit of resistance is Ω(ohm).K=1000Ω,M=1000KΩ 3.The unit of capacitance is μF(microfarad). P=10 μF. -
Page 39: Terminal View Of Transistors
Information of Resistors and Capacitors Terminal view of transistors 2SC1815-Y------F 2SC4544----B-A 2SA1015-Y------F 2SB1569A-E----B-A EXPORT 2SC752GTM-Y------F EXPORT 2SP2400A-E----B-A EXPORT 2SC2878-A(TEM)------F EXPORT 2SC3853(2SC3852)----E-A RN1204(DTC144ESATP) EXPORT KSR1010TA 3DD2553----B-A 2SA562TM-Y------F KSR2010TA 3CA688----E-A 2SC3355------F EXPORT 2SC3853(2SC3852)----B-A 2SD18887YD Figure 11... - Page 40 Sincere Forever group Tel：86-532-8938356 Web site：http：//www.haier.com...
