Asus Terminator 2 Barebone System T2-AH1 Product Manual page 79

7 . 7 . 7 . 7 . I D E c o n n e c t o r ( 4 0 - 1 p i n I D E ) I D E c o n n e c t o r ( 4 0 - 1 p i n I D E ) I D E c o n n e c t o r ( 4 0 - 1 p i n I D E )
7 . I D E c o n n e c t o r ( 4 0 - 1 p i n I D E ) I D E c o n n e c t o r ( 4 0 - 1 p i n I D E )
This connector is for an Ultra DMA 100/66 signal cable. The Ultra DMA
100/66 signal cable has three connectors: a blue connector for the
primary IDE connector on the motherboard, a black connector for an
Ultra DMA 100/66 IDE slave device (optical drive/hard disk drive), and
a gray connector for an Ultra DMA 100/66 IDE master device (hard disk
drive). Refer to the hard disk documentation for the jumper settings.
• Pin 20 on the IDE connector is removed to match the covered hole
on the Ultra DMA cable connector. This prevents incorrect insertion
when you connect the IDE cable.
• Use the 80-conductor IDE cable for Ultra DMA 100/66 IDE devices.
IDE connector
8 . 8 . 8 . I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D ) I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D )
8 . 8 . I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D ) I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D ) I n t e r n a l a u d i o c o n n e c t o r s ( 4 - p i n A U X , C D )
These connectors allow you to receive stereo audio input from sound
sources such as a CD-ROM, TV tuner, or MPEG card.
Internal audio connectors
A S U S T 2 - A H 1 A S U S T 2 - A H 1 A S U S T 2 - A H 1 A S U S T 2 - A H 1 A S U S T 2 - A H 1
NOTE: Orient the red markings
(usually zigzag) on the IDE
ribbon cable to PIN 1.
PIN 1
AUX CD
(White) (Black)
4 - 7 4 - 7 4 - 7 4 - 7 4 - 7
