- Page 1 A m e r i c a n V i d e o E q u i p m e n t 1617 E. Richey Road • Houston, Texas 77073 Phone: (281 )443-2300 • Fax: (281) 443-8915 AVE is on-line! E-mail us at aveus@ibm.net or visit AVE’s web site at www.americanvideoequipment.com...
-
Page 2: Time And Date
RT-195 Event Recorder The RT-195 is AVE’s newest addition to our Mobile VCR product line. The RT-195 is a low cost, 12VDC mobile event recorder with interactive on-screen programming. The features of the RT-195 include: •Time and Date •20 character title •Recycle Record... - Page 3 RT-195 IR Remote Control The RT-195 is programmed with the VCR’s IR Remote Control. The IR remote still maintains its normal functions, but when the On- screen programming mode is entered, several buttons take on alternate roles. 1 STOP: Press and hold the STOP button for approximately 5 seconds to access the main programming menu of the RT-195.
- Page 4 RT-195 Connections The RT-195 requires the use of composite video. To see the on- screen programming menu, you must have a video camera in and a monitor connected. The audio and video jacks are standard RCA type jacks. You will need to use RCA to BNC adapters when using standard CCTV cameras with BNC connectors.
- Page 5 RT-195 On-screen Programming The RT-195 can be programmed via the included IR remote con- trol. You will need a video source in and a monitor connected to be able to see the programming menu. To access the programming menu of the RT-195 VCR, Press and hold the STOP button for approximately 5 seconds.
- Page 6 Then press and release P/S and the Title Display will appear. Programming a Title The RT-195 provides you with the option of displaying a 1 line by 20 character title. This will appear as one line of 20 solid blocks, with the first block flashing.
-
Page 7: Programming Record
S button and your choice will disappear and you can con- tinue programming other features. Power-up Rec The POWER-UP REC option will allow the RT-195 to go into the RECORD mode when power is applied. (Of course, a blank tape must be in the VCR.) The choices for this feature are: ON or OFF. - Page 8 Master/Slave This feature allows the use of multiple RT-195's to be used in applications where you need real time continuous recording with out interuption for more than 8 hours. Using 3 RT-195's in this configuration will allow for 24 hour real-time record- ing.
- Page 9 RT-195 Master/Slave Connection Diagram Conn ect any number of RT-195's together following the diagram below. Program each VCR's Master/Slave option to ON in the main programming menu. Place a tape in each machine and start the first VCR recording. When the first VCR reaches the end of its tape it will automatically start the next VCR to record.
- Page 10 The arrow should be pointing to ALM REC DWELL, which is a feature used in conjunction with the alarm input jack on the rear of the VCR. If you supply the RT-195 a contact closure, the VCR will alarm record for the length of time set in the ALARM RECORD DWELL menu.
-
Page 11: Display Setting
option. SP is the standard, and is the default setting for the RT- 195. If you wish to change the speed to EP, first select TAPE SPEED with the (-) or (+) button, then press and release P/S and you will see the setting displayed. (-) or (+) toggles back and forth between settings. -
Page 12: Master Reset
2 DO A MASTER RESET and press and release the P/S button. You will be presented with a copyright notice which lists the software version for the RT-195. This will go away after a few seconds and the Time/Date display will appear reset back...
