SONIQ IM350GK Instruction Manual

iM350GK
GETTING STARTED
Thanks for choosing Cube Clock Radio
Please keep this instruction manual for future reference.
Enhance Your Enjoyment of the Music stored on Your iPod :
* Powerful built-in 2.0, 1W * 2 Speakers system
* Docking station for your iPod
* FM Radio
* Digital clock display with dual alarm function
* Wake to iPod, radio, or buzzer
* User-friendly backlit LCD screen
* Integrated universal dock for your iPod
* Charges your iPod
* Aux In allow your listen to music from other Audio devices.
Product Accessories
* Stereo Audio * AC Adapter * Instruction Manual * Warranty Card
* Hotline Card
* Made for iPod Classic, iPod Nano 3G, iPod Touch, iPod Nano 2G,
iPod Nano, iPod 5G (Video), iPod Photo only.
GETTING STARTED
Installing the AC adapter
Locate the AC adapter jack on the back of the unit. Insert the AC
adapter cable into this jack, and then plug the AC adapter into the
wall outlet.
Installing the Backup Battery for Clock and Alarm Settings
In order to offer consistent clock settings and alarm functions, the
unit uses a backup battery system. This means that in the event of a
power failure, all the settings of unit will remain saved. For example,
after the installation of the Backup Battery, the AC cord is
disconnected or a power failure occurs, the display will NOT remain
lit, but the time and date settings will be temporarily maintained. The
alarm, however, will not sound when the unit is powered only by the
Backup Battery. To install Backup Battery, follow the instructions
below.
1. Make sure the connection between the DC adapter and the unit is
secure. This is important because during battery replacement it is
possible for all settings to be lost if clock and alarm have already
been set.
2. Locate the battery compartment on the bottom of the unit and
open.
3. Insert 2 "AAA" batteries, following the correct polarity(+/-)
drawings inside the battery compartment. For longer battery life,
alkaline batteries are suggested. Please note that new and used
batteries should not be mixed. Likewise, alkaline, standard (carbon-
zinc) or rechargeable (nickel-cadmium) batteries should not be used
together.
GETTING STARTED
The Cute Cube has Three modes: iPod, AUX, Radio. You can choose
the mode you need by pressing the Standby/Source button,
accordingly the LCD screen will light the indicator. To adjust Cute
Cube into Standby, by pressing and holding Standby/Source .
Caution: Please put battery into the battery compartment, batteries
are used for keeping setting memory in your Cute Cube.
Setting Clock
1. Under standby, press /time/mem button until Time display
flashes.
2. Press Up/Tune- to increase Hour, press Down/Tune+ to increase
Minute.
3. Please wait for seconds to secure the time setting.
Setting Alarm
This unit supports two alarm settings for dual alarm feature.
1. To set alarm1, press /time/mem button two times under standby,
until the display begins to flash and alarm1 indicator displayed,
press Up/Tune- to increase Hour, press Down/Tune+ to increase
Minute.
3. To choose the alarm method, after choosing alarm time, press vol-
/al1 to light the indicator of each alarming method such as Radio,
iPod Dock, Buzzer.
4. To set alarm2, press /time/mem button three times under
standby, until the display begins to flash and alarm2 indicator
displayed, press Up/Tune- to increase Hour, press Down/Tune+ to
increase Minute.
5. To choose the alarm method, after choosing alarm time, press
vol+/al2 to light the indicator of each alarming method such as
Radio, iPod Dock, Buzzer.
6. To exit setting alarm, press /time/mem botton until the display
stop flashing.
7. Alarm1 and Alarm2 indicator displayed on LCD screen means
alarm is ready.
8. To preset the volume level when the alarms are activated, use the
volume "+" "-" buttons to adjust the volume level.
OPERATIONAL INSTRUCTIONS
Locations On the Main Unit
1. Standby/Source 6. Up / Tune -
2. Vol+ / Alarm 2 7. Ipod dock station
8. Snooze / Sleep
3. Down / Tune+
9. DC 5V IN
4. Play / Pause / Time setting / Mem
10. AUX IN
5. Vol- / alarm 1
11. Battery compartment
Location On LCD screen
9. ST indicator
1. Alarm 1 armed
10. Time / alarm indicator
2. Alarm 2 armed
11. FM indicator
3. Wake to radio
12. MHZ indicator
4. Wake to buzzer
13. FM freqency
5. Wake to ipod
14. CH indicator
6. Aux mode
15. MEM indicator
7. Ipod dock mode
16. Volume indicator
8. Radio mode
OPERATIONAL INSTRUCTIONS
Listening to Your Favorite Songs on iPod
1. To listen to music, make sure that your iPod is playing and inserted
into the built-in universal dock correctly. It will then automatically
turn ON and music will begin to play.
2. To pause music, press the /time/mem button during the play
mode. To resume playback, press it again.
3. To adjust volume, press Volume+ and Volume- button on Cute
Cube.
4. To go to the Next or Previous track, use the Up or Down button on
Cute Cube. To search the current track using high speed forward or
rewind, press and hold Up or Down while track is playing.
5. To turn the unit off, press and hold the Standby/Source button. If
