INSTALLATION INSTRUCTIONS

This air conditioner uses the new refrigerant R410A.
Contents
- Multi Split system air conditioner -
Page
Combine indoor and outdoor units only as listed
below.
Indoor Unit
MCAF78MR5I
MCAF98MR5I
MCAF128MR5I
MCAF188R5I
MCAF248R5I
Power Source:
50 Hz, single-phase, 220 - 240 VAC
Combinations of indoor and outdoor units
Connect indoor and outdoor units only in the
combinations listed in the catalog or installation
manual.
CAUTION
Connecting any other model may result in
operation failure and system damage.
Be sure to read the yellow instruction sheet
attached to the outdoor unit for models using the
new refrigerant R410A.
NOTE
The illustrations are based on the typical appearance
of a standard model. Consequently, the shape may
differ from that of the air conditioner that you are
installing.
12/2007
For Indoor Unit
COOL / DRY/ HEAT Model
Model Combinations
Outdoor Unit
GRF148MR5I
GRF198MR5I
GRF248MR5I
GRF318MR5I
