Meyer Sound HD-2 Specification Manual

HD-2
The Meyer Sound HD-2 is a high-defi-
nition monitor system that is suitable for
a wide variety of critical mid-field moni-
toring applications. Itis optimized to ap-
proximate a true point-source radiator
within its coverage area, with a frequency
response of 32Hz to 22 kHz (-3dB points) .
Each unit is individually calibrated, and is
available in both a wide horizontal cover-
age (HD-2w) and a narrow horizontal
coverage (HD-2n) version.
The HD-2 comprises a 10-inch cone
low-frequency driver and 1-inch high-fre-
quency driver housed in a vented cabinet.
An active crossover, optimized pole-zero
response correction filters, loudspeaker
element protection circuitry and dual
power amplifiers are built directly into
the enclosure.
High Definition
Mid-Field Monitor
Both HD-2 drivers are of a proprietary
design and are individually factory-tested
and selected for maximum linearity. The
high-frequency horn driver is of an en-
tirely new configuration, employing a tita-
nium dome and silk suspension in a pat-
ented, low distortion design. It is coupled
to a modified radial horn in the HD-2w,
and to a unique aspherical waveguide in
the HD-2n.
The HD-2's power amplifiers utilize
complementary power MOSFET output
stages in a class AB configuration. Input
sensitivity is switchable to either +4 dBu
or -10 dBV. A magnetically shielded ver-
sion is available on special order.
Features
Self-powered
Two-way biamplified
Controlled directivity
Individually factory-aligned
Patented horndriver
Ultra-low distortion
Patented response alignment
Applications
Music recording
Compact Disc™ mastering
Project studios
Surround sound dubbing
Broadcast control rooms
Meyer Sound Laboratories, Inc.
2832 San Pablo Avenue
Berkeley, CA 94702
(510) 486-1166
FAX (510) 486-8356
