Laws. LG-Ericsson reserves the right to make changes in specifications at any time without notice. The information furnished by LG-Ericsson in this material is believed to be accurate and reliable, but is not warranted to be true in all cases.
LIP-8012E/24E/40E Quick Guide Regulatory information European Union Declarations of Conformity LG-Ericsson Co., Ltd. declare that the equipment specified in this document bearing the “ CE” mark conforms to the European Union Radio and Telecommunications Terminal Equipment Directive(R&TTE 1999/5/EC), including the Electromagnetic Compatibility Directive(2004/108/EC) and Low Voltage Directive(2006/95/EC).
Page 4
LIP-8012E/24E/40E Quick Guide Figure LIP-8024E *The Button names and layout may be a bit different among LIP-8012E/24E/40E. For more detailed information, refer to the User guide each model. Fixed Feature Button Definitions DND – Blocks all incoming calls; red LED illuminates.
LIP-8012E/24E/40E Quick Guide LIP Keyset User Operation The following is provided as quick reference for commonly used features/functions. Complete instructions are included in the User Guide. Placing a Call: ICM Line – Lift handset or press SPEAKER button. Dial the extension number from the keypad.
LIP-8012E/24E/40E Quick Guide Answering a Call while idle: ICM Line – Lift handset, or if in HF mode, just speak. CO Line – Lift handset, and press flashing Flex button (as needed). MUTE - (toggle) press to STOP sound on a call.
LIP-8012E/24E/40E Quick Guide (iPECS-CM/MG) Place a call to first member. If first member answer, press Conference flexible button and place a call to second member. * For conference more than 4 members, VPCM board is needed. * For conference members, VOIB(VOIU) board is always needed in iPECS-MG.
Page 8
LIP-8012E/24E/40E Quick Guide Delete Call Forward: Lift handset or press SPEAKER button. Press the FWD soft button. Dial #. Call Transfer: While on an active call, press the TRANS/PGM button. Place call to the transfer destination.
LIP-8012E/24E/40E Quick Guide Adjust LCD Contrast: While idle, press the VOL buttons to change the screen contrast (brightness level). (iPECS-CM/MG) Press MENU button. Dial 12. (Set Contrast) Press the VOL buttons to change the screen contrast.
Page 10
LIP-8012E/24E/40E Quick Guide LIP-8012E/24E/40E Installation Note: LIP-8012E/24E/40E Gigabit Phone can be powered by either AC adaptor or Power over Ethernet (PoE, class 2). To use AC power, use only the LG-Ericsson Approved AC power adaptor, which you can order separately. To use PoE, your connected LAN must support PoE.
Page 11
LIP-8012E/24E/40E Quick Guide Code Function Send Message Inbox Network Configuration Attendant Network Configuration Flex Button Program Press the TRANS/PGM button. Press the flexible button to be programmed. Press TRANS/PGM button and User Program Code (refer to table).
Page 12
LIP-8012E/24E/40E Quick Guide Code Function Remark Station Wait Retrieve CLI/IP Message Wait Retrieve Authorization Code (Password) Entry Input up to 12 digits DID Call Wait Button Message Wait in Exec/Sec Pair Send SMS Message Register Mobile Ext. Activate Mobile Ext.
Page 13
LIP-8012E/24E/40E Quick Guide Code Function Remark MONITOR Button REDIAL Button FWD Button PTT Button Requires room number(01~10) In-Room Indication Button Hot Desk LOGin Code Hot Desk LOGout Code Force FWD to Dest. Register Bluetooth Bluetooth Usage System User Program Codes (iPECS-CM/MG)
Page 15
LIP-8012E/24E/40E Quick Guide System User Program Codes (SBG) Code Function Remark Intercom Answer Mode Select ICM Signal mode, 1:HF, 2:Tone, 3:Privacy Headset/Speakerphone mode 0:H, 1:S Select Headset Ring type 1:S, 2:H, 3:Both Set Wake-Up Time Once/Permanent & Hour/Min Erase Wake-Up Time...
