LED TV
Installation manual
Thank you for purchasing Samsung product.
To receive more service, please register your
product at
www.samsung.com/register
Model
Serial No.

Advertisement

Table of Contents
loading

Related Manuals for Samsung 690

Summary of Contents for Samsung 690

  • Page 1 LED TV Installation manual Thank you for purchasing Samsung product. To receive more service, please register your product at www.samsung.com/register Model Serial No.
  • Page 2 Failing to do so may result in a fire or problems with the TV caused by an increase in its internal temperature. ✎ When using a stand or wall-mount, use parts provided by Samsung Electronics only. – If you use parts provided by another manufacturer, it may cause a problem with the product or cause the product to fall, leading to serious injury.

  • Page 3: Table Of Contents

    Contents y Accessories ............................. 4 y Installing the LED TV Stand ........................5 y Using the TV's Controller ......................... 7 y The Connection Panel ..........................8 y The Remote Control ..........................10 y Connecting to the Network ........................12 y Connecting the TV to an SBB or STB ...................... 14 y Connecting the Bathroom Speakers ......................

  • Page 4: Accessories

    Accessories ✎ Please make sure the following items are included with your LED TV. If any items are missing, contact your dealer. ✎ The items’ color and shape may vary, depending on the model. ✎ The parts for the stand are listed under Stand Components on the following page. List of Parts Remote Control Data Cable...

  • Page 5: Installing The Led Tv Stand

    Installing the LED TV Stand Components When installing the stand, use the provided components and parts. B 1 EA 1 EA x8 (M4 X L14) Stand Guide Stand Screws x4 (M4 X L14) ✎ Place a soft cloth over the table to protect the TV, and then place the TV on the cloth screen-side down.
  • Page 6 x4 (M4 X L14) ✎ Progress the assembly of screw in the manual’s order. ✎ NOTE – Make sure to distinguish between the front and back of each component when assembling them. – Make sure that at least two persons lift and move the TV. English...

  • Page 7: Using The Tv's Controller

    Using the TV's Controller ✎ The color and shape of the TV Controller may vary depending on the model. ✎ The TV's Controller, a small joy stick like button on the bottom right side of the TV, lets you control the TV without the remote control.

  • Page 8: The Connection Panel

    The Connection Panel EX-LINK VOL-CTRL AUDIO IN HDMI IN 3 (ARC) HDMI IN 1 (DVI) HDMI IN 2 DIGITAL AUDIO OUT (OPTICAL) AUDIO ✎ Whenever you connect an external device to your TV, make sure that power on the TV and the device is turned off. ✎...
  • Page 9 HDMI 1.2 version, contact to the Samsung customer care center. Refer to page 52 for the information of the Samsung customer care center. ✎ Use a cable shorter than 10 feet (3m) to get the best UHD viewing quality.

  • Page 10: The Remote Control

    The Remote Control ✎ This remote control has Braille points on the Power, Channel, and Volume buttons and can be used by visually impaired customers. Display and select the available video Turns the TV on and off. sources. Press to directly access channels. Press to select additional digital channels being broadcast by the same station.
  • Page 11 Installing batteries (Battery size: AAA) Match the polarity of the batteries to the symbols in the battery compartment. After you have installed the batteries, use a screwdriver to screw in the screw that holds the battery cover closed. ✎ NOTE –...

  • Page 12: Connecting To The Network

    Authentication Modes: WEP, WPAPSK, WPA2PSK y Encryption Types: WEP, TKIP, AES In compliance with the newest Wi-Fi certification specifications, Samsung TVs do not support WEP or TKIP security encryption in networks running in the 802.11n mode. If the wireless router supports WPS (Wi-Fi Protected Setup), you can connect the TV to your network using PBC (Push Button Configuration) or a PIN (Personal Identification Number).
  • Page 13 Network Connection - Wired There are three main ways to connect your TV to your network using cable, depending on your network setup. They are illustrated below: External Modem The Modem Port on the Wall TV Side Panel (ADSL / VDSL / Cable TV) Modem Cable (Not Supplied) LAN Cable (Not Supplied) TV Side Panel...

  • Page 14: Connecting The Tv To An Sbb Or Stb

    Connecting the TV to an SBB or STB TV Rear Panel ETH MODEM Data Cable 1. Connect the DATA jack of the TV to the ETH MODEM jack of the STB (SBB) with the Data cable. ✎ The "ETH MODEM" jack name that you connect the Data Cable to may differ depending on the SBB or STB type. English...
  • Page 15 Contact your nearest dealer or your SI Vendor to buy the data cable not included in the TV. Confirm the code on the Code Label Note the labeled end. Note the labeled end. SI Vendor Cable code Pin assign Remark Samsung BN39-00865B Provided Enseo Guest-Tek NXTV nStreams Sonifi BN39-01011E...
  • Page 16 Connecting the Audio Output to an Audio Amplifier ¦ TV Rear Panel AUDIO AUDIO IN Audio Amplifier 1 Stereo cable 1. Connect the AUDIO OUT port of the TV to the Audio In port of an audio amplifier with a stereo cable. English...

  • Page 17: Connecting The Bathroom Speakers

    Connecting the Bathroom Speakers You can connect the Bathroom Speakers in the following manner. Connecting through the Variable Output (available without an external amplifier) ¦ TV Rear Panel EX-LINK EX-LINK Speaker VOL+ VOL-CTRL Volume Control Box VOL- AUDIO IN AUDIO IN 1.

  • Page 18: Connecting The Rjp (Remote Jack Pack)

    [HDMI] port of the TV to the HDMI port of the RJP. 4. Connect the EX-LINK port of the TV to the RS/232 port of the RJP. ✎ This Samsung TV is compatible with the TeleAdapt TA-7610 RJP only. English...
  • Page 19 y RJP (Remote Jack Pack): The RJP is a hardware module that has various Audio and Video inputs (A/V Video, A/V Audio, PC and HDMI) and corresponding outputs. The corresponding outputs are connected from the RJP to the TV. The RJP communicates with the TV via RS232. The RJP communicates with the TV by sending messages regarding Active/Inactive sources.

  • Page 20: Setting The Hotel Option Data

    After a menu appears, follow these general directions to navigate and change values: – Use the Up and Down arrow buttons on the Samsung remote to move from menu item to menu item. – Press the ENTERE or Left or Right arrow buttons to select a menu item. The screen displays that menu item only.

  • Page 21: Menu Items

    Interactive mode: TV works with an SI STB or SBB. Mode y Standalone mode : TV works alone, without an SI STB or SBB. y Interactive mode: Samsung / OCC / MTI / Nstreams / Enseo / Cardinal / Guestek / SeaChange / MDC / Innvue SI Vendor...
  • Page 22 Hotel TV Function Description Category Item Picture Menu Lock Enable or disable the Picture Menu. y ON: The Main Menu is displayed. Menu Display y OFF: The Main Menu is not displayed. Tools Display Hide or show the Tools menu. Channel Menu Display Hide or show the Channel menu.
  • Page 23 Hospitality Logo DL y BMP or AVI files only. y Max file size: BMP - 960 X 540. AVI - 30MB. y The file can only be named samsung.bmp or samsung.avi. Logo Display Time Hospitality Logo Display Time (3/5/7 seconds).
  • Page 24 Vendor Server: In the case of that the special SI vendor of the server is installed in your site. y SINC Server: In the case of that the Samsung SINC server is installed in your site. Server URL Setting If this item is entered into, URL of the solution server can be inputted.
  • Page 25 DTV OpenCable AGC Gain unless problems occur. If the Samsung Sound Bar device is connected to this TV, this item lets you to select where the TV sound is outputted when the TV is turned on. y ON: When the TV is turned on, the TV sound is automatically outputted in the Sound Bar device only.

  • Page 26: Welcome Message

    Welcome Message ¦ The Welcome Message feature displays a custom message on the TV every time it is turned on. – Welcome message settings are in the Hotel Option Menu. – Set Welcome Message to ON to display the message when the TV is powered on. Welcome Message Edit Welcome Message Hospitality Logo...
  • Page 27 Logo File Format – The TV supports only BMP and AVI format. – The file name must be samsung.bmp or samsung.avi. – The maximum resolution of the BMP format is 960 x 540. – The maximum file size for AVI format is 30MB.
  • Page 28 USB Cloning ¦ The USB Cloning function lets you download user-configured settings (Picture, Sound, Input, Channel, Setup, and Hotel Setup) from one TV to a USB device, and then upload these settings from the USB device to other TV sets. This lets you create a standard file of settings and distribute that standard file to all the TVs in your facility.
  • Page 29 Settings Cloned in the Hotel Menu Menu Item Cloning Support Hospitality Mode SI Vendor Power On Channel Power On Channel Num Power On Channel Type Power On Volume Power On Volume Num Min Volume Max Volume Power On Source Power On Option Channel Setup Channel Editor Dynamic SI...
  • Page 30 Menu Item Cloning Support Setting Auto Initialize REACH 3.0 REACH Channel Group ID IPG Room Type Ticker REACH Update Time REACH Update Immediate Room Number REACH Server Version Network Setup SmartHub Model Setting SmartHub Setting Widget Mode Solution Type Server URL Setting License Server IP Setting IPTV Mode Virtual Standby...
  • Page 31 Multi Code Remocon ¦ A Multi Code Remocon is a special remote which is designed to control multiple TVs. This function is useful where there is more than one TV in a location. You can control up to 10 TVs with a different ID code of each remote with no conflicts between the TVs. ID numbers are displayed on each TV's OSD.
  • Page 32 General Sound Additional Settings Game Mode Audio Format BD Wise Audio Delay Sound Feedback Dolby Digital Comp Boot Logo Auto Volume Samsung Instant On Reset Sound Anynet+ (HDMI-CEC) Anynet+ (HDMI-CEC) Auto Turn Off Device search DivX® Video On Demand English...
  • Page 33 Hotel Plug & Play ¦ The Hotel Plug & Play function, which automatically performs the Hotel mode selection, Country Setup, Clock Setup, and Picture Mode Setup, runs once, when power is first turned ON. Setup also runs automatically after you have executed a Service Reset.
  • Page 34 – If you select Standalone from the “Select Hotel TV Mode” OSD, the “Select Menu Language” OSD appears. – Initially highlighted: English – Display time: OSD time out and operation are the same as Samsung's consumer TV models. – If you press the Enter key, the “Picture Mode” OSD appears y Picture Mode OSD –...
  • Page 35 ¦ Samsung may offer upgrades to the TV’s SW in the future. Please contact the Samsung Hospitality Hot line at 1-866-894- 0524 to receive information about downloading upgrades and using a USB drive to update the SW by connecting the USB drive containing the upgrade to the USB port located on the TV.
  • Page 36 Soundbar(AirTrack) Hotel mode functional characteristics: y Power On/Off is synchronized with the TV y HDMI_CEC defaults set to On y Functions through the “HDMI OUT” port only y Disables the "Input mode" key on the VFD to prevent unexpected audio-source changes. y Acquires adjustable Power On and Max Volume settings from the TV’s Hotel option menu.
  • Page 37 5. Edit the Channel Bank. An example is below. a. Bank1 (Free channel): Select the channels that will be accessible when a remote doesn’t have a card. b. Bank2 (Family Card - Green): Select the channels that will be accessible when a remote has a GREEN CARD. c.
  • Page 38 Channel Editor ¦ The Channel Editor lets you edit the channels stored in the TV's memory. Using Channel Editor you can: – Change the channel numbers and names, and sort the channels in your desired channel number order. – Apply the video mute to channels you select. The video mute blanks out the video from a channel and outputs only the sound while displaying a speaker icon on the screen.
  • Page 39 The picture below shows a sample Channel Editor screen. Channel ----- (Cable) a 10 ----- (Cable) Air 10-1 CW DTV ----- (Cable) a 11 ----- (Cable) Air 11-1 HBO DTV ----- (Cable) a 12 Air 12-1 NBC DTV Air 7-1 a 13 ----- (Cable) a 14...
  • Page 40 When you press the TOOLS button, the following menu is available. Channel TOOLS ----- (Cable) a 10 Edit Channel Number ----- (Cable) Air 10-1 CW DTV Rename Channel ----- (Cable) a 11 Information ----- (Cable) Air 11-1 HBO DTV ----- (Cable) a 12 Air 12-1 NBC DTV...
  • Page 41 The external sources of this TV are displayed in the last page of the Channel Editor menu as shown in the example below. In the example, there are two external sources connected to the TV, HDMI 2 and AV. – You can assign a new analog channel to an external source by selecting the source on the last page, pressing the TOOLS button, selecting Edit Channel Number, and then using the up or down arrow button on the remote to select the channel number of the analog channel.

  • Page 42: Installing The Wall Mount

    For detailed information on installing the wall mount, see the instructions provided with the wall mount. Contact a technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you select to install the TV on your own.
  • Page 43 Samsung is not liable for these kinds of accidents. – Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

  • Page 44: Anti-Theft Kensington Lock

    Refer to the manual provided with the Kensington Lock for additional information on proper use. The Kensington Lock is not supplied by Samsung. ✎ Please find the “K” icon on the rear of the TV. A Kensington slot is beside the “K”...

  • Page 45: Specifications

    Specifications Display Resolution 3840 x 2160 Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Stand Swivel (Left / Right) 0°...

  • Page 46: Display Resolution

    Display Resolution When you use your TV as a computer monitor, you can also select one of the standard resolutions listed in the Resolution column. The TV will automatically adjust to the resolution you choose. Display Horizontal Vertical frequency Clock frequency Polarity (horizontal Mode Resolution...
  • Page 47 Display Horizontal Vertical frequency Clock frequency Polarity (horizontal Mode Resolution format frequency (KHz) (Hz) (MHz) / vertical) 720(1440) x 576i 50 Hz 15.625 50.000 27.000 - / - 720(1440) x 480i 60 Hz 15.734 59.940 27.000 - / - 720 x 576 50 Hz 31.250 50.000...

  • Page 48: Dimensions

    Dimensions Front view / Side view (Unit: inches) 36.1 34.9 19.6 21.0 22.9 HG40ND690U HG48ND690U 42.7 41.5 23.4 24.8 26.6 10.0 HG55ND690U 48.9 44.1 26.8 28.2 30.0 10.5 Jack panel detail / Rear view (Unit: inches) HG40ND690U 14.0 24.7 HG48ND690U 13.4 12.9 15.7...
  • Page 49 Base Stand detail (Unit: inches) HG40ED690U 26.3 HG48ED690U 28.6 10.0 HG55ED690U 29.8 10.5 ✎ NOTE All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors. English...
  • Page 50 SAMSUNG will additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
  • Page 51 HDMI Licensing LLC in the United States and other countries. Open Source License Notice Open Source used in this product can be found on the following webpage. (http://opensource.samsung.com) Open Source License Notice is written only English. English...
  • Page 52 Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Customer Care Web Site Address Center CANADA 1-800-SAMSUNG www.samsung.com/ca/support (English) Samsung Electronics Canada Inc. 2050 Derry (726-7864) Road West, Mississauga, Ontario L5N 0B9 www.samsung.com/ca_fr/support (French)
