Meridian Active Subwoofer M1500 Technical Specifications

Background
Bass is the foundation to music, a key to enjoying full-range music and
spectacular Hollywood soundtracks. Unfortunately, most subwoofers
compensate for a lack of low bass by over-emphasising mid bass. The result is a
boomy character that might impress at first but clouds the midrange and
eventually fatigues the listener.
Meridian, in contrast, emphasizes extreme bass depth, clarity, control,
articulation, slam and attack and the Meridian M1500 Active Subwoofer is
designed to bring you the highest quality sound possible, whether as part of an
enhanced stereo system or a full home theatre.
Meridian M1500
Using a 100-watt amplifier wired directly to a 10-inch woofer in an active
configuration, the M1500 provides far more bass energy than a conventional
design of the same power. The subwoofer is easily capable of visceral bass for
subterranean theatre effects, yet nimble enough to teat the most subtle music
with delicacy.
The M1500 has left and right unbalanced inputs with both positive and negative
phase connections, a switchable electronic crossover and a 100-Watt high-
efficiency bipolar amplifier design. It is fully shielded for use close to monitors
and televisions and, like all Meridian subwoofers, is constructed from 22mm MDF
which is both braced and damped.
The crossover in the M1500 is a second order Butterworth design with switchable
settings at 80Hz and 120Hz. It can also be switched to the "OFF" position,
bypassing the internal crossover to allow better integration between the M1500
and surround sound controllers that feature internal crossovers on their
dedicated subwoofer outputs.
Technical Specification
Performance:
In room response within 3dB, 30Hz-400Hz (Bypass).
Switchable 2nd order Butterworth crossover with settings at
80Hz and 120Hz.
Typical output >107dB spl @ 1m.
Noise and hum <-72dBm.
Distortion <0.1%, typically less than 0.02% up to full power at
all relevant frequencies.
Inputs:
Unbalanced on phono connectors 6V-500mV.
Construction:
Two 250mm high-efficiency long-throw custom drivers with 2kg
shielded magnet in a magnesium basket.
Veneered MDF braced and damped, in black with 6mm
annealed plate glass top.
Complementary high-efficiency bipolar design, with output-
stage error correction and twin feedback loop.
200W mean power continuous.
Power:
100-125; 200-230; 210-250V AC 50-60Hz
6VA idle; 150VA max
Dimensions:
Height, Width and depth 416mm (16.4in) without supplied feet
or castors. Weight 35kg (77lb).
M1500
Active Subwoofer
Sales information
th
25 March 2002
Single 10-inch driver acoustic-
suspension active loudspeaker
High-efficiency 100 Watt power
amplifier
Switchable electronic crossover
Built from 22mm MDF, braced and
damped and finished with a 6mm
annealed plate glass top
Digital version (D1500) available
