Ranger Bluetooth Audio 2-Way Splitter ® ® With A2DP, CSR aptX supported Features ◎ Can connect up to 2 devices ( Bluetooth headphones) ® ◎ aptX normal and low latency codec support ◎ SBC codec support A2DP Bluetooth profile supported ◎...
Page 4
( Pairing name is BT Music Splitter ) A) Connection ( TV audio connection ) Connect one end of the 3.5mm audio cable to the audio in jack on the Ranger Bluetooth Audio 2-way splitter. Connect the other end of the 3.5mm audio cable to an audio output on your TV’s headphone output or speaker output port.
After connect the 3.5mm audio cable and the built in usb cable to the TV , the Ranger Bluetooth Audio 2-way splitter blue led light will start flashing on / off . It will takes estimate about 10 to 20 secs to auto connect the “pairing” devices. When the headphone are connected, the Ranger Bluetooth Audio 2-way splitter will show steady blue led light.
If there is no sound comes out from both the headphones , please unplug and replug again the Ranger Bluetooth Audio 2-way splitter from the TV. Wait for a short while for it to get connected.
