Summary of Contents for Memorex MB2190
- Page 1 MB2190 O/M.QXD 3/31/03 3:07 PM Page 13 MB2190 User’s Guide Micro Cassette Recorder Before operating this product, please read these instructions completely.
-
Page 2: Location Of Controls
MB2190 O/M.QXD 3/31/03 3:07 PM LOCATION OF CONTROLS 1. MIC (Microphone) Jack 2. VOLUME/VOX Mic Sensitivity Control 3. Microcassette Compartment 4. Tape Counter Reset Button 5. Tape Counter 6. REC/BATT Indicator 7. Speaker 8. PHONES (Headphones) Jack 9. VOX (Voice Activation) ON/OFF Switch 10. -
Page 3: Power Sources
MB2190 O/M.QXD 3/31/03 3:07 PM POWER SOURCES BATTERY INSTALLATION Open the battery compartment and insert two (2) "AAA" size batteries (not included) following the polarity diagram. Put the battery compartment cover back into place. NOTE: The REC/BATT indicator will brightly light during recording when batteries are fresh. -
Page 4: Operation
MB2190 O/M.QXD 3/31/03 3:07 PM OPERATION TO PLAY A PRERECORDED MICROCASSETTE TAPE Press the Stop/Eject button and insert a microcassette tape with the side to be played facing you. Close the Cassette Compartment. Press the Play button to start playback... - Page 5 MB2190 O/M.QXD 3/31/03 3:07 PM OPERATION (CONTINUED) TO FAST REWIND/REVIEW A MICROCASSETTE TAPE To rapidly rewind a microcassette tape in the Stop mode, slide the REW (REV)/F.F (CUE) switch to the REW (REV) position. Press the Stop/Eject button when you reached the desired position.
-
Page 6: Tape Counter
MB2190 O/M.QXD 3/31/03 3:07 PM OPERATION (CONTINUED) TO PAUSE A CASSETTE TAPE This unit can pause the microcassette while Recording, Playback, Rewind or Fast Forward To pause Recording, Playback, Rewind or Fast Forward, slide the PAUSE switch to the ON position. -
Page 7: Normal Recording
MB2190 O/M.QXD 3/31/03 3:07 PM OPERATION (CONTINUED) NORMAL RECORDING This unit is capable of recording only when sound is heard. To use this feature, see the next page. For normal recording, follow the steps below. Press the Stop/Eject button and... - Page 8 MB2190 O/M.QXD 3/31/03 3:07 PM OPERATION (CONTINUED) VOICE ACTIVATED (VOX) RECORDING Voice activated recording will allow dictation only when you speak. When the unit detects a pause of a few seconds, it will temporarily stop recording until it detects sound again.
-
Page 9: Cue Marker
MB2190 O/M.QXD 3/31/03 3:07 PM OPERATION (CONTINUED) CUE MARKER The cue marker will allow you to record a tone on the microcassette for easy locating after you record. While recording, press and hold the CUE MARKER button for three seconds; a tone will then be recorded on the microcassette at that point. -
Page 10: Care And Maintenance
MB2190 O/M.QXD 3/31/03 3:07 PM Page 9 CARE AND MAINTENANCE SAFEGUARD AGAINST ACCIDENTAL ERASURE When a new recording is made, any program material previously recorded automatically erased and only the new recording remains. safeguard valuable recordings from being erased accidentally, the cassette and the deck are equipped with a special device. - Page 11 MB2190 O/M.QXD 3/31/03 3:07 PM CARE AND MAINTENANCE (CONTINUED) CLEANING Clean the tape head, capstan and pinch roller using a cotton swab slightly moistened with alcohol. Avoid scratching the head surface. To clean the unit housing, use a soft cloth slightly dampened with water and wipe dry.
-
Page 12: Specifications
MB2190 O/M.QXD 3/31/03 3:07 PM SPECIFICATIONS Tape Speed ..... 2.4cm/sec or 1.2cm/sec Frequency Response..... . . 250-4500Hz Speaker . - Page 13 MB2190 O/M.QXD 3/31/03 3:07 PM Page 12 Memcorp, Inc. Weston, FL Printed in Hong Kong Visit our website at www.memorexelectronics.com...
