- Page 1 ’ ’ UIDE UIDE RF7000 ERSION Wireless EZ Touch Wireless EZ Touch Keyboard & Optical Mouse Keyboard & Optical Mouse...
- Page 3 MPORTANT OTICE The information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. No warranty of representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular purpose of this document. The manufacturer reserves the right to make changes to the content of this document and/or the products associated with it at any time without obligation to notify any person or organization of such changes.
-
Page 5: Table Of Contents
ABLE OF ONTENTS 1. Introduction What's in this package 2. System Requirements 3. Using the Keyboard and Mouse 3.1 Hardware Installation 3.2 Wireless ID Setting 3.3 Attaching the Wrist Rest 4. Software Installation 5. Uninstallation 6. Wireless EZ Touch Software 6.1 To Display the "KeyMaestro"... -
Page 6: Introduction
It has a scroll wheel, and three of its five buttons may be pro- grammed using the included software. In order to enjoy the full potential of the RF7000 EZ Touch Keyboard and Optical Mouse combo, please read this manual carefully. -
Page 7: Using The Keyboard And Mouse
3. Using the Keyboard and Mouse This wireless keyboard and mouse combo consists of a receiver that plugs into the computer, a wireless keyboard, and a wireless mouse. 3.1 Hardware Installation 3.1.1 Getting the Receiver Ready Connect the receiver and select a wireless channel: 1. - Page 8 6. The optical mouse is deigned to save power by going into a Sleep mode after 10 minutes of inactivity. Simply move the mouse or click on the buttons to wake it up. Keyboard Channel Slide Switch Synch Button...
-
Page 9: Wireless Id Setting
Important: Whenever you want to set the IDs of both the keyboard and mouse, you must first set the receiver ID and keyboard ID, and then set the receiver ID and mouse ID, as described in this procedure. - Page 10 6. Turn the mouse over and locate the ID button on the left side of the mouse near the battery compartment. Press the ID button firmly with a blunt pointed object (like the tip of a ballpoint pen), then let go. The receiver should blink rapidly then stop.
-
Page 11: Attaching The Wrist Rest
Step 2: Insert the driver CD in your computers CD-ROM drive. The software should auto start*. Step 3: Select "Install Memorex RF7000 Wireless EZ Touch Keyboard" (see following picture). Step 4: Follow onscreen instructions to finish the installation procedure. In order to take advantage of the special shortcut button functionality of the mouse you will have to install the mouse driver software which is located on the included driver CD. -
Page 12: Uninstallation
Step 4: Select "Uninstall KeyMaestro Mouse Driver". Step 5: Click “Yes” to confirm you want to uninstall. If the keyboard and/or mouse is not working properly, see "Troubleshooting" for tips on how to solve your problem. 6. Wireless EZ Touch Software 6.1 To Display the "KeyMaestro"... -
Page 13: To Display The "Configure Button" Dialogue Box
6.1.2 Enable Display Label This command displays or hides the OSD (On Screen Display). When the OSD is enabled, each time you press any one of the multimedia buttons, its function name (button label) will show on the right-bottom corner on the screen. This function is enabled by default. 6.1.3 Enable Taskbar Icon This command displays or hides the taskbar software icon. -
Page 14: Using The Keyboard
7. Using the Keyboard 7.1 O FFICE PPLICATION Word Excel PowerPoint Calendar 7.2 I NTERNET Back Forward Stop Refresh Search Favorite E-mail Opens Microsoft Word Opens Microsoft Excel Opens Microsoft PowerPoint Opens “Calendar” function of Microsoft Outlook Returns to the last page you viewed. Returns to the page you viewed before selecting the back button. -
Page 15: Application Keys
7.3 A PPLICATION Computer Calculator Log Off Log Off Sleep Power Note: For Power Management functions, please see your computer's manual for assistance. Or see "Troubleshooting" on page 15 for more information. 7.4 M ULTIMEDIA Mute Volume Up Volume Down Stop Previous Next... -
Page 16: Enhanced Function Keys
7.5 Enhanced Function Keys Enhanced function keys consist of 12 keys and functions. There are two ways these functions may work: 1. As a part of the main keyboard: F1 – F12. 2. As 12 embedded office keys and functions. NHANCED UNCTION Office Wizard... -
Page 17: Multimedia Keys
Scroll Wheel to scroll the doc- ument vertically. 2. Works as a mouse button. When you push on the scroll wheel, a series dialogue functions will pop-up as shown below. Their functions are divided into 3 parts: 7.7 C... -
Page 18: Using The Mouse
8. Using the Mouse 8.1 Using the Mouse Driver After installing the mouse driver as described in section 4 you will be able to start up the Mouse Control Panel by left double-clicking on the KeyMaestro Mouse icon Windows task bar. This should appear after restarting your machine. You can also invoke the Mouse Control Panel by choosing Start?Programs?MMaestro?KeyMaestro Mouse Driver. -
Page 19: Quick Jump Function Introduction
Returns to the page you viewed before selecting the back button. 8.3 Quick Jump Function Introduction After installing the mouse driver and invoking the KeyMaestro mouse driver program you will have access to nine special function icons by pressing the scroll wheel once. These nine functions are: Mouse... -
Page 20: Troubleshooting
IDs if your keyboard and mouse are not working properly. 2. Mouse does not work accurately: Use the mouse only on a clean, flat, non-slip- pery surface in order to ensure smooth and accurate cursor action. If you use a mouse-pad, choose a light-colored one to use less battery power. - Page 21 6. Windows Media Player cannot play VCD titles or MPEG files: Make sure you have installed Windows Media Player version 7 or later properly. If not, please download the latest version of Windows Media Player (version 7 or higher required) from the Microsoft website.
- Page 22 To register your product please visit service and support online at www.memorex.com or write to us with your name, address, phone number, model name, model number, date of purchase and place of purchase at: Memorex Products, Inc. 10100 Pioneer Blvd, Suite 110, Santa Fe Springs, CA 90670.
- Page 23 FCC Guidelines: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equip- ment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions may cause harmful interference to radio communications.
- Page 24 ©2003 Memorex Products, Inc. • Santa Fe Springs, CA 90670 • www.memorex.com All other brand or product names are trademarks or registered trademarks of their respective owners. 5395 6196...
