Basic Operating Instructions

Digital Camera

DMC-3D1
Model No.
Before use, please read these instructions completely.
More detailed instructions on the
operation of this camera are
contained in "Operating
Instructions for advanced features
(PDF format)" in the supplied CD-ROM. Install it
on your PC to read it.
Web Site: http://www.panasonic-europe.com
VQT3U38
E

Advertisement

Table of Contents
loading

Related Manuals for Panasonic Lumix DMC-3D1

Summary of Contents for Panasonic Lumix DMC-3D1

  • Page 1: Basic Operating Instructions

    Before use, please read these instructions completely. More detailed instructions on the operation of this camera are contained in “Operating Instructions for advanced features (PDF format)” in the supplied CD-ROM. Install it on your PC to read it. Web Site: http://www.panasonic-europe.com VQT3U38...

  • Page 2: Information For Your Safety

    Dear Customer, We would like to take this opportunity to thank you for purchasing this Panasonic Digital Camera. Please read these Operating Instructions carefully and keep them handy for future reference. Please note that the actual controls and components, menu items, etc. of your Digital Camera may look somewhat different from those shown in the illustrations in these Operating Instructions.

  • Page 3: Caution For Ac Mains Lead

    For the United Kingdom  IMPORTANT Caution for AC mains lead The wires in this mains lead are coloured For your safety, please read the following in accordance with the following code: text carefully. Blue: Neutral, Brown: Live. This appliance is supplied with a moulded As these colours may not correspond with the coloured markings identifying the three pin mains plug for your safety and...
  • Page 4 ∫ About the battery pack CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. • Do not heat or expose to flame. •...
  • Page 5 ∫ Cautions for Use • Always use a genuine Panasonic AV cable (DMW-AVC1; optional). • Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30; optional). Part numbers: RP-CDHM15 (1.5 m) (5 feet), RP-CDHM30 (3.0 m) (10 feet) • Do not use any other USB connection cables except the supplied one.
  • Page 6 -If you see this symbol- Information for Users on Collection and Disposal of Old Equipment and used Batteries These symbols on the products, packaging, and/or accompanying documents mean that used electrical and electronic products and batteries should not be mixed with general household waste.

  • Page 7: Table Of Contents

    Contents Information for Your Safety ................2 Main features of the camera ................. 8 Care of the camera ..................9 Accessories....................10 Names and Functions of Main Parts ............12 How to Use the Touch Panel ..............13 Charging the Battery ................... 14 •...

  • Page 8: Main Features Of The Camera

    Main features of the camera This unit has two lenses built-in so that you can enjoy making a variety of different recordings. You can switch between the following functions using the 3D/2D switch. When the 3D/2D switch is set to [3D] •...

  • Page 9: Care Of The Camera

    Care of the camera Remove the lens cover seal A before use. Do not subject to strong vibration, shock, or pressure. • The lens, LCD monitor, or external case may be damaged if used in following conditions. It may also malfunction or image may not be recorded.

  • Page 10: Accessories

    Accessories Check that all the accessories are supplied before using the camera. Product numbers correct as of October 2011. These may be subject to change. Battery Pack (Indicated as battery pack or battery in the text) Charge the battery before use. Battery Charger (Indicated as battery charger or DMW-BCG10E...

  • Page 11: Optional Accessories

    For customers within Ireland: 01 289 8333 • For further support on your product, please visit our website: www.panasonic.co.uk Direct Sales at Panasonic UK • Order accessory and consumable items for your product with ease and confidence by phoning our Customer Communications Centre Monday–Thursday 9:00 a.m.–5:30 p.m.,...

  • Page 12: Names And Functions Of Main Parts

    Names and Functions of Main Parts Self-timer indicator AF Assist Lamp Right lens Flash Left lens Lens cover Speaker • Do not cover the speaker with your fingers. Microphone Power button Shutter button 10 Zoom lever Motion picture button 12 3D/2D switch 13 Touch panel/LCD monitor 14 Strap eyelet •...

  • Page 13: How To Use The Touch Panel

    How to Use the Touch Panel This touch panel is a type that detects pressure. Touch the screen Drag To touch and release the touch panel. A movement without releasing the touch panel. Use this to perform tasks such as This is used when performing tasks selecting icons or images displayed on such as moving to the next image by...

  • Page 14: Charging The Battery

    Please be advised that we are not liable for any accident or failure occurring as a result of use of a counterfeit battery pack. To ensure that safe products are used we would recommend that a genuine Panasonic battery pack is used. • Use the dedicated charger and battery.

  • Page 15: Approximate Operating Time And Number Of Recordable Pictures

    CIPA is an abbreviation of [Camera & Imaging Products Association]. • Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when LCD monitor is on. • Using a Panasonic SD Memory Card (32 MB). • Using the supplied battery. • Starting recording 30 seconds after the camera is turned on. (When the Optical Image Stabiliser function is set to [On].)

  • Page 16: About The Built-In Memory/The Card

    Memory Card compatible equipment. • Check that the PC and other equipment are compatible when using the SDXC Memory Cards. SDXC Memory Card http://panasonic.net/avc/sdcard/information/ (48 GB, 64 GB) SDXC.html • Only the cards with capacity listed left can be used.

  • Page 17: Inserting And Removing The Card (Optional)/The Battery

    Inserting and Removing the Card (optional)/the Battery • Check that this unit is turned off. • We recommend using a Panasonic card. Slide the release lever in the direction of the arrow and open the card/battery door. • Always use genuine Panasonic batteries (DMW-BCG10E).

  • Page 18: Setting Date/Time (Clock Set)

    Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Turn the camera on. • Lower the lens cover. • When turning off the power, raise the lens cover. Touch [Language Set]. Select the language, and then touch [Set]. Touch [Clock Set].

  • Page 19: Taking 3D Pictures

    Taking 3D pictures With the two lenses built into this unit, you can record 3D pictures. Set the 3D/2D switch to [3D]. Aim the AF area at the point you want to focus on. Press the shutter button halfway to focus. A ISO sensitivity B Aperture value C Shutter speed...

  • Page 20: Recording 3D Motion Pictures

    Recording 3D motion pictures Set the 3D/2D switch to [3D]. Start recording by pressing the motion picture button. A Available recording time B Elapsed recording time • Release the motion picture button right after you press it. • The recording state indicator (red) C will flash while recording motion pictures.

  • Page 21: Selecting A 2D Recording Mode

    Selecting a 2D Recording Mode Set the 3D/2D switch to [2D]. In Recording Mode, touch [ Touch the Recording Mode icon. ∫ List of [Rec] Modes Normal Picture Mode The subjects are recorded using your own settings. Intelligent Auto Mode ¦...

  • Page 22: Taking Pictures Using The Automatic Function (Intelligent Auto Mode)

    Applicable modes: Taking Pictures Using the Automatic Function (Intelligent Auto Mode) The camera will set the most appropriate settings to match the subject and the recording conditions so we recommend this mode for beginners or those who want to leave the settings to the camera and take pictures easily. Set the 3D/2D switch to [2D].

  • Page 23: Recording 2D Motion Pictures

    Applicable modes: Recording 2D Motion Pictures Set the 3D/2D switch to [2D]. Start recording by pressing the motion picture button. A Available recording time B Elapsed recording time • A 2D image is recorded using the left lens. • You can record motion pictures fitting each Recording Mode.

  • Page 24: Playing Back Pictures ([Normal Play])

    Playing Back Pictures ([Normal Play]) To view 3D images, a television that supports 3D is required (This unit will play back in 2D). For details, read the PDF. In Recording Mode, touch [ • The display switches to normal playback. Drag the screen horizontally.

  • Page 25: Deleting Pictures

    Deleting Pictures Once deleted, pictures cannot be recovered. • Pictures on the built-in memory or the card, that are being played back will be deleted. In Playback Mode, select the picture to delete and touch [ Touch [Delete Single]. • Confirmation screen is displayed.

  • Page 26: Setting The Menu

    Setting the Menu Example: In the [Rec] menu, change [AF Mode] from [Ø] (1-area-focusing) to [š] (Face Detection) Touch [ Touch the menu icon. Touch the menu item. Touch the Settings. • Depending on the menu item, its setting may not appear or it may be displayed in a different way.

  • Page 27: About The Supplied Software

    About the supplied software The supplied CD-ROM includes the following software. Install the software on to your computer before use. • PHOTOfunSTUDIO 7.0 HD Edition (Windows XP/Vista/7) You can load 2D and 3D pictures, 3D motion pictures, and motion pictures recorded in [AVCHD] or [MP4] format on to your computer, and categorise and organise the loaded pictures by recording date, type of digital camera equipment, etc.

  • Page 28: Installing Supplied Software

    Installing supplied software • Before inserting the CD-ROM, close all running applications. Check the environment of your PC. • Operating environment of “PHOTOfunSTUDIO 7.0 HD Edition” – Windows XP (32bit) SP2/SP3, Windows Vista (32bit) or SP1/SP2, Windows 7 (32bit/64bit) or SP1 –...

  • Page 29: Reading The Operating Instructions (Pdf Format)

    Reading the Operating Instructions (PDF format) More detailed instructions on the operation of this camera are contained in “Operating Instructions for advanced features (PDF format)” in the supplied CD-ROM. Install it on your PC to read it. ∫ For Windows Turn the PC on and insert the CD-ROM containing the Operating Instructions (supplied).
  • Page 30 OS from the following Web Site. http://get.adobe.com/reader/otherversions ∫ To uninstall the Operating Instructions (PDF format) Delete the PDF file from the “Program Files\Panasonic\Lumix\” folder. ∫ For Mac Turn the PC on and insert the CD-ROM containing the Operating Instructions (supplied).

  • Page 31: Specifications

    Specifications Digital Camera: Information for your safety Power Source: DC 3.6 V Power Consumption: 1.6 W (When recording in 3D) 1.6 W (When recording in 2D) 1.1 W (When playing back) Camera effective 12,100,000 pixels pixels Image sensor 1/2.3q MOS sensork2, total pixel number 12,800,000 pixels, Primary colour filter Lens Optical 4kzoom lensk2, fl4.5 mm to 18 mm...
  • Page 32 Burst recording Burst speed (Number of recordable pictures) Approx. 2 pictures/second (Max. 100 pictures) Approx. 4 pictures/second (Max. 100 pictures) Approx. 8 pictures/second (Max. 12 pictures) Minimum Approx. 14 lx (when i-low light is used, the shutter speed Illumination is 1/25th of a second) Shutter speed 8 seconds to 1/1300th of a second [Starry Sky] Mode: 15 seconds, 30 seconds...
  • Page 33 10%RH to 80%RH Battery Charger (Panasonic DE-A66A): Information for your safety Input: 110 V to 240 V 50/60 Hz, 0.2 A Output: 4.2 V 0.65 A Battery Pack (lithium-ion) (Panasonic DMW-BCG10E): Information for your safety Voltage/capacity: 3.6 V/895 mAh (ENG) VQT3U38...
  • Page 34 This product incorporates the software licensed under BSD license. For the software licensed under BSD license, please refer to the applicable license terms in the following. A C-program for MT19937, with initialization improved 2002/1/26. Coded by Takuji Nishimura and Makoto Matsumoto. Before using, initialize the state by using init_genrand(seed) or init_by_array(init_key, key_length).
  • Page 35 • SDXC Logo is a trademark of SD-3C, LLC. • “AVCHD” and the “AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation. • Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
