SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes or
modifications to this equipment may cause harmful interference unless
the modifications are expressly approved in the instruction manual. The
user could lose the authority to operate this equipment if an unauthorized
change or modification is made.
ATTENTION:
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA
PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE
LA PRISES ET POUSSER JUSQU'AU FOND.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
1

Advertisement

Table of Contents
loading

Summary of Contents for Memorex portable user

  • Page 1 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 2: Safety Precautions

    INFORMATION: This equipment complies with Class B digital device regulations. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
  • Page 3 Dear Customer: Selecting fine audio and video equipment such as the unit you’ve just purchased is only the start of your musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your equipment offers. This manufacturer and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level.
  • Page 4: Location Of Controls

    MAIN UNIT 1. Screen 2. Remote Sensor 3. SD/MMC/MS/xD Card Slot (Side of Unit) 4. CF Card Slot (Side of Unit) 5. Navigation † Button 6. Navigation π Button 7. ENTER/PLAY Button 8. Wall Mount Hole 9. Stand 10. Wall Mount Hole 11.
  • Page 5 REMOTE 1. MUTE Button 2. Navigation √/VOLUME - Button 3. Navigation π Button 4. Navigation † Button 5. MENU Button 6. EXIT Button 7. Remote Transmitter (Top of Unit) 8. TIME Button 9. Navigation ®/ VOLUME + Button 10. ENTER/PLAY Button 11.
  • Page 6: Power Source

    AC CONNECTION Insert the small end of the AC adapter into the DC 12V IN jack (located under the left cover on the side of this unit). Connect the other end to a wall outlet having 120V AC, 60 Hz. AC Adapter, DC 12V Z NOTES: •...
  • Page 7: Optional Features

    OPTIONAL FEATURES HEADPHONES JACK (SIDE OF UNIT) For private listening, plug headphones into this jack. The speakers will be disconnected when a plug is inserted into this jack. WALL MOUNT HOLES (2) (REAR OF UNIT) If desired, the digital frame can be mounted onto a wall. Simply hang using the Wall Mount holes, as you would hang an ordinary photo frame or painting.
  • Page 8: Using A Memory Card

    USING A MEMORY CARD You can access media files from an external memory card as described below. This unit accepts memory cards up to these sizes: SD up to 2GB, MMC up to 1GB, MS up to 1GB, xD up to 1GB and CF up to 2GB. Please place under 300 photo files on the memory card, otherwise some photos may not appear in the frame.
  • Page 9 “Memorex”. 4. Navigate to the media files that you want to copy. Then, drag and drop them to the “Memorex” drive. (Refer to the owners manual accompanying your computer for more information on copying files.) NOTES: •...
  • Page 10: Operation

    SETTING THE TIME AND DATE Press the Power button to the On (in) position to turn the unit on. This unit will either show the Main menu or automatically start showing a photo Slideshow (if the Auto Play option in the Setup menu is set to ON).
  • Page 11 BASIC PHOTO PLAYBACK Press the Power button to the On (in) position to turn the unit on. This unit will either show the Main menu or automatically start showing a photo Slideshow (if the Auto Play option in the Setup menu is set to ON).
  • Page 12 ZOOM While viewing a photo (see the previous page), press the ZOOM IN button 1; the unit will zoom x2. Repeatedly press to zoom up to x13. Use the Navigation √,®,π,† buttons 2 to move the photo on the screen. Press the ZOOM OUT button 3 to zoom back out of the photo.
  • Page 13 PHOTO “FAVORITES” PLAYBACK While in Photo Thumbnail view (see page 11), select a photo to add to your Favorites using the Navigation √, ®, π, † buttons 1. Then press the ZOOM IN button 2 to confirm; a red frame will appear around the selected photo.
  • Page 14: Adjusting The Volume

    BASIC MUSIC PLAYBACK Press the Power button to the On (in) position to turn the unit on. This unit will either show the Main menu or automatically start showing a photo Slideshow (if the Auto Play option in the Setup menu is set to ON).
  • Page 15 BASIC VIDEO PLAYBACK Video: Compress type: MPEG-4 Video Dimensions: 352 x 288 CIF Audio: -Law 2:1 or A-Law 2:1 Press the Power button to the On (in) position to turn the unit on. This unit will either show the Main menu or automatically start showing a photo Slideshow (if the Auto Play option in the Setup...
  • Page 16: Deleting A File

    DELETING A FILE Press the Power button to the On (in) position to turn the unit on. This unit will either show the Main menu or automatically start showing a photo Slideshow (if the Auto Play option in the Setup menu is set to ON).
  • Page 17: Copying A File

    COPYING A FILE Press the Power button to the On (in) position to turn the unit on. This unit will either show the Main menu or automatically start showing a photo Slideshow (if the Auto Play option in the Setup menu is set to ON).
  • Page 18: Setup Menu

    SETUP MENU The Setup menu lets you customize this digital frame by allowing you to select the source for your media files, set the effects between your photos, adjust the speed of the Slideshow and more! Use the following instructions to navigate and change the options which are described on the following page.
  • Page 19: Setup Options

    OPERATION (Continued) SETUP OPTIONS Select Card: Use this Setup option to select the source for your media files. Choose from Internal Flash, as well as any external media inserted (i.e. SD/MMC). Photo Mode: Use this Setup option to select the mode in which the photos will be displayed.
  • Page 20: Troubleshooting Guide

    If you experience a problem with this unit, check the chart below before calling for service. SYMPTOM Main unit, no power. Remote, no power. No photos in frame. Computer does not recognize frame as a Removable Disk. CAUSE AC adapter is not connected.
  • Page 21: Specifications

    PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR CONSUMER REPLACEABLE PART(S), SEE PART NUMBER(S) ON PAGES 4 AND 5 AND THEN CONTACT FOX INTERNATIONAL AT 1-800-321-6993.
