TGA670C(e).fm Page 1 Friday, May 19, 2006 11:56 AM
Thank you for purchasing a Panasonic cordless telephone.
This handset is an accessory handset for use with Panasonic base unit
KX-TG6700C. You must register this handset with your base unit before
it can be used.
This installation manual describes only the steps needed to register and
begin using the handset. Please read the base unit's operating
instructions for further details.
Charge the battery for 7 hours before initial use.
Please read this Installation Manual before using the unit and save for
future reference.
For assistance, please call 1-800-561-5505 or
visit us at www.panasonic.ca
Installation Manual
5.8 GHz Expandable Digital Cordless Handset
KX-TGA670C
Model No.
PQQX15238ZA
DM0506FF0
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TGA670C
Summary of Contents for Panasonic KX-TGA670C
- Page 1 KX-TGA670C Model No. Thank you for purchasing a Panasonic cordless telephone. This handset is an accessory handset for use with Panasonic base unit KX-TG6700C. You must register this handset with your base unit before it can be used. This installation manual describes only the steps needed to register and begin using the handset.
-
Page 2: Accessory Information
TGA670C(e).fm Page 2 Friday, May 19, 2006 11:56 AM Accessory information Included accessories Accessory item Quantity Charger AC adaptor for charger Battery Handset cover *1 The handset cover comes attached to the handset. Additional/replacement accessories Accessory item Order number Rechargeable nickel metal HHR-P105 hydride (Ni-MH) battery Headset... -
Page 3: Setting Up The Handset
Press the notch of the handset cover firmly, and slide it in the direction of the Connecting the charger arrow. L Use only the included Panasonic AC adaptor PQLV207. (120 V AC, 60 Hz) Bottom of Insert the battery (A), and press it... -
Page 4: Battery Charge
TGA670C(e).fm Page 4 Friday, May 19, 2006 11:56 AM Panasonic battery performance Battery charge Place the handset on the charger for 7 Operation Operating time hours before initial use. While in use Up to 5 hours While charging, the charge indicator on the (talking) handset lights in amber. -
Page 5: Changing The Display Language
TGA670C(e).fm Page 5 Friday, May 19, 2006 11:56 AM Changing the display language Registration You can select either “English” or “Français” as the display language. The Register the handset to a KX-TG6700C default setting is “English”. base unit. {MENU} i {0}{8}{1} Base unit: Press and hold {INTERCOM} until the Select the desired setting. -
Page 6: Headset (Optional)
Connecting a headset to the handset Drive the screws (not included) into the allows hands-free phone conversations. wall using the wall mount template as a We recommend using the Panasonic guide. headset noted on page 2. 25.4 mm (1 inch) -
Page 7: Specifications
TGA670C(e).fm Page 7 Friday, May 19, 2006 11:56 AM Charger Specifications Dimensions: Approx. height 58 mm x width 87 mm x General depth 95 mm (2 inches x 3 inches x inches) Operating environment: 5 °C – 40 °C (41 °F – 104 °F) Mass (Weight): Approx. -
Page 8: Important Safety Instructions
TGA670C(e).fm Page 8 Friday, May 19, 2006 11:56 AM WARNING: Important safety L To prevent the risk of fire or electrical shock, do not expose the product to rain instructions or any type of moisture. CAUTION: L Unplug the product from power outlets if it emits smoke, an abnormal smell, or Installation makes an unusual noise. - Page 9 TGA670C(e).fm Page 9 Friday, May 19, 2006 11:56 AM Copyright: This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
-
Page 10: Warranty
5770 Ambler Drive, Mississauga, Ontario L4W 2T3 PANASONIC PRODUCT - LIMITED WARRANTY Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase.
