Focus The Binocular - Meade CaptureView CV-2 User Manual

If you want to...

Focus the Binocular

Focus knob
How to Use Your Binocular
1. Set the Diopter Scale on underside
2. Choose an object (such as a
Diopter scale
3. Looking with only your left eye,
4. Looking with only your right eye,
5. Now, looking with both eyes, rotate
Do this...
of CaptureView at its center point
between "+" and "-."
telephone pole) that is at least 50
feet (15m.) away.
rotate the Focus Knob until the
object you are viewing is focused.
rotate the Diopter Scale until the
object you are viewing is focused.
the Focus Knob to focus on both far
and near objects.
11
