NON-CFC
This unit uses totally NON-CFC MATERIALS both for refrigerant (R600a) and for
insulation (Cyclo-Pentane). So, this refrigerator does not damage the Earth's ozone layer.
Thank you for purchasing the Panasonic product.
• Please read these instructions carefully and follow safety precautions on page 2-4 before
using this product.
• Please make sure the date and name of store of purchase are stamped in warranty card and
keep it with these operating instructions.
PHI
Operating Instructions
NR-DZ601W
NR-DZ601V, NR-DZ601W
Model No.:
NR-DZ601V
Refrigerator
For Household Use
ARAH1E202681
P0521-1071
Printed in Vietnam
Advertisement
Table of Contents
Related Manuals for Panasonic NR-DZ601V
Summary of Contents for Panasonic NR-DZ601V
-
Page 1: Table Of Contents
This unit uses totally NON-CFC MATERIALS both for refrigerant (R600a) and for insulation (Cyclo-Pentane). So, this refrigerator does not damage the Earth’s ozone layer. Thank you for purchasing the Panasonic product. • Please read these instructions carefully and follow safety precautions on page 2-4 before using this product. -
Page 2: Safety Precautions
Safety precautions Please be sure to follow these instructions. WARNING CAUTION This sign means: It may lead to a serious This sign means: It may result in injury or injury or death. property damage. These signs mean prohibited action. This sign means required action. iso-butane This sign means the appliance must Risk of fire / flammable materials... - Page 3 Otherwise it may WARNING cause a fire, injury, electrical shock. When using: ● Do not damage the cooling circuit (piping on the back). ● Do not touch the compressor and pipes, because of high temperature, that there is a risk of burn injury. ●...
-
Page 4: Usage Precautions
CAUTION Otherwise it may cause injury, accidents. When opening/closing the doors: ● While opening the refrigerator, be careful not to pinch other one's hand holding the door. ● Mind the gap between the doors. They may nip your hand while closing the door. When storing food: ●... - Page 5 Usage precautions When using: ● When the plug is disconnected, leave it for 5 minutes before 5 mins plugging again. If not, the compressor may not work. ● Adjust the temperature according to the actual operating condition for energy saving. ●...
-
Page 6: Installation
2 cm or less) ●The refrigerator LED light, specially designed for this refrigerator, do not replace it by yourself. If you need replacement, please contact Panasonic Service Center. ●If there is no grounding wiring plug in refrigerator, it should be connected with grounding connection to prevent electrical hazard from electric leakage. - Page 7 If the door is slanted downwards. Turn the adjuster bolt on the lower side, as When the door is lowered. shown in the diagram, in order to adjust the level. Lower the right Lower the left adjuster bolt for adjuster bolt for ●The freezer/refrigerator doors may tilt the right door.
-
Page 8: Parts Identification
Parts identification 1. Model : NR-DZ601W FREEZER ROOM PRIME FRESH ROOM (Blue Ag LED light) FRIDGE ROOM 1 Shelf FC 2 FC Glass tray 3 Auto Ice Making tray 4 Ice box 5 Door Ag Hygiene Zone 6 Ag Hygiene Zone Case 7 LED light 8 Door Prime Fresh 9 Prime Fresh case... - Page 9 Parts identification 2. Model : NR-DZ601V FREEZER ROOM PRIME FRESH ROOM (Blue Ag LED light) FRIDGE ROOM 1 Shelf FC 2 FC Glass tray 3 Ice twister 4 Ice box 5 Door Ag Hygiene Zone 6 Ag Hygiene Zone Case...
-
Page 10: Temperature Control
2 °C ~ 3 °C 2 °C ~ 3 °C 2 °C ~ 3 °C 2. Model : NR-DZ601V (Inside Control Panel) 1 Press the [Zone Select] button to select Fridge room [A], Prime Fresh room [B], or Freezer room [C*]. - Page 11 To adjust the temperature for the Freezer room Follow steps 1 ~ 5 above, but select Freezer room [Freezer] instead of Fridge room [Fridge]. 2. Model : NR-DZ601V (Inside Control Panel) To adjust the temperature for the Fridge room 1 Set the LED display to “Min” position by pressing the [Zone Select] button to select [A] (Fridge Room) then press the [Temp.
-
Page 12: Econavi Operation
Darkness is detected by the light intensity sensor at approximately 3 lx to 10 lx or less. 2. Model : NR-DZ601V This model also has ECONAVI mode, but it does not feature ECONAVI light and light intensity... -
Page 13: Quick Freezing
●If you want to stop the “Quick Freezing” operation immediately, repeat step 1 - 3. The [Quick Freezing] LED will turn off. 2. Model : NR-DZ601V ●Press the button [Zone Select] to select [C*] (Freezer room), then press [Temp. Select] until the light LED [Quick Freezing] turns on. -
Page 14: Prime Fresh
●If you want to stop the “Prime Fresh+” operation immediately, repeat step 1 - 3. The [Prime Fresh+] LED will turn off. 2. Model : NR-DZ601V ●Press the button [Zone Select] to select [B] (Prime Fresh), then press [Temp. Select] until the light LED [Prime Fresh+] turns on. -
Page 15: Fridge Room
Fridge room The position of the PC glass tray can be changed 1 Lift up the back of the tray and pull it 2 Insert the tray in the desired position by forward. Once the protrusions of the tray reversing the steps. are unhooked from rails, tilt the tray and remove it. - Page 16 Auto ice making (Model : NR-DZ601W) Auto ice-making tray Water supply tank approx. 1.2 liters Back Ice box Front Water filter Automatic ice maker To use the automatic ice maker in comfort Please use only the Do not put liquids such as the following into the drinking water for auto ice water supply tank.
- Page 17 To make ice* 1 Take out the water supply tank. 2 Fill with water. 3 Install the water supply tank. Push the water supply tank in Do not add water over the completely. “Max” line. Water supply tank Slide the lid and fill water Confirm the direction of Fill water if the level is below into the tank then put the lid...
-
Page 18: Usage Tips
To make ice (Model : NR-DZ601V) Take out the ice twister Fill with water ICE TWISTER Pull out the ice twister. (P. 22) Fill water up to the “WATER LEVEL” line. Install the ice twister To move ice cubes Twist the ice twister clockwise. -
Page 19: How To Clean The Refrigerator
Storage using hermetically sealed containers is recommended! To prevent the To prevent odors interior from being from spreading! discolored! ● Garlicky or other strong smelling ● Cut citrus fruits vegetables (→ The plastic will be discolored white.) (→ Odors will spread to other nearby food.) How to clean the refrigerator Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the power outlet. - Page 20 How to clean the refrigerator Trays Once every 3 months „ Removing „ Attaching 1 Lift up the back of the tray and pull it 2 Push the tray until it reached the end forward. Once the protrusions of the tray lock.
- Page 21 How to clean the refrigerator Ag Hygiene Zone / Prime Fresh case Once every 3 months „ Removing „ Attaching Pull out the case as far as possible. With With holding up door case FC, lift the back lifting up the front, pull it out at an angle of the case and install it along the rails inside.
- Page 22 6 Once the buzzer sound stops, cleaning is completed. process will not start. 7 Open the door and clean the ice box. Ice twister / Ice box (Model : NR-DZ601V) Once every 3 months „ Removing „ Attaching...
-
Page 23: Troubleshooting
Troubleshooting Before you call for service, please check the following items: ●Check that the plug and its socket are in good condition. ●Check if there is any problem on main fuse and electrical The refrigerator system of the house. does not operate. ●Check by unplug and wait for 5 minutes before plugging it back ●Check to be sure that light in control panel is displayed at proper position. - Page 24 The sound becomes more quiet after cooling fully. Light does not ●Please contact Panasonic service center. turn on. ●Has the “Quick Freezing” mode been activated? (P.13) ECONAVI ●Is the temperature setting of the freezer compartment and...
-
Page 25: Specifications
●ECONAVI operation may be performed while the refrigerator ECONAVI is being used depending on the conditions of use, but the light rarely cooling performance is maintained. turns off). Specifications Model No. NR-DZ601W NR-DZ601V Freezer Star Rating Total 550/533 Capacity (L) Freezer 156/146 Gross/Storage (ISO 8561) - Page 26 Memo...
