Cuisinart 85-3691-4 Assembly Manual

Gourmet outdoor oven
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Check out our
Cuisinart
®
Video Series @
www.cuisinartbbqs.com
Cuisinart
Gourmet Outdoor Oven
®
READ AND SAVE MANUAL FOR FUTURE REFERENCE.
Missing or damaged parts should be claimed within 30 days of purchase.
LIMITED 2-YEAR WARRANTY
Gourmet
For support, please call 1-800-309-3452.
www.cuisinartbbqs.com
/CuisinartBBQs
Serial # __________________________________
Model Number: 85-3691-4 (P501)
/CuisinartBBQs
ASSEMBLY
MANUAL
/CuisinartBBQ
Manual Revision #: 01272015 PD

Advertisement

Table of Contents
loading

Related Manuals for Cuisinart 85-3691-4

Summary of Contents for Cuisinart 85-3691-4

  • Page 1 ® Video Series @ www.cuisinartbbqs.com Cuisinart Gourmet Outdoor Oven ® Model Number: 85-3691-4 (P501) READ AND SAVE MANUAL FOR FUTURE REFERENCE. Missing or damaged parts should be claimed within 30 days of purchase. For support, please call 1-800-309-3452. www.cuisinartbbqs.com /CuisinartBBQs...

  • Page 2: Before You Get Started

    Create authentic pizzas, amazing roasted meats, baked breads, pastas, desserts, or smoke an endless variety of foods such as brisket and baby back ribs. With your new Cuisinart Gourmet Outdoor Oven ®...
  • Page 3 POSITIONING YOUR GOURMET OUTDOOR OVEN Care must be taken to ensure that the appliance is set-up on a flat and stable surface to avoid tipping. MINIMUM CLEARANCE 1000mm / 39 inches 915mm / 36 inches 915mm / 36 inches 915mm / 36 inches MINIMUM CLEARANCE TO COMBUSTIBLE MATERIALS: Rear: 915mm / 36 inches...
  • Page 4 MOVING YOUR GOURMET OUTDOOR OVEN CAUTION NEVER RELOCATE A HOT OVEN. Always ensure that the oven is not in operation and is cooled completely, before attempting to lift the moving handles to relocate. • The oven can be moved easily by pulling out the two moving handles that are nested in the left cart legs. •...

  • Page 5: Inside Of The Oven

    GETTING TO KNOW YOUR CUISINART GOURMET ® OUTDOOR OVEN Chimney Cap Chimney Chimney Damper Thermometer Door Latch Cooking Chamber Smoker Vent Control Air Intake Controls Door Latch Fire Chamber Tool Hooks Tool Hooks Top Shelf Moving Handle Cart Assembly Bottom Shelf...

  • Page 6: Before First Use

    BEFORE FIRST USE 1. Read this manual in its entirety. 2. Clean the oven. 3. Get to know key features. 4. Season the oven. 5. Get cooking!!! CLEANING BEFORE USE Before attempting to light your Gourmet Outdoor Oven, it is necessary to clean the inside of the oven to remove the special coatings applied during the manufacturing process.
  • Page 7 PROS CONS CHARCOAL BRIQUETTES 100% all-natural charcoal briquettes. Some charcoal briquettes contain chemical accelerants and additives, which may disrupt the flavours of your food. Briquettes are all sized the same allowing for a Will not burn quite as hot as lump charcoal. more consistent burn.
  • Page 8 NEVER USE hearth logs meant for a NOT contain any chemicals. fireplace. Use twigs, paper and corrugate to get your fire going. HOW TO LIGHT YOUR CUISINART OUTDOOR OVEN ® USING HARDWOOD 1. Lay out kindling on your wood grate first.
  • Page 9 HOW TO USE THE CHIMNEY DAMPER The chimney damper control handle allows the user to: 1. Control how quickly the fuel burns in the fire chamber. Pointer 2. Control the temperature output inside of the cooking chamber 3. Control the smoke inside of the cooking chamber by venting smoke out the chimney THERE ARE THREE POSITIONS WITHIN THE CHIMNEY DAMPER Chimney is closed...
  • Page 10 HOW TO USE THE AIR INTAKE CONTROLS Opening the three air intake controls and the chimney damper, allows air to enter the wood chamber and circulate through the oven, increasing the flames and temperature within the cooking chamber. These controls can be used to both raise and lower temperatures. CLOSE OPEN OPEN...
  • Page 11 SEASONING BEFORE USE Cleaning and seasoning your Gourmet Outdoor Oven are essential to its proper operation. 1. Ensure that the cooking grills and the baking stone are positioned correctly inside of the cooking chamber. 2. Open the door of the fire chamber to add the recommended dry hardwood or lump charcoal. Load small pieces of hardwood, not longer than 30cm / 12”.
  • Page 12 HOW TO SMOKE USING THE SMOKER VENT AND SMOKER BOX FEATURES ATTENTION When not in use, store your smoker box indoors. When not smoking, ensure that the Smoker Vent Control is in the closed position. 1. Allow enough time to build a fire and get the oven up to temperature. 2.

  • Page 13: Cooking Tips

    COOKING TIMES Cooking times vary depending on the type of foods being prepared, its weight and size. When cooking a particular dish for the first time in your Cuisinart Gourmet Outdoor Oven, you should regularly monitor the ®...

  • Page 14: Cleaning And Maintenance

    HOW TO USE YOUR OUTDOOR OVEN AS A FIREPLACE The Cuisinart Gourmet Outdoor Oven can easily be ® transformed into an outdoor fireplace. Simply open the fire chamber door after cooking is complete to provide warmth and ambience to your outdoor space.
  • Page 15 CLEANING THE COOKING CHAMBER 1. Before cleaning the cooking chamber, remove the baking stone and the fire bricks. ATTENTION Do not allow the oven to build up with stains and grease. It is much harder to clean an oven that has been neglected for a long period of time, and much easier to perform maintenance on a regular basis.

  • Page 16: Warranty And Service

    WARRANTY & SERVICE DO NOT RETURN TO THE STORE: Call the Cuisinart Outdoor Products Customer Care Hotline ® 1-800-309-3452 HOURS: 8AM- 7PM EST Mon-Fri, Closed Saturday and Sunday BEFORE YOU CALL FOR ASSISTANCE, have the following information available: 1. Serial number: The serial number is located on the upper rear panel of your outdoor oven on the rating label, as well as on the front cover of the user manual.
  • Page 17 2 YEAR LIMITED WARRANTY Trileaf Distributions hereby warrants to the original purchaser of ® this Cuisinart Gourmet Outdoor Oven that it will be free of defects, ® under normal use, for up to 2 years, from the date of purchase, when purchased from an authorized dealer, under the terms and exclusions listed below.

  • Page 18: Hardware Pack

    HARDWARE PACK Tools Needed for Assembly No. Description Part Number Qty. M4x10 Screw 10101-04010-036 • #2 Phillips screwdriver 4mm Washer 40300-04000-036 • Adjustable wrench Locking Bolt & Chain P501-0027-9000 M6x15 Screw 10101-06015-036 For correct hardware assembly, always 6mm Washer 40300-06000-036 position the lock washer between the screw 6mm lock Washer 41400-06000-036...
  • Page 19 EXPLODED DIAGRAM AND PARTS LIST FOR 85-3691-4 (P501) Item No. Qty. Description Part No. Item No. Qty. Description Part No. Left Side panel P501-0001-9047 Fire Chamber Door P501-0020-9014 Cooking Chamber Door P501-0002-9047 Smoker Box + Lid P501-0021-9047 Window P501-0003-9000 Bracket for Smoker Box...

  • Page 20: Assembly Instructions

    ASSEMBLY INSTRUCTIONS YOU WILL NEED: G x 2 J x 2 H x 2 YOU WILL NEED: D x 8 E x 8...
  • Page 21 ASSEMBLY INSTRUCTIONS YOU WILL NEED: D x 2 E x 2 YOU WILL NEED: D x 10 E x 10...
  • Page 22 ASSEMBLY INSTRUCTIONS YOU WILL NEED: A x 4 K x 4 B x 4 YOU WILL NEED: L x 2 M x 2 C x 2...
  • Page 23 ASSEMBLY INSTRUCTIONS CAUTION THIS STEP REQUIRES 2 OR MORE PEOPLE. DO NOT ATTEMPT ALONE. EXTREMELY HEAVY. WEIGHT: 54 kg / 119 lbs WARNING Before completing this step, remove both the Cooking Chamber and Fire Chamber doors. Reach hands inside Oven to lift safely. For your safety, do not lift the oven from the bottom.
  • Page 24 ASSEMBLY INSTRUCTIONS YOU WILL NEED: D x 6 E x 6...
  • Page 25 ASSEMBLY INSTRUCTIONS YOU WILL NEED: N x 8...
  • Page 26 ASSEMBLY INSTRUCTIONS...
  • Page 27 ASSEMBLY INSTRUCTIONS YOU WILL NEED: A x 2...
  • Page 28 ASSEMBLY INSTRUCTIONS YOU WILL NEED: D x 4 F x 4 E x 4...
  • Page 29 ASSEMBLY INSTRUCTIONS...
  • Page 30 ASSEMBLY INSTRUCTIONS...
  • Page 31 ASSEMBLY INSTRUCTIONS...
  • Page 32 ASSEMBLY INSTRUCTIONS...
  • Page 33 ASSEMBLY INSTRUCTIONS...
  • Page 34 ASSEMBLY INSTRUCTIONS...
  • Page 35 NOTES...
  • Page 36 Register your Gourmet Outdoor Oven @ www.cuisinartbbqs.com Cuisinart Customer Service: ® 1-800-309-3452 Join the conversation facebook.com/cuisinartbbqs twitter.com/cuisinartbbqs pinterest.com/cuisinartbbq Cuisinart is a registered ® trademark used under license © 2015 Trileaf Distributions Trifeuil...
