- Page 1 Bosch DCN Standalone Automatic Camera Control DCN-SWSACC Software Manual...
-
Page 3: Table Of Contents
Bosch DCN Standalone Automatic Camera Table of Contents | en Control Table of Contents Introduction System license key Installation Allegiant video switcher 2.1.1 Configuration 2.1.2 Operation AutoDome 2.2.1 Configuration 2.2.2 Operation Cables Software Installation The DCN-SWSACC application The application main screen 3.1.1... -
Page 4: Content Panel
Bosch DCN Standalone Automatic Camera en | Table of Contents Control Upload Print layout Warning and error reports Index DCN-SWSACC_V4.0 | V1.0 | 2011.10 Software Manual Bosch Security Systems B.V. -
Page 5: Introduction
The license key can be uploaded to the system with the Download and License Tool. NOTICE! For demo purposes a demo license is available. In case you have a demo license the Bosch logo in the right top of the application will note "Demo version not for sale". The demo version is fully operational but will not be supported. -
Page 6: Installation
Start the DCN-SWSACC software. – Configure the camera control as described in: Section 3 The DCN-SWSACC application, Section 4 System, Section 5 Cameras and Section 6 Assign & store. Disconnect the temporarily PC from the DCN system: and the Allegiant. -
Page 7: Operation
Start the DCN-SWSACC software. Refer to Section 2.4 Software Installation. – Configure the ‘camera control’ as described in Section 3 The DCN-SWSACC application, Section 4 System, Section 5 Cameras and Section 6 Assign & store. Disconnect the temporarily PC from the DCN system: and the AutoDome. -
Page 8: Operation
Bosch DCN Standalone Automatic Camera en | Installation Control 2.2.2 Operation Make the connections according the image below: – – Refer to Section 2.3 Cables for cable type 5. Cables Cable 1. PC to DCN-CCU Cable 2. PC to Allegiant Cable 3. -
Page 9: Software Installation
Control Software Installation PC requirements DCN-SWSACC is compatible with Windows Vista and Windows 7 both 32 and 64 bits versions. Starter editions are not supported. PC requirements are the same as requested for Windows Vista and Windows 7 by Microsoft. -
Page 10: The Dcn-Swsacc Application
Bosch DCN Standalone Automatic Camera en | The DCN-SWSACC application Control The DCN-SWSACC application This chapter describes the main part of the application. The application main screen Figure 3.1 Application main screen Menu Workflow buttons Configuration list Content panel DCN-SWSACC_V4.0 | V1.0 | 2011.10 Software Manual Bosch Security Systems B.V. -
Page 11: Menu
Bosch DCN Standalone Automatic Camera The DCN-SWSACC application | en Control 3.1.1 Menu (1) The menu provides access to functionality present in the application. File - New (Ctrl+N) Creates a new configuration. - Open...(Ctrl+O) Opens a configuration. - Save(Ctrl+S) Saves the configuration to the current configuration filename. -
Page 12: System
Bosch DCN Standalone Automatic Camera en | System Control System This workflow describes the system settings: PC Communication Settings DCN system: The DCN system: option defines the Serial communication: port of the PC to which the DCN- CCU is connected. Selecting --None-- disables the connection to the DCN system:. -
Page 13: Cameras
Bosch DCN Standalone Automatic Camera Cameras | en Control Cameras This workflow defines the Camera system and the cameras. Camera System Type The DCN system supports two types of Camera systems: Allegiant: cameras are connected to the video switcher and multiple screen outputs can be controlled. -
Page 14: Add/Remove Camera
Bosch DCN Standalone Automatic Camera en | Cameras Control Number of audience screens: This selection allows you to select the Number of audience screens:. The Number of audience screens: (excluding the operator screen) can be set from 1 till 4. All audience screens show the same picture. -
Page 15: Assign & Store
Bosch DCN Standalone Automatic Camera Assign & store | en Control Assign & store This workflow is used to assign prepositions to the units of the DCN system and store the prepositions in the Camera system. Figure 6.1 Assign & store main window The Assign &... -
Page 16: Temporarily Pc With 2 Serial Ports
Bosch DCN Standalone Automatic Camera en | Assign & store Control Temporarily PC with 2 serial ports The following preconditions of Assign & store are required: Both the DCN system and the Camera system are properly connected and have the correct settings. -
Page 17: Assigning Cameras And Prepositions To A Unit
NOTICE! The Allegiant cannot display graphic characters that are used in certain non-European and non-US languages such as Chinese. Please contact your local Bosch representative how to use alternative characters. When all units have a camera assigned the configuration must be uploaded to the DCN system. -
Page 18: Temporarily Pc With 1 Serial Port
Bosch DCN Standalone Automatic Camera en | Assign & store Control Temporarily PC with 1 serial port Make a connection between the DCN system and the temporarily PC. In workflow Section 4 System set the Section 4.1 PC Communication Settings for DCN system to the correct port. - Page 19 Bosch DCN Standalone Automatic Camera Upload | en Control Upload This workflow describes Uploading the configuration to the DCN system. To do so: Click the Start upload button. – The window text is changed into Uploading the configuration to the DCN system.
-
Page 20: Print Layout
Bosch DCN Standalone Automatic Camera en | Print layout Control Print layout The print function (Section 3.1.1 Menu (1)) allows you to print the camera configuration settings as given within the table below: DCN Standalone Automatic Camera Control Configuration Name configuration1.sacc... -
Page 21: Warning And Error Reports
Check the version of your DCN system. Content The DCN system with version {0} does not match the version of the DCN-SWSACC application. Update your DCN system to at least version 2.60.xxxx by using the Download and License Tool. Button Bosch Security Systems B.V. - Page 22 Bosch DCN Standalone Automatic Camera en | Warning and error reports Control Error Error issued on start upload when the DCN-SWSACC application has loaded a single CCU configuration, while it connects to a Multi CCU DCN system. Icon Main instruction The configuration can not be uploaded.
- Page 23 Bosch DCN Standalone Automatic Camera Warning and error reports | en Control Error Error issued when the required authorizations are not present in the DCN system. Icon Main instruction Check the license key of your DCN system. Content The license key of the DCN system does not contain the DCN- SWSACC authorization.
- Page 24 Error Error issued when the application fails to start. Icon Main instruction Failed to start the application. Repair the installation by starting the DCN-SWSACC setup and choose Repair. Button DCN-SWSACC_V4.0 | V1.0 | 2011.10 Software Manual Bosch Security Systems B.V.
- Page 25 Bosch DCN Standalone Automatic Camera Warning and error reports | en Control Error Error issued when the connection with the DCN system by IP address or Hostname cannot be established. Icon Main instruction Check your connection with the DCN system.
- Page 26 Bosch DCN Standalone Automatic Camera en | Index Control Index Add/Remove camera 14 Assign & store 15 Assigning the overview 16 Cables 8 Camera Control Settings 13 Camera information 14 Camera System Type 13 Demo version 5 Menu 11 PC Communication Settings 12...
- Page 28 Bosch Security Systems B.V. Kapittelweg 10 4800 RA, Breda The Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2011...
