Repeater
Operating Instructions
VL-FAN1BX
Model No.
Thank you for purchasing a Panasonic Repeater.
This unit is an accessory unit for Panasonic Wireless Video Intercom System.
You must register this unit to the main monitor station before using.
Please read these Operating Instructions before using the unit and save for future reference.
Advertisement
Table of Contents
Related Manuals for Panasonic VL-FAN1BX
Summary of Contents for Panasonic VL-FAN1BX
-
Page 1: Operating Instructions
Model No. Thank you for purchasing a Panasonic Repeater. This unit is an accessory unit for Panasonic Wireless Video Intercom System. You must register this unit to the main monitor station before using. Please read these Operating Instructions before using the unit and save for future reference. -
Page 2: Table Of Contents
Table of Contents Important Information Important safety instructions ..............3 Additional safety information ..............4 For best performance ................5 LBefore using ......................... 5 LLocation/avoiding noise ....................5 LEnvironment ......................... 5 LInstallation ........................6 LWhile in use ........................6 LTapping ......................... 7 LUsing near medical equipment .................. -
Page 3: Important Information
Important Information Important safety instructions 1) Read these instructions. All the safety and operating instructions should be read before the appliance is operated. 2) Keep these instructions. The safety and operating instructions should be retained for future reference. 3) Heed all warnings. All warnings on the appliance and in the operating instructions should be adhered to. -
Page 4: Additional Safety Information
Important Information Additional safety information 1. Use only the power source marked on the unit. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. 2. Use only the specified AC adaptor. 3. -
Page 5: For Best Performance
Important Information For best performance Before using L� I t is prohibited to disassemble or modify this unit. Contact the dealer where you purchased this unit for repairs. L� W hen power fails, this unit cannot be used. Location/avoiding noise L�... -
Page 6: Linstallation
Important Information Installation L� I f there are no obstacles between this unit and the main monitor station, you can install the unit within about 100 m from the main monitor station. (Usage area varies depending on the location where the unit is installed. Install the unit in the locations where the STATUS indicator lights in green (page 14).) Lights in green. -
Page 7: Ltapping
Important Information Tapping This unit uses digital wireless technology so that a call is rarely intercepted. However, calls may be tapped by a third party because the unit also communicates using radio waves. L� “ Tapping” means that the other party intercepts a radio message intentionally or accidentally by using a receiver. -
Page 8: Introduction
Introduction Included items Item Quantity Notes Repeater ------ AC adaptor Cord length: Approx. 3 m AC cord Cord length: Approx. 1.8 m Wood screws For wall-mounting Washers For wall-mounting Registration number sticker ------... -
Page 9: Feature Highlights
Introduction Feature highlights If the sub monitor station is away from the main monitor station or there are the following obstacles between them, the radio signal weakens. In this case, sound cuts in and out, and moreover “OUT OF RANGE” is displayed on the sub monitor station as it cannot be used. The repeater strengthens the radio wave signal and extends the range of use which may resolve these problems when it is installed between the main monitor station and the sub monitor station. -
Page 10: Preparation
Preparation Location of controls N� F ront View / Right side view A Antenna L� T ransmitter/Receiver of radio waves. B {PROGRAM} button L� P ress to register to the main monitor station. C Indicators L� S how the status of this unit and the radio signal level (page 11). -
Page 11: Lindicators
Preparation Indicators The indicators show the status of this unit and radio wave signals as follows. Indicator Status POWER Green, light on The power is turned on. Light off The power is turned off. STATUS Green, flashing While registering to the main monitor station. -
Page 12: Installation
Installation Registering the repeater to the main monitor station (REGISTRATION/CANCELLATION) To use the repeater, the registration to your main monitor station is required. L� T he repeater can only be registered to one main monitor station at a time. Registering the repeater (REGISTRATION) Connect the AC cord to the AC adaptor, then connect the AC cord to a power outlet installed nearby the main monitor station. -
Page 13: Lto Stop Using The Repeater (Cancellation)
Installation Attach the included registration number sticker on the repeater. Registration number sticker (Example: 1st. repeater) Disconnect the AC adaptor and place the repeater in the desired location. L� E ven if you disconnect the AC adaptor, the registration to the main monitor station is not canceled. -
Page 14: Installing The Repeater
L� I t is recommended that you install the repeater in a location where the STATUS indicator lights in green although you can install it in other places where the indicator lights in amber or red. L� U se only the included Panasonic AC adaptor PQLV202. -
Page 15: Wall-Mounting
Installation Wall-mounting You can mount the repeater on the wall with the included wood screws and washers. Mount the repeater on a wall (pillar) where the wood screws can be firmly fixed. Drive the wood screws with washers into the wall (pillar). Approx. -
Page 16: Help
Help Troubleshooting Indicator Problem Cause & Solution Page The POWER indicator is L� T he power is not turned on. Connect the AC turned off. adaptor. The STATUS indicator is L� T he repeater has not been registered. Register it turned off. -
Page 17: Cleaning
Help Cleaning When cleaning this unit, disconnect the AC adaptor from the power outlet. Clean the repeater with a soft, dry cloth. Important: L� D o not use anything containing alcohol, polish powder, powder soap, benzine, thinner, wax, petroleum, or boiling water. Also do not spray with insecticide, glass cleaner, or hair spray. -
Page 18: General Information
General Information Technical data about this product Power supply: AC adaptor (100 – 240 V AC, 50/60 Hz) (12.0 V DC, 750 mA) Current consumption: Standby: Approx. 0.05 A During operation: Approx. 0.08 A Dimensions: Approx. height 27 mm x width 101 mm x depth 82 mm Approx. - Page 19 Index AC adaptor ......8, 12, 14 AC cord ....... 8, 12, 14 Antenna ......... 10 Cancellation ........13 Cleaning ........17 DC IN jack ......10, 12, 14 {FACTORY DEFAULT RESET} button ........10, 17 Indicators ........10 IN USE indicator .......10, 11 POWER indicator ..10, 11, 12, 14 {PROGRAM} button ....
